1
4
1. Connect the supplied RJ-11 cable to the DSL port on the back of your device to
the phone port that supplies your ADSL.
2. And/or, insert a compatible 3G SIM card into the USIM slot on the back of the
device.
3. Connect the supplied RJ-45 Ethernet cable from one of the Ethernet ports on
the back of the device to your computer.
4. Screw the supplied detachable antennas to the Wi-Fi and 3G connectors on
the back of the router.
5. Connect the supplied power adapter to your router and press the on/off button
to power the router on.

Connecting the cables

5
2
4
3
1
4
