R
TOP VIEW
SIDE VIEW
Panel
Size
STD
Large
Page 4
3100-I ACT WOOD INSERT
INSERT DIMENSIONS
8-5/8"
(219mm)
12-3/16"
(310mm)
20-3/8"
(518mm)
7-7//8"
(00mm)
A
B
44-5/8"
30-1/2"
50-1/2"
34-1/2"
27-7/16"
(697mm)
22-7/16"
(570mm)
C L
5-3/8" (137mm)
38-7/8"
(987mm)
23-1/8"
(587mm)
26-1/4"
(667mm)
B
250-6381D
14-1/8"
(359mm)
21-1/2"
(546mm)
FRONT VIEW
A
September 1, 2008
