PEDICURE SPA USER MANUAL
Before Operating the unit, please read this manual thoroughly and retain it for future reference
RECEIVING AND INSPECTION:
PLEASE TAKE NOTE! Thoroughly inspect each shipment immediately upon arrival. It is
important that you notify the driver and insist on a notation of the damage. Make this
notation directly on the freight company's waybill or bill of lading. Failure to note damage on
the waybill or bill of lading may impede and/or prevent any claims that you may have
against the freight carrier.
If missing parts or damage is found. Please notify the carrier at once and request an
inspection. DO NOT DISCARD THE SHIPPING BOX. If you give the carrier a clear receipt
for goods that have been damaged in transit, you do so at your own risk and expense.
TRADEMARK DISCLAIMER
Vigor, Stellar, Ultima and Princess Seat are the registered trademarks of Lexor. Reproduction or reuse of part or all of trademarks are
expressly prohibited without written permission from Lexor. Due to limitation of the printing process, product colors shown might look
different from actual colors. Lexor will not be responsible for any misprint of this advertisement. Lexor's footspa specification and prices
may change without prior notice. Pedicure Spas are intended for professional used only, always follow your State Board's sanitation and
disinfectant guideline.
Pioneering "Smart" Pedi-Spas
ULTIMA
®
.
Advertisement
Table of Contents
Related Manuals for Lexor ULTIMA
Summary of Contents for Lexor ULTIMA
- Page 1 TRADEMARK DISCLAIMER Vigor, Stellar, Ultima and Princess Seat are the registered trademarks of Lexor. Reproduction or reuse of part or all of trademarks are expressly prohibited without written permission from Lexor. Due to limitation of the printing process, product colors shown might look different from actual colors.
-
Page 2: Table Of Contents
Table of Contents SAFETY PRECAUTIONS: ....................3 Parts Identifying Parts for Ultima® Model ................... 4 SPA to SPA RECOMMENDED CLEARANCE: ..............5 Wall Clearance: ......................... 5 MANICURE TRAY/ ARMREST / BACK REST INSTALLATION ........6 ... -
Page 3: Safety Precautions
If a crack in the GLASS BOWL occurs, DO NOT handle unless the proper attire and equipment is used. Discontinue use of the bowl until proper replacement is arranged. You may be held accountable for any injury that may occur. Lexor is not liable for any injury that may occur. -
Page 4: Identifying Parts For Ultima® Model
This equipment shall be installed between the water inlets and the spa at Salon’s cost. PLEASE SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE __________________________________________________Identifying Parts Identifying Parts for Ultima® Model (Pedicure Whirlpool with Massage System) 1. Head Rest 3. Armrest Cushion 6. -
Page 5: Spa To Spa Recommended Clearance
Discharge On/Off Knob 11. Flex Water Filler/Spray 15. Water Level Sensor 9. Jet On/Off Knob & Auto- Spout 16. Drain Stopper Fill™ 12. Up/Down Armrest 17. Pure-Flo™ Jet 10. Hot/Cold Water Mixer 13. Handbag (purse) Hook 18. Adjustable height Tech Valve 14. -
Page 6: Manicure Tray/ Armrest / Back Rest Installation
_____________________________________________________Installation MANICURE TRAY/ ARMREST / BACK REST INSTALLATION Up/Down Swinging Armrest: 1. Plug-In the manicure trays and attach the purse hook. (1 Supplied) Back Rest:... -
Page 7: Plumbing Connections
1. To set backrest up: Lift up the backrest until a “Click” is heard. Make sure the lever is locked before operating. 2. To fold down backrest: Lift up lever handle located on the left side / bottom of Chair. _______________________________________________________Installation Plumbing Connections: Warning... -
Page 8: Gravity Drain (No Drain Pump)
_______________________________________________________Installation Gravity Drain (No Drain Pump): Plumbing Flow Pattern for Power Drain:... -
Page 9: Plumbing Flow Pattern For Gravity Drain
_______________________________________________________Installation Plumbing Flow Pattern for Gravity Drain: HOT AND COLD WATER SUPPLY LINES Carefully connect ½” ID supply hoses (not provided) to fresh water sources. Shut-off valves (not provided) should be utilized. Valves should be placed outside the tub for easy access. Before water line connections, please follow below: Determine if your spa chair is used for a new construction of a salon or a replacement spa chair. - Page 10 Installation ______________________________________________________________ CONNECT DRAIN WITH POWER DRAIN (PUMP) OR GRAVITY DRAIN (NO PUMP) Using ¾” schedule 40 PVC (Power Drain) or 1 ¼” flex tube (Gravity Drain) and appropriate traps. Connect drain to meet local plumbing codes. Rubber connection to the drain should be removable for easy service and should not be permanent to prevent damages.
-
Page 11: Electrical And Pedicure Spa Component Specifications
Armrest swing up / down. SPECIFICATIONS Spa Dimensions & Vigor = 28” (W) x 56” (L). Stellar = 26” (W) x 54” (L). Ultima = 23” (W) x 55” (L) Weights All Models fully reclined: 74” (L). With Manicure Tray Installed: 46” (W) Empty Weight: ~ 200 lbs. -
Page 12: Operation And Care Instructions
Operation and Care _______________________________________________________ OPERATION AND CARE INSTRUCTIONS Auto-Fill™: Automatic Auto-Fill™ cycle: Water will automatically turn-off when optimal water level is detected by 2 sensors and followed with the immediate start of Whirlpool jets for a duty cycle of thirty (30) minutes. The Auto-Fill™ cycle is safely protected by 2 sensors, 3-minute time out and can be extended with a manually operative shut-off valve located at the front panel. - Page 13 ______________________________________________Operation and Care Auto-Fill™ / Jet Knob/Switch: (Dual-functional momentary switch located on the right side of the front panel) 1. To turn water on: Turn knob clockwise for 1 second and release. Water will fill up to reach the sensor level and activate the whirlpool jets to proceed a running duration of thirty (30) minutes automatically. 2.
-
Page 14: Jet Cover Removal & Installation
______________________________________________Operation and Care JET COVER REMOVAL & INSTALLATION: 1. Turn Counterclockwise to remove. Turn Clockwise to install. -
Page 15: Jet Housing Removal & Installation
______________________________________________Operation and Care JET HOUSING REMOVAL & INSTALLATION 1. Turn clockwise to remove motor. Turn counterclockwise to install motor. -
Page 16: Massage System & Remote Controller
______________________________________________Operation and Care MASSAGE SYSTEM & REMOTE CONTROLLER: 1. Press Auto Button to start Auto mode. Press again to turn off massage. Auto and Manual mode will run for duration of 15min. 2. Press any button (Rolling/Spot, Kneading, Tapping, Combine) to enter Manual mode. 3. - Page 17 _______________________________________________Operation and Care NOTE : If the Massage Chair is not provided, then the end-user will need to install a UL listed and cUL/CSA certified massage chair with a suitable Class 2 Power Supply. TOP MASSAGE CHAIR BASIC INSTALLATION INSTRUCTIONS: Fig.2 Fig.1 Install seat cushion with 2 screw-Knobs...
-
Page 18: Safety Requirements For Pedicure Spas
WARNING ou must always refer to your state or local guidelines for cleaning requirements Overnight soaking with overdosed Chlorine may damage rubber part in basin CLEANING PROCEDURE IS REQUIRED BY STATE BOARDS Note: *** A cleaning log should be kept with each pedicure spa *** Each State will have slight differences in cleaning policies, please check with your state’s Bureau of Barbering and Cosmetology or Regulatory Authority for specific details. - Page 19 FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY AND/OR WARRANTY WILL BE NULL. YOU MUST HAVE A QUALIFIED LICENSED PLUMBER TO CONNECT THE SPA IN PLACE SAFELY. UL SAFETY RECOGNIZED FOR UNITED STATES AND CANADA. LEXOR INC, 14800 GOLDENWEST STREET, WESTMINSTER CA 92683, USA CUSTOMER CARE: TEL 1-800-559-3630 FAX: 1-714-622-1740 www.Lexor.com...
