Dynex DX-TVM112 Assembly Manual

Tv wall mount
Hide thumbs Also See for DX-TVM112:

Advertisement

Quick Links

Download this manual
DX-TVM112
TV Wall Mount
For either wood-stud or
concrete wall installations
A S S E M B LY G U I D E
Before using your new product, please read these instructions to prevent any damage.
Tools needed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Package contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation instructions . . . . . . . . . . . . . . . . . . . . . . . 4

Advertisement

loading

Related Manuals for Dynex DX-TVM112

Summary of Contents for Dynex DX-TVM112

  • Page 1 A S S E M B LY G U I D E DX-TVM112 TV Wall Mount Safety information and specifications ..2 Tools needed ....... . . 2 Package contents.

  • Page 2: Safety Information And Specifications

    Wall-mount weight: 3 lbs. doubts about the safety of the installation, contact Customer Service or call a qualified contractor. Dynex is not We’re here for you responsible for damage or injury caused by incorrect www.dynexproducts.com installation or use.

  • Page 3: Package Contents

    A Wall Plate (1) B Left TV Bracket (1) C Right TV Bracket (1) P Wall plate template (1) DX-TVM112 Wall Plate Template • Gabarit de la plaque de montage • Plantilla de la placa de montaje Dessus Dessus Vista superior...

  • Page 4: Installation Instructions

    DX-TVM112 Installation instructions Installation instructions STEP 1 - Determine wall-mount location Notes: • For more detailed information on determining where to drill your holes, visit our online height-finder at: http://mf1.bestbuy.selectionassistant.com/index.php/heightfinder • Your TV should be high enough so your eyes are level with the middle of the screen. Normally, 40 to 60 inches from the ground.
  • Page 5 Edge-to edge Wall plate (A) Drill stud finder M (2) DX-TVM112 Wall Plate Template • Gabarit de la plaque de montage • Plantilla de la placa de montaje Dessus Dessus Vista superior Vista superior Level Note: For wood frame installations, use Tools Needed a stud finder to locate a wood stud first.
  • Page 6 1/2" socket Drill Wall plate (A) O (3) wrench Hammer DX-TVM112 Wall Plate Template • Gabarit de la plaque de montage • Plantilla de la placa de montaje Dessus Dessus Vista superior Vista superior Note: For wood frame installations, use Tools Needed a stud finder to locate a wood stud first.
  • Page 7 Installation instructions DX-TVM112 STEP 3 - Determine whether your TV has a flat back or an irregular or obstructed back 1 Carefully place your TV screen face-down on a cushioned, clean surface to protect the screen from damages and scratches.
  • Page 8 DX-TVM112 Installation instructions STEP 4 - Select screws, washers, and spacers 1 Select the hardware for your TV (screws, washers, and spacers). A limited number of TVs come with mounting hardware included. (If there are screws that came with the TV, they are almost always in the holes on the back of the TV.) If you don't know the correct length of the mounting screws your TV requires, test various sizes by...
  • Page 9 Installation instructions DX-TVM112 STEP 5 - Option 1: Attaching the mounting hardware to TVs with a flat back 1 Align the left and right TV brackets (B and C) with the screw holes on the back of the TV. Make sure that the brackets are level.
  • Page 10 DX-TVM112 Installation instructions STEP 5 - Option 2: Attaching the mounting hardware to TVs with irregular or obstructed backs 1 Align the left and right TV brackets (B and C) with the screw holes on the back of the TV. Make sure that the brackets are level.
  • Page 11 Installation instructions DX-TVM112 STEP 6 - Mounting the TV to the wall plate 1 Place the TV brackets (B and C) into the slotted flanges of the wall plate (A). 2 Push the bottom of the TV toward the wall until the latch mechanism clicks into place.
  • Page 12 DX-TVM112 Installation instructions Removing the TV from the wall plate 1 Grasp the TV by the bottom edge, then pull down on the locking cords and pull the bottom of the TV out from the wall. 2 Release the locking cords and lift the top of the TV from the wall bracket.
  • Page 13 7601 Penn Ave. South, Richfield, MN 55423 U.S.A. © 2013 BBY Solutions, Inc. All rights reserved. DYNEX is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
