swisherinc.com
OWNER'S
MANUAL
MODEL NO.
LS11534A
STARTING SERIAL #:
L206-010001
IMPORTANT
Read and follow all Safety
Precautions and Instructions
before operating this
equipment.
Rev. 06-010
1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093
Manufacturing quality lawn care equipment since 1945
11328
LOG
SPLITTER
Safety
Assembly
Operation
Service and Adjustment
Repair Parts
FAX 660-747-8650
PHONE 660-747-8183
Made In The
USA
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Swisher LS11534A
Summary of Contents for Swisher LS11534A
- Page 1 OWNER’S MANUAL MODEL NO. LS11534A STARTING SERIAL #: L206-010001 SPLITTER Safety IMPORTANT Assembly Read and follow all Safety Operation Precautions and Instructions before operating this Service and Adjustment equipment. Repair Parts Rev. 06-010 1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093...
- Page 2 Should you have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the splitter will be needed before any warranty claim can be processed.
-
Page 3: Safety Precautions
SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands, feet, and throw objects. Failure to observe the following safety instructions could result in serious injury or death. - Page 4 Fluid escaping from a very small hole can be almost invisible. Do not check for leaks with your hand. Escaping fluid under pressure can have sufficient force to penetrate skin, causing serious personal injury. Leaks can be located by passing a piece of cardboard or wood over the suspected leak and looking for discoloration.
- Page 5 TOWING SAFETY Do not allow persons to ride on splitter. Do not carry any cargo or wood on your • splitter. It may fall off and endanger vehicles that are following you. Be sure support leg is in the travel position and coupling secure. This must also •...
- Page 6 OPERATION Intended use: This log splitter is intended and designed to only split wood. NEVER use for any other purposes. Doing so can cause injury or VOID THE WARRANTY. ASSEMBLY INSTRUCTIONS This log splitter has been partially assembled at the factory. Refer to the drawings and part lists should it become necessary to disassemble the unit for repair or replacement of parts.
- Page 7 OPERATION TOWING This unit should not be towed on any street, highway, or public road without checking the existing federal, local, and state laws. Any licensing or modifications such as taillights, etc., need to comply with existing federal, local, or state vehicle requirements is the sole responsibility of the purchaser. Obey all regulations when towing on public roads and highways.
- Page 8 REPAIR PARTS Your Swisher Log Splitter has been produced with components designed specifically to this machine. Although standard springs, hardware, etc. may look similar to parts used on other machinery, they may in...
- Page 9 SAFETY DECALS Replace decals immediately if damaged. OD16 – FUEL SHUT OFF DECAL OD07 – COLD WEATHER DECAL OD12 – HYDRAULIC FILL PLUG DECAL OD08 – OPERATOR INSTRUCTION DECAL OD09 – DANGER/POSITION LOCK DECAL...
- Page 10 ASSEMBLY DETAIL LS11534A...
- Page 11 Nut 3/8-16 Serr Flange NB779 Bolt 5/16-18 X 3/4 Serr Flange NB596 Nut 5/16-18 Serr Flange NB170 18" Suction Hose 7346 #16 Hose Clamp LS4999 Hydraulic Pump-LS11534A LS2002B Pressure Line Fitting 11248 Motor Base 11207TK Support Leg 11220TK Support Leg Bracket 11213TK...
- Page 12 Bolt 3/8-16 X 1 1/4" Carriage 10501 Nut 3/8-16 Nyloc NB182 Nut 1/2-13 Nyloc Jam NB121 1/2-13 X 3 1/2 GR5 ZP NB577 Ram Cylinder - LS11534A Model 7355TK 2-W ay Pipe Nipple 7292 Steel Pin 7293 Clip Pin NB642...
- Page 13 ENGINE DETAIL LS11534A MODEL ITEM # DESCRIPTION PART # Engine Bolt 5/16-18 X 1 1/4 Serr. Flange NB253 Nut 5/16-18 Serr. Flange NB170 Upper Spacer 689S Engine Pulley BB105 Lower Spacer BB105S Washer TR150W Washer Belleville Bolt 7/16-20 X 1 GR 5 w/Loctite...
- Page 14 NOTES ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________...
-
Page 15: Specifications
SPECIFICATIONS Model LS11534A Splitting 34 Tons Force 11.5 HP Briggs Engine and Stratton I/C Splitting Horizontal and Vertical Positions Cylinder 5 1/2" X 24" Size 2 Stage with Heavy Pump Duty Bearings Pump 16 Gallons Per Minute Specs Valve Auto Return... - Page 16 The serial number for the engine will be found on the top of the blower fan housing. All Log Splitter parts listed herein may be ordered directly from Swisher Mower & Machine Co. Inc., your nearest MODEL NO. Swisher dealer, or from our website.
