Raise and Lower Monitor Screen

The monitor may be raised or lowered. To raise or lower screen, place hands on each side of the monitor and lift or lower to
the desired height (Figure RL.1). Note: Handle with care when raising or lowering the monitor screen.
Tilt and Swivel
Grasp both sides of the monitor screen with your hands and adjust the tilt and swivel as desired (Figure TS.1).
Note: Handle with care when tilting the monitor screen.

Remove Monitor Stand for Mounting

To prepare the monitor for alternate mounting purposes:
1. Lay down the unit with caution and face down the screen of the unit on a flat material (Figure S.1).
2. Gently put the Height Adjustment up about 30 degrees (Figure S.2).
Figure S.1
3. Remove two pieces of plastic parts. Use your fingers to push them a little bit away from the stand (A). Then push them to
the top direction (B) (Figure S.3).
4. Unscrew the pair of "1" and "2" screws sequentially (Figure S.4).
Figure RL.1
Figure TS.1
Figure S.4
English-4
