Summary of Contents for Rane MA3

  • Page 1 MULTICHANNEL AMPLIFIER...
  • Page 2: Important Safety Instructions

    • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. CAUTION: Changes or modifications not expressly approved by Rane Corporation could void the user's authority to operate the equipment. This Class B digital apparatus complies with Canadian ICES-003.
  • Page 3: Quick Start

    Driving the MA3 from a balanced source is recommended. • Twist the strands together. If you must drive the MA3 Input with an unbalanced source, we • Fully insert the wire into the Euroblock connector. recommend using a cable that has two conductors plus a shield, •...
  • Page 4: Front Panel Description

    0 dB remaining is indicated by a red indicator. When lit, any additional signal causes the Limiter to operate. It is possible to “com- press” the signal as much as 20 dB with very little effect on sound quality. This gives the MA3 the overload characteristics of a much larger amplifier, without the use of external compressors.
  • Page 5: Rear Panel Description

    Driving the MA3 from a balanced source is recommended. If you must drive the MA3 Input with an unbalanced source, use a cable that has two conductors plus a shield. Connect the (+) or “hot” source to the MA3 (+) Input, the ground to the MA3 (–) Input and connect the shield to the MA3 shield input.
  • Page 6 DISTRIBUTED DISTRIBUTED ZONE 2 ZONE 1 ZONE 3 The MA3 is shipped with the internal 80 Hz High- pass filters in the bypassed position. ©Rane Corporation 10802 47th Ave. W., Mukilteo WA 98275-5000 TEL 425-355-6000 FAX 425-347-7757 WEB rane.com Manual-4...
