Rane HC 4 Operator's Manual

Headphone amplifier

Download this manual

OPERATORS MANUAL

Conect the output from any stereo source such as a mixer or tape deck, and plug the left and right inputs into the

respective INPUT jacks. The Inputs accept balanced or unbalanced sources. Just plug them in. This source is now routed to

each of the four Outputs.

For a single mono source feeding all headphones, connect it to either one of the INPUT jacks and engage the STEREO/

MONO switch. Set the CHANNEL LEVEL controls for individual headphone levels.

Never connect anything except a Rane power supply to the thing that looks like a telephone jack on the rear of the

unit. This is an AC input and requires special attention if you do not have a power supply exactly like the one originally

packed with your unit. See the full explanation of the power supply requirements elsewhere in this manual.

WEAR PARTS: This product contains no wear parts.

HEADPHONE AMPLIFIER

HC 4

Manual-1

Page 1: Headphone Amplifier
MONO switch. Set the CHANNEL LEVEL controls for individual headphone levels. Never connect anything except a Rane power supply to the thing that looks like a telephone jack on the rear of the unit. This is an AC input and requires special attention if you do not have a power supply exactly like the one originally packed with your unit.
Page 2 This is not a tele- does not ground the chassis through the line cord. The HC 4 can be grounded phone jack. Never use a power supply with your unit other than the one...
Page 3 Your basic, straightforward power switch. standard ¼" TRS stereo headphone set of headphones as they are driven When the yellow LED is lit, the HC 4 is ready plugs. from the INPUTS. It’s always a good idea to keep this control turned down to go.
Page 4 LOAD IN OHMS HC 4 power with all Channels driven simultaneously or with any combination ©Rane Corporation 10802 47th Ave. W., Mukilteo WA 98275-5098 TEL (425)355-6000 FAX (425)347-7757 WEB http://www.rane.com Manual-4 All features & specifications subject to change without notice. 105154...
