ASSEMBLY INSTRUCTIONS
DX-WD1239
TV Cart
Tools needed............................................................3
Package contents ...................................................3
Assembly instructions...........................................5

Advertisement

loading
Need help?

Need help?

Do you have a question about the DX-WD1239 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dynex DX-WD1239

Summary of Contents for Dynex DX-WD1239

  • Page 1 ASSEMBLY INSTRUCTIONS DX-WD1239 TV Cart Safety information and specifications ....2 Tools needed............3 Package contents ...........3 Assembly instructions...........5...

  • Page 2: Safety Information And Specifications

    DX-WD1239 Safety information and specifications CAUTION: Maximum weight: 95 lbs. (43.09 kg) Maximum screen size: 42" This TV cart’s work surface is intended only for Weight capacity (top of TV cart): 95 lbs. (43 kg) use with a product not weighing more than 95 Weight capacity (middle shelf ): 25 lbs.

  • Page 3: Tools Needed

    DX-WD1239 Tools needed No. 2 Phillips screwdriver Hammer Caution: Do not use an electric drill or screwdriver Flatblade screwdriver Package contents Package contents: hardware Make sure you have all the hardware necessary to assemble your new TV cart: Label Hardware Qty.
  • Page 4 DX-WD1239 Package contents: parts Note: All parts except for the stop molding (H) have a lettered sticker to make identifying parts easier. Letter Description Qty. Letter Description Qty. Right end Bottom Left end Adjustable shelf Upright Valance Stop molding Need help? Call 800-305-2204...

  • Page 5: Assembly Instructions

    DX-WD1239 Assembly instructions Step1: Assemble your TV cart on a carpeted floor or on the empty carton to avoid scratching your TV cart or the floor. Push nine hidden cams (I) into the ends (A and B), upright (C), and top (D), then insert a cam dowel (J) into each hidden cam.
  • Page 6 DX-WD1239 Step 2: Insert two metal pins (M) into the two holes beside the hidden cam on the right end (A). Repeat this step for the left end (B). You’ll need: M (4) Need help? Call 800-305-2204...
  • Page 7 DX-WD1239 Tightening hidden cams In the remaining steps, use these illustrations for instructions on tightening hidden cams. Warning: Risk of damage or injury. Hidden cams must be completely tightened. Hidden cams that are not completely tightened will loosen, and parts may separate.
  • Page 8 DX-WD1239 Step 3: Fasten the stop molding (H) to the top (D). Use a flatblade screwdriver to tighten three hidden cams. See “Tightening hidden cams” on page 7. Unfinished surface Arrow 210° You’ll need: Flatblade screwdriver Need help? Call 800-305-2204...
  • Page 9 DX-WD1239 Step 4: Fasten the left end (B) to the top (D). Use a flatblade screwdriver to tighten two hidden cams. See “Tightening hidden cams” on page 7. Finished edge Arrow 210° You’ll need: Flatblade screwdriver Need help? Call 800-305-2204...
  • Page 10 DX-WD1239 Step 5: Slide the valance (G) onto the two metal pins (M) in the left end (B). Unfinished surface Finished edge Need help? Call 800-305-2204...
  • Page 11 DX-WD1239 Step 6: Fasten the right end (A) to the top (D). Use a flatblade screwdriver to tighten two hidden cams. See “Tightening hidden cams” on page 7. Note: Make sure that the metal pins in the right end (A) insert into the holes in the valance (G).
  • Page 12 DX-WD1239 Step 7: Fasten the upright (C) to the top (D). Use a flatblade screwdriver to tighten two hidden cams. See “Tightening hidden cams” on page 7. Fasten the bottom (E) to the ends (A and B) and upright (C). Use a Phillips screwdriver and six black 1 7/8" flat head screws (P).
  • Page 13 DX-WD1239 Step 8: Fasten the swivel casters (K) and the non-swivel casters (L) to the bottom (E). Use a Phillips screwdriver and 16 black 9/16" large head screws (Q) (four screws per caster). The tabs on the non-swivel casters (K) must insert into these holes.
  • Page 14 DX-WD1239 Step 9: Carefully stand your TV cart upright. Push the rubber sleeves (N) on the metal pins (N), then insert the metal pins into the hole locations of your choice in the right end (A) and upright (C). Set the adjustable shelf (F) onto the metal pins (M).
