  • Page 1 User manual Built in double oven ZOU580...

  • Page 2: Table Of Contents

    Contents Safety information _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 2 What to do if… _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 22 Product description _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 3 Installation _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 23 Before first use _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 4...

  • Page 3: Product Description

    • Always stand back from the appliance when opening build-up of fat or other foodstuff could result in a fire the oven door to allow any build up of steam or heat especially in the grill pan. to release. • Do not leave cookware containing foodstuffs, e.g. •...

  • Page 4: Before First Use

    Control Panel Overview Top oven function knoob Oven grill shelf Top oven temperature knob Decrease button Mode button Increase button Main oven function knob Main oven temperature knob Display Oven accessories Anti stick meat/Drip pan 3 oven shelfs Before first use Rating plate Preparing to use your appliance This is situated on the front frame of the appliance and...

  • Page 5: Operation

    Do not use baking trays larger than 30cm x 35cm (12” Important! There is a hot surface label on the oven x 14”) as they will restrict the circulation of heat and door. Please remove the label from the door before first may affect performance.

  • Page 6: Oven Functions

    Warning! Do not place cookware and cooking The power indicator is lit as long as the oven is in pots with rough bases e.g. cast iron on the oven operation. door as damage to the glass may occur. The temperature pilot light is lit as long as the oven is heating up.

  • Page 7: Clock Functions

    Oven function Application Thermaflow® The fan function is particularly suitable for cooking larger quantities of food. Set the oven temperatures 20-40 °C lower than when using Conventional. Defrost For defrosting e. g. flans and gateaux, butter, bread, fruit or other frozen foods.

  • Page 8: Use, Tables And Tips

    When the time has elapsed, the function indicator 2. Using the End time function, set the time at flashes, an audible signal sounds for 2 minutes and which the dish should be ready. the oven switches itself off. The function indicators Cook time and End 3.
  • Page 9 How to use the Baking Tables • To prevent escaping meat juices or fat from burning on to the pan, we recommend placing some liquid • The tables give the required temperature settings, in the roasting cookware. cooking times and oven levels for a selection of typ- ical dishes.
  • Page 10 • Ensure that food is placed centrally on the shelf and • Do not place baking trays directly on the oven base there is sufficient room around the baking tray/dish as it interferes with the oven air circulation and can to allow for maximum circulation.
  • Page 11 Temperature Approx Cook Time Food Shelf Position [°C] (mins) - Victoria Sandwich 160 - 170 18 - 25 - Madeira 140 - 150 75 - 90 - Rich Fruit 140 - 150 120 - 150 - Gingerbread 140 - 150 75 - 90 - Meringues 90 - 100...
  • Page 12 Temperature Approx Cook Time Food Shelf Position [°C] (mins) Roasting Meat, Poultry See roasting chart. Top Oven - Grilling Adjust shelf position and grill pan grid to suit dif- ferent thicknesses of food Grill Time Food (mins in total) Bacon Rashers 5- 6 Beefburgers 10 - 20...
  • Page 13 Temperature Approx Cook Time Food [°C] (mins) Cakes: - Small & Queen 160 - 170 18 - 25 - Sponges 160 - 170 20 - 30 - Victoria Sandwich 160 - 170 18 - 25 - Madeira 140 - 150 75 - 90 - Rich Fruit 140 - 150...
  • Page 14 Temperature Approx Cook Time Food [°C] (mins) Yorkshire Pudding: - Large 180 - 190 25 - 40 - Individual 200 - 210 15 - 25 Roasting Meat, Poultry See roasting chart. Top Oven - Pizza Cooking Food Shelf Position Temperature Approx Cook Time [°C] (mins)
  • Page 15 Temperature Approx Cook Time Food [°C] (mins) - Puff Follow manufacturer´s instructions; Reduce the temperature for Fan oven by 20°C Plate Tarts 180 - 190 25 - 45 Quiches/Flans 170 - 180 25 - 45 Scones 210 - 230 8 - 12 Roasting: Meat and Poultry 160 - 180 see Roasting Chart...
  • Page 16 Grill Time Food (mins in total) - Pork 20 - 25 Fish - Whole 10 -12 Trout/ Makarel Fillets - Plaice/Cod 4 - 6 Kebabs 12 - 18 Kidneys - Lamb/Pig 6 - 10 Sausages 20 - 30 Steaks - Rare 4 - 6 - Medium 6 - 8...
  • Page 17 Type of meat Quantity Heating Function Level Temperature Time (h:min) (°C) Knuckle of pork (pre-cooked) 750 g - 1 Thermal Grilling 150 - 170 1:30 - 2:00 Veal Type of meat Quantity Heating Function Level Temperature Time (h:min) (°C) Roast veal 1 kg Thermal Grilling 160 - 180...

  • Page 18: Care And Cleaning

    Care and cleaning 3. Set the oven with max temp. of 275˚C for 30 min Warning! When cleaning, the appliance must be (use Conventional Cooking or Thermaflow® func- switched off and cooled down. tion). Warning! Cleaning the appliance with a steam 4.
  • Page 19 Replacing the side oven lamp/Cleaning the glass cover (for selected models only) Insert the rails in the Lower into position at the holes at the back front and press them at the back 1. Take out the left-hand side rails. Oven back lamp (for selected models only) 2.
  • Page 20 Removing the glass door panels 90° Hold the glass panels on their upper side and one Open the door as far as it after the other pull them will go. up and out of their retain- ers. Cleaning the glass door panels Thoroughly clean the glass door panels using a solution of water and washing-up liquid.
  • Page 21 On the open side of the door strip (B) there is a guide Fold the clamp levers on both door hinges (A) down bar (C). This must be pressed between the outer side into their original position. of the door and the corner (D). The seal (E) must Close the oven door.

  • Page 22: What To Do If

    Cleaning inside the grill and oven • Household detergents and bleaches. compartments • Soap Impregnated pads unsuitable for non-stick The vitreous enamel coating in the grill/top oven and saucepans. main oven compartments can be cleaned using normal • Abrasive cleaning pads, scorers and steel wool oven cleaners with care.

  • Page 23: Installation

    Problem Possible Solution Leave the grill door open and allow the grill to cool. After a couple of hours check that the grill works as normal The indicator neons are not working Check that you have selected only the function you require. Ensure all correctly.

  • Page 24: Electrical Installation

    2x 3,5x16 Drill with drilling machine at high revolution and Important! HOUSE CIRCUIT lowest torque. Earth leakage and continuity tests must be carried out before the appliance is connected to the mains supply Electrical Installation and re-checked after fitting. • Enquiries regarding the installation of the cooker GETTING THINGS READY CHOICE OF point, if required, should be made to your Regional ELECTRICAL CONNECTION...

  • Page 25: Disposal

    separation in all poles and neutral) and protected Cooker Point with a fuse or miniature circuit breaker at your mains fuse box. Oven b) By connecting the appliance together with a hob It is good practice to : directly to a cooker point(s). Having a double pole –...

  • Page 26: Great Britain & Ireland - Guarantee/Customer Service

    GREAT BRITAIN & IRELAND - Guarantee/Customer Service ed to Service Force Centre covering your postcode Standard guarantee conditions area). For address of local Service Force Centre and We, Electrolux, undertake that if within 12 months of further information, please visit: www.service- the date of the purchase this Electrolux appliance or force.co.uk Before calling out an engineer, please en- any part thereof is proved to be defective by reason...
  • Page 27 Belgique/België/Belgien +32 2 363 04 44 Bergensesteenweg 719, 1502 Lembeek Česká republika +420 261302111 Budějovická 3, Praha 4, 140 21 Danmark +45 70 11 74 00 Sjællandsgade 2, 7000 Fredericia Deutschland +49 180 32 26 622 Fürther Str. 246, 90429 Nürnberg Eesti +37 2 66 50 030 Pärnu mnt.
  • Page 28 Slovensko +421 (02) 32141334 Electrolux Slovakia s.r.o., Electro- lux Domáce spotrebiče SK, Seber- íniho 1, 821 03 Bratislava Suomi www.electrolux.fi Sverige +46 (0)771 76 76 76 Electrolux Service, S:t Göransga- tan 143, S-105 45 Stockholm Türkiye +90 21 22 93 10 25 Tarlabaşı...
