Page 1
instructions, troubleshooting guide, and guarantee Problems? Don’t take it back to the shop, they won’t be able to fix it. Ring the helpline 0845 658 9700 it’s a local rate number...
Read the instructions before using your vacuum cleaner, and keep them safe. If you pass the cleaner on, pass on the instructions too. important safeguards Follow basic safety precautions, including the ones below. It’s quite a list, but most of them are simple common sense.
connection The cleaner doesn’t need an earth. It has a 13A BS1362 fuse in a 13A BS1363 plug. To replace the plug, fit the blue wire to N, and the brown wire to L. Fit the cord grip. If in doubt, call an electrician. Don’t use a non-rewireable/moulded plug unless the fuse cover is in place.
13 You’ll have your own preferences, but here are few tips for the first time user. big brush used with the extension tubes, for floors and carpets. Press the rear of the brush pedal to extend the bristles for hard floors, or floor coverings without pile.
27 Keep clear of the cable, as it rewinds at a fair lick. If it catches on anything, stop pressing, and it’ll stop rewinding. 28 We’ve tried not to make it too powerful, to avoid wrecking your home, so you may need to push the plug end into the storage area manually.
Page 7
outlet filter 49 Push the lock down, then lift the cover off the cleaner. 50 Pull the outlet filter out of the cover. 51 If the filter looks a bit mucky, tap it over the newspaper, to dislodge the dirt. 52 If its very dirty, soak it in warm soapy water, swill it out under a running tap, to remove all trace of soap, then let it air dry, till it’s completely dry, before refitting.
help – 0845 658 9700 If you need help, note the Model No (on the rating plate) and ring the helpline 0845 658 9700 (it’s a local rate number). spare parts Note the Model No (on the rating plate) and the part(s) you need, then ring the helpline –...
