Electronic continuous flow gas indoor water heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

Installation Instructions

The ONLY suitable flue parts are certified Rheem coaxial flue components carrying the following label:
•
Unless a certified Rheem coaxial flue system, venting to the outside through a certified Rheem
terminal is installed in accordance with the Installation Instructions.
•
If a loud continued vibration occurs during operation
This water heater must be installed and serviced by an authorised person.
Owner's Guide
Electronic Continuous Flow
Gas Indoor Water Heater
864, series
027 models
DO NOT use any other type of flue parts.
Carefully follow the Installation Instructions.
DO NOT OPERATE THIS WATER HEATER:
Please leave this guide with the householder.
and
INSTALLER:
OPERATOR:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 27 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rheem 27

Summary of Contents for Rheem 27

  • Page 1: Installation Instructions

    Gas Indoor Water Heater 864, series 027 models INSTALLER: The ONLY suitable flue parts are certified Rheem coaxial flue components carrying the following label: DO NOT use any other type of flue parts. Carefully follow the Installation Instructions. OPERATOR: DO NOT OPERATE THIS WATER HEATER: •...
