PART LIST NUMBER DESCRIPTION QUANTITY REAR BASE MAIN FRAME FRONT BASE GUIDE ROD MAIN VERTICAL FRAME TOP CROSS BEAM RESIST BAR RIGHT TOP BEAM PRESS BAR RIGHT CHEST SUPPORT LEFT CHEST SUPPORT LEG EXTENSION LEFT TOP BEAM HAND GRIP ANGLE IRON FRONT SIDE BASE DIP- BAR CHIN-UP BAR...
Page 6
SHORT CABLE WITH NO BALL LONG CABLE WITH NO BALL CABLE WITH ONE AND HALF BALL CABLE WITH ONE BALL AND BOLT BIG FOAM ROLLER FOAM ROLLER WEIGHT PLATE TOP PLATE LOCK LEVER TUS PULLEY CHAIN HOOK PLASTIC CIRCLE ADJUSTABLE CYLINDER RUBBER BUFFER SPRING CLIP BALL HEAD PIN...
Page 8
STEP 01 1. Attach part (21) to part (B) with bolt (37). Attach part (O) to part (B) with bolt assembly (46). Attach part (B) to part (C) with bolt assembly (42) and (49). 2. Attach part (P) to part (C) with bolt assembly (48). 3....
Page 9
STEP 02 1. Attach part (E) and part (AI) to part (B) with bolt assembly (45) and (48). 2. Attach part (V) and part (AH) to part (A) with bolt assembly (48). Attach part (AH) to part (V) with bolt assembly (48). 3.
Page 10
STEP 03 1. Attach part (L) to part (B) with bolt assembly (49). 2. Attach part (G) and part (AI) to part (E) with bolt assembly (48). 3. Attach part (I) to part (F) with part (AA) and bolt assembly (27). 4....
Page 11
STEP 04 1. Attach part (Z) to part (V) with bolt assembly (49). 2. Slide part (W) and part (X) to part (V), secure with plastic bolt (25). 3. Attach part (20) to part (V) with bolt assembly (29). 4. Attach the other side of part (20) to part (W) and part (V) with bolt assembly (31). 5....
Page 12
STEP 05 1. Attach part (S) to part (M) with bolt assembly (35). 2. Insert part (T) into port of part (V), secure with bolt assembly (44). 3. Attach part (S) to part (V) and part (T) with bolt assembly (46). 4.
Page 13
STEP 06 1. Attach two pulley (15) to part (F) with bolt assembly (39). 2. Attach two pulley (15) to part (H) with bolt assembly (39). 3. Attach two pulley (15) to part (Z) with bolt assembly (39). 4. Attach a pulley (15) to part (E) with part (24), bolt assembly (46). 5.
Page 14
STEP 07 CABLE ASSEMBLY 1. Assembly the long cable with no ball (7) Attach one end of the cable to part (K) with bolt assembly (36). Then thread the other end of the cable over pulley Z1, down and round pulley AJ1 on upright pulley block (AJ), up and over pulley Z2, finally attach the end to part (J) with bolt assembly (36).
Page 15
STEP 08 1. Attach part (1) to part (E) with bolt assembly (34). 2. Attach part (2) to part (B) and part (O) with bolt assembly (34) and (28). 3. Attach part (3) to part (V) with bolt assembly (34). 4.
Page 16
