Axis P5522/-E PTZ Datasheet

AXIS P5522/-E PTZ Dome Network Cameras
Affordable day/night PTZ domes with 18x zoom for broad application.
The indoor AXIS P5522 and outdoor AXIS P5522-E are easy-to-install pan/tilt/zoom dome
cameras suitable for surveillance applications in areas such as stores, offices, hotels, warehouses,
parking lots and construction sites.
AXIS P5522/-E cameras enable users at a remote
location to pan 360° for overview surveillance, tilt 180°
and zoom in 18x with autofocus for detailed views. The
Advanced Gatekeeper functionality enables the cameras
to automatically move to a preset position when motion
is detected in a pre-defined area.
High image quality is maintained even in low
light conditions, thanks to the cameras' day/night
functionality. Support for wide dynamic range enables
objects in both dark and light areas of a scene to be
visible.
The PTZ cameras provide H.264 and Motion JPEG streams
at full frame rate in all resolutions up to D1 (720x480 in
60 Hz, 720x576 in 50 Hz).
The indoor AXIS P5522 has an IP51 rating, which ensures
protection against dust and dripping water, enabling
the camera to operate even when the sprinkler system
is activated. The outdoor AXIS P5522-E has IP66- and
NEMA 4X-rated protection against dust, rain and
snow and can operate in temperatures from -20 °C to
50 °C (-4 °F to 122 °F). Easy installation features include
support for Power over Ethernet Plus (PoE+). A PoE+
midspan is supplied.
DATASHEET
> Superb video quality > 18x optical zoom
with autofocus including HDTV 1080p
> Multiple H.264 video > D1 resolution,
day/night, H.264 streams
> Remote focus and > IP-rated protection
zoom against dust and
water
> Outdoor ready
> Advanced Gatekeeper
> Digital PTZ and
> Easy installation multi-view streaming
including PoE+
(IEEE 802.3at)
> P-Iris control
Note: Mounting kits for hard and drop
ceilings are included with AXIS P5522.
Other mounts are sold separately.
