Axis P55 & Q60 HD network/IP PTZ cameras with Dotworkz D2 Outdoor Housing -
10 minute installation guide
Prepare the camera Remove shroud
Using the included Axis After unscrewing, remove
Torx screw driver unscrew P55 or Q60 series camera
all 8 bottom Torx screws (4 cover and open smaller cable
"outside" ones for the main latch. Set aside the main
cover plus 4 for smaller lower camera shroud as it is
cables latch cover). not going to be needed.
Mount the standoffs Secure camera
You will need to use the 1.5 Twist-lock camera into collar
while applying down pressure;
and the 0.75 inches stand-
line up the diamond mark as
offs on the 4 brass inserts
in this picture; Secure the
on top of the D2 enclosure -
camera plate to the standoffs
DO NOT over tighten or cross
using included 832 pan
thread the standoffs.
head screws.
IP68 Cable glands External power source
Have a qualified electri-
Run CAT5 cable through exist-
ing D2 cable gland; Remove
cian connect an external
the plug and install an included
power source to D2 terminal
second cable gland, making
power block. See manual for
sure to seal it tight. Note: if
more details.
using conduit be sure sealing
to avoid water moisture.
remote video solutions
Connect cables Reassemble latch cover
Attach the Dotworkz 5502-491 Securely close the cable
patch cable that will provide
latch using the Torx screw
camera power; attach the
driver again.
RG45 connector of a CAT5
Ethernet cable to the camera;
Feed both cables out their
respective slots.
Check camera fit Using Dotworkz cable
Check camera install by care- Remove the terminal block
fully closing the D2 camera
from Dotworkz 5502-491
hatch and verifying clearance
cable: you will only use
between camera and D2
BROWN and RED wires.
lens: should be enough space
between the clear dome and
the camera to move freely.
Tighten cable glands Close the D2
Make sure to have only one Close the enclosure and
cable per gland and tighten tighten all screws using
them really shut to com- a philips screw driver.
pletely seal D2 enclosure The D2 can be mounted
from the outside. directly to a wall or to a pole
mount adapter.
Install Axis collar
Attach the Axis P55 or Q60
series camera collar to the
Dotworkz universal camera
mounting plate, making sure
to line up correctly and tight-
ening lock washers securely.
Correct poles
Connect BROWN wire to
(-) negative and RED to (+)
positive on the MVP terminal.
The BLACK wire is not used
so we recommend isolating
it with electrical tape.
Leave a drip loop
Make sure to create a "U"
shape drip loop with the
cables to prevent water
from pooling and possibly
seeping inside.
