OWNER'S
MANUAL
MODEL NO.
LS728C
LS10528C
IMPORTANT
Read and follow all Safety
Precautions and Instructions
before operating this
equipment.
Rev.
1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093
Manufacturing quality lawn care equipment since 1945
11815
LOG
SPLITTER
Safety
Assembly
Operation
Service and Adjustment
Repair Parts
FAX 660-747-8650
PHONE 660-747-8183
Made In The
USA
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Swisher LS728C, LS10528C
Summary of Contents for Swisher LS728C, LS10528C
- Page 1 swisherinc.com OWNER’S MANUAL MODEL NO. LS728C LS10528C IMPORTANT Read and follow all Safety Precautions and Instructions before operating this equipment. Rev. 1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093 Manufacturing quality lawn care equipment since 1945 11815 SPLITTER Safety Assembly Operation Service and Adjustment Repair Parts PHONE 660-747-8183 FAX 660-747-8650...
-
Page 2: Limited Warranty
Should you have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands, feet, and throw objects. Failure to observe the following safety instructions could result in serious injury or death. - Page 4 Fluid escaping from a very small hole can be almost invisible. Do not check for leaks with your hand. Escaping fluid under pressure can have sufficient force to penetrate skin, causing serious personal injury. Leaks can be located by passing a piece of cardboard or wood over the suspected leak and looking for discoloration.
-
Page 5: Towing Safety
Do not allow persons to ride on splitter. Do not carry any cargo or wood on your • splitter. It may fall off and endanger vehicles that are following you. Be sure jack stand is in the travel position and coupling secure. This must also be •... -
Page 6: Operation
Intended use: This log splitter is intended and designed to only split wood. NEVER use for any other purposes. Doing so can cause injury or VOID THE WARRANTY. ASSEMBLY INSTRUCTIONS This log splitter has been partially assembled at the factory. Refer to the drawings and part lists should it become necessary to disassemble the unit for repair or replacement of parts. - Page 7 OPERATION FILLING THE HYDRAULIC RESERVOIR Fill the hydraulic reservoir with at least five gallons of General Purpose Hydraulic fluid or Automatic Transmission fluid. After the hydraulic reservoir and the engine crankcase are filled correctly with their respective oils, start the engine. Remember to set the throttle and turn on the fuel shut-off valve.
- Page 8 OPERATION 1. Set up the log splitter in a clear, level area and block the wheels. The suction port on the tank should always be on the lower side of the log splitter. 2. Place a log on the beam, against the foot plate. Make sure the log is securely on the foot plate and up against the beam.
- Page 9 REPAIR PARTS Your Swisher Log Splitter has been produced with components designed specifically to this machine. Although standard springs, hardware, etc. may look similar to parts used on other...
-
Page 10: Safety Decals
Replace decals immediately if damaged. OD16 – FUEL SHUT OFF DECAL OD12 – HYDRAULIC FILL PLUG OD08 – OPERATOR INSTRUCTION OD09 – DANGER/POSITION LOCK SAFETY DECALS OD07 – COLD WEATHER DECAL DECAL DECAL DECAL... -
Page 11: Assembly Detail
LS728C, LS10528C MODELS NOT ALL PARTS ARE ON ALL MODELS FENDERS & FENDER BRACKETS SOLD ASSEMBLY DETAIL SEE DETAIL SEPERATELY SEE DETAIL... -
Page 12: Service Parts
Please have Model and Serial Numbers ready when ordering parts. Color cannot be guaranteed upon service parts. ITEM NUMBER 1/2 X 3 1/2 HITCH PIN W/ HAIR PIN HYDRAULIC PUMP - LS622,LS67525 MODEL HYDRAULIC PUMP - LS928,LS11534 MODELS FENDER BRACKET - RIGHT SIDE - LS11534 ONLY FENDER BRACKET - LEFT SIDE - LS11534 ONLY SERVICE PARTS DESCRIPTION... - Page 13 SERVICE PARTS Please have Model and Serial Numbers ready when ordering parts. Color cannot be guaranteed upon service parts. ITEM NUMBER WIRE LINK FOR IDLER SPRING #14 x 3/4 SELF-TAPPING SCREW DESCRIPTION MOTOR BASE / AXLE TIRE / WHEEL COTTER PIN WHEEL DUST COVER CASTLE NUT WASHER...
- Page 14 ITEM NUMBER STATIONARY LINE ASSEMBLY RAM CYLINDER - LS622 MODELS RAM CYLINDER - LS928&LS67525 MODEL RAM CYLINDER - LS11534&LS12534DMODEL 1/2-13 X 2 1/2 GR5 CARRIAGE BOLT 1/2-13 JAM 2-WAY LOCK NUT VALVE CONTROL W/ LEVER BEAM WELDMENT - LS12534D MODEL BEAM DETAIL ALL MODELS NOT ALL PARTS ARE ON ALL MODELS...
- Page 15 ENGINE DETAIL LS10528C MODELS ITEM # DESCRIPTION ENGINE 5/16-18 X 1 1/4 GR5 BOLT 5/16-18 2-WAY LOCK NUT UPPER SPACER ENGINE PULLEY LOWER SPACER BELLEVILLE WASHER 7/16-20 X 1 GR5 BOLT W/ NYLOCK KEYSTOCK WASHER NOTSHOWN WIRING HARNESS - LS12534D MODEL NOTSHOWN OIL DRAIN VALVE NOTSHOWN...
- Page 16 NOTES ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________...
- Page 17 NOTES ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________...
- Page 18 NOTES ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________...
-
Page 19: Specifications
Splitting Force 7 HP Briggs and Engine Splitting Positions Cylinder Size 2 Stage with Heavy Pump Pump Specs Valve Approx. 4.5 Gallon Capacity Maximum Log length Tire Specs with High Speed Metal Fenders Ball Hitch Unit Weight SPECIFICATIONS Models LS728C 28 Tons Stratton Intek Horizontal and... -
Page 20: Log Splitter
All Log Splitter parts listed herein may be ordered directly from Swisher Mower & Machine Co. Inc., your nearest Swisher dealer, or from our website. All engine parts may be ordered from the nearest dealer of the engine supplied with your log splitter without notice.
