Citizen iDP-3110 User Manual
Mini dot matrix printer idp-3110
Hide thumbs
Also See for iDP-3110:
- User manual (36 pages) ,
- Service manual (17 pages) ,
- Product manual (24 pages)
Subscribe to Our Youtube Channel
Related Manuals for Citizen iDP-3110
Summary of Contents for Citizen iDP-3110
- Page 1 User’s Manual CITIZEN User’s Manual MINI DOT MATRIX PRINTER iDP-3110 MODEL Japan CBM Corporation Information Systems Div. CITIZEN 1/35...
-
Page 2: Declaration Of Conformity
User’s Manual 1995.09.04(10-DCL)8 Declaration of Conformity Manufacturer's Name : : Japan CBM Corporation Manufacturer's Address : 1-1-7, Okubo, Shinjuku-ku, Tokyo 169, Japan Declare the Product Product Name Dot Matrix Printer Model Number (s) iDP-3110 Series (iDP3110R, iDP3110P) (S.NO.95X0001 - ) -
Page 3: Important Safety Instructions
User’s Manual IMPORTANT SAFETY INSTRUCTIONS * Read all of these instructions and save them for later reference. * Follow all warnings and instructions marked on the product. * Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. - Page 4 User’s Manual IMPORTANT: This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instruction manual, may cause interference to radio communications. It has been tested and found to comply with the limits for a Class A computing device pursuant to Subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment.
-
Page 5: Table Of Contents
User’s Manual CONTENTS 1. INTRODUCTION ..............................6 1.1 Features................................6 1.2 Accessories ................................6 2. TYPE CLASSIFICATIONS ............................7 2.1 Type ..................................7 2.2 AC adapter ................................7 2.3 Specifications............................... 8 3. EXTERNAL APPEARANCE AND PART DESCRIPTION ..................9 3.1 External Appearance............................ -
Page 6: Introduction
User’s Manual INTRODUCTION The iDP 3110 is a dot-impact printer suitable for use with various data communication terminals, and measurement terminals. This product is extremely compact and features extensive functions suited for a wide range of applications. Please read this manual thoroughly to understand the printer before use. -
Page 7: Type Classifications
User’s Manual 2. TYPE CLASSIFICATIONS 2.1 Type The product is categorized according to the naming plan indicated below. iDP-3110 iDP-3110 230 - Model Name Printer cover Number of columns A : 60mm(Dia.) 24 : 24 columns/144 dots(MD-910) Paper roll 40 : 40 columns/180 dots(MD-911) B : 80mm(Dia.) -
Page 8: Specifications
User’s Manual 2.3 Specifications Item iDP3110-24* iDP3110-40* 1 Printing method Dot matrix 2 Printing direction One-way printing 3 Character configuration (5 + 1) × 8 (4 + 0.5) × 8 (W × H) 4 Number of columns per line... -
Page 9: External Appearance And Part Description
User’s Manual 3. EXTERNAL APPEARANCE AND PART DESCRIPTION 3.1 External Appearance CITIZEN 9/35... -
Page 10: Part Descriptions
User’s Manual 3.2 Part Descriptions 1. DC Jack Insert the output plug of the AC adapter attached. 2. Power Switch When switched ON, power is supplied to the printer, starting the initializing operation. 3. Power Lamp Lighted when power is turned ON and goes out when turned OFF. -
Page 11: Operations
User’s Manual 4. OPERATIONS 4.1 Inserting the AC Adapter (1) Ensure that the power switch is OFF. (2) Insert the output plug of the AC adapter into the DC jack of the printer. (3) Insert the power plug of the AC adapter into a power outlet supplying the designated voltage. -
Page 12: Inserting The Printer Cover
User’s Manual 4.2 Inserting the Printer Cover (1) Hold the protruding section at the rear of the printer cover and lift in the direction indicated. (2) Attach the cover by pressing downward after hooking the cover to the acceptor located in the front part. -
Page 13: Inserting Ribbon Cassettes
User’s Manual 4.3 Inserting Ribbon Cassettes (1) Turn the printer off and remove the printer cover. (2) Press down on the Ribbon cassette while inserting the ribbon between the printing head and the platen. (3) Wind up the ribbon slack by turning the knob in the direction of the arrow. -
Page 14: Inserting Paper
User’s Manual 4.4 Inserting Paper (1) Remove the printer cover. (2) Ensure that the end of the paper is straight as indicated in the diagram. (3) Insert the end of the paper into the slot of the printer mechanism. -
Page 15: Self Test Printing
User’s Manual 4.5 Self Test Printing A self-printing function is incorporated in this product to enable the printer to check itself. This function is triggered by the following procedure. (1) Insert paper into the printer. (2) Ensure that the ribbon cassette is attached correctly and turn the power OFF. -
Page 16: Parallel Interface
User’s Manual 5. PARALLEL INTERFACE 5.1 Specifications a) Data input system : 8 bit parallel (DAT 1-8) b) Control signal : ACK, BUSY, STB, RESET, SELECT c) Compatible Connector : Printer side : 57LE-40360 (AMPHENOL or equivalent) : Cable side : 57-30360 (AMPHENOL or equivalent) 5.2 Connector Pin Assignment... -
Page 17: Description Of Input / Output Signals
User’s Manual 5.3 Description of Input / Output Signals (1) Input signal All input signals utilize type 74HC of CMOS and can be used in TTL level as the input is pulled up with 3.3 kW resistance. - DATA... - Page 18 User’s Manual · Output [ Printer side ] [ Host side ] (4) Timing chart Timing for data entry and printing 0.5 ms MIN 1 ms MIN T2, T3 2 ms TYPE Data receiving Printer is capable of accepting data from the host while the BUSY signal is in the “LOW” state. Printer cannot accept data when the signal is “HIGH”.
-
Page 19: Serial Interface
User’s Manual 6. SERIAL INTERFACE 6.1 Specifications 1) Synchronization : Asynchronous 2) Baud rate : User selection, 4,800; 9,600 Baud / sec 3) Word configuration : Start bit 1 bit : Data bit 8 bit : Stop bit More than 1 bit... -
Page 20: Connector Pin Assignment
User’s Manual 6.2 Connector Pin Assignment SIGNAL SIGNAL SIGNAL DIRECTION FUNCTION RS232C NAME HOST-PRINTER Frame ground Signal ground ® Received data ¬ Printer BUSY signal ® RESET Printer reset signal Note : 1. Signals for RS-232C are based on EIA RS-232C level. - Page 21 User’s Manual 3) RESET Signal resets the entire printer. (More than 4ms.) 4) FG Frame ground 5) GND Common ground for the circuit. (2) Data configuration (1) Start bit (1 bit) (2) Data bit (8 bit) (3) Stop bit (more than 1)
- Page 22 User’s Manual (4) Electrical characteristics 1) RS-232C circuit Input (RD) [PRINTER] [HOST] MAX 232 equivalent Mark = (-8V) : Stop bit Space = (+8V) : Start bit Output (DTR) MAX 232 equivalent DTR (-8V) when BUSY (+8V) when READY...
-
Page 23: Dip Switch Setting
User’s Manual 7. DIP SWITCH SETTING 7.1 Serial Interface Type Switch Functions Shipping Setting Character direction Normal Inverted selection character character Baud rate selection 9600 BPS 4800 BPS Not used 7.2 Parallel Interface Type Switch Function Shipping Setting Character direction... -
Page 24: Print Control Function
User’s Manual 8. PRINT CONTROL FUNCTION 8.1 Control Command 1) Print command (CR or LF) If parallel interface is used, select code CR (0DH) or LF (0AN) on the DIP switch 2. If the selected code (CR or LF) is input, the data in the print buffer is printed and line feed is performed. - Page 25 User’s Manual 4) Power down function In order to reduce power consumption when printer is waiting for the operation, 2 power down modes triggered by the codes DC2 and DC3 are incorporated into this product. When the printer receives power down commands (DC2 or DC3), it switches to the power down mode after all entered data is printed out.
- Page 26 User’s Manual a) Line spacing setting command (ESC + A + n) Dot line space setting is determined by entering the code ESC +A + n. Initial setting is 2 dot line space. The n should be an even number in the range of 0 £ n £ 255.
- Page 27 User’s Manual As this printer prints out 4 dot lines as one unit, the lacking data is output as space once the data for 4 dot lines are read in or the output of data specified in n1, n2 and n3 has finished.
- Page 28 User’s Manual d) Character registration (ESC + & + A1 + A2) Individual patterns can be registered by entering the code ESC + & + A1 + A2, then entering the pattern data. A maximum of 8 characters can be registered, and any address in the range of 20H to FFH can be used for the registration.
- Page 29 User’s Manual d-2) Multiple character registration By repeating the single character registration, a maximum of 8 characters can be registered. When defining multiple characters in a successive address (character code), register pattern data for a maximum of 8 characters by designation A1 as the starting address and A2 as the ending address.
- Page 30 User’s Manual d-4) In case of iDP3110-40* (40 columns) specification Pattern data to be registered must consist of 7 bytes per character. That is, pattern data configured by a 7 ´ 8 dot matrix is broken up into 7 vertically positioned units each of which is represented by 1 byte of data.
-
Page 31: Character Set
User’s Manual 9. CHARACTER SET 9.1 Character code (In the following Table *1-*12 are the characters of the next page by a command, ECS + R + n.) CITIZEN 31/35... - Page 32 User’s Manual CITIZEN 32/35...
- Page 33 User’s Manual Individual Country Character Codes CITIZEN 33/35...
-
Page 34: External Dimensions
User’s Manual 10. EXTERNAL DIMENSIONS CITIZEN 34/35... - Page 35 User’s Manual CITIZEN 35/35...
