1. Water container
When the tumble dryer is being used, condensation is
collected in a special container. To empty container,
please refer to 'Cleaning' chapter.
Important: If the water container fills up completely
during the drying cycle, the relevant light lights up
indicating that the container has to be emptied. The
drying time selector dial continues to turn towards the
"O" position, but the drying cycle is stopped, that
means that the laundry is not dried. After having
emptied the container, you have to select the drying
programme again for the time required to complete
drying.
Attention: After this operation, the dryer can stay still
for some minutes before starting the programme and
during this period the water container light remains
alight.
2. Programme chart
3. Door opening button
To open door, press this button. Should the door be
opened while appliance is working, the tumble dryer
will stop functioning. Press start button to resume
drying.
4. Low temperature button
(optional function)
Press this button in order to reduce the intensity of
heat produced while the tumble dryer is functioning
(1400 W). Press this button when drying delicate
cotton and linen items.
N.B. When drying programme has been completed,
press low temperature button once again to
desactivate function.

DESCRIPTION OF CONTROL PANEL

1 2
A U T O R E V E R S E
3 4 5
5. Start button
Select desired drying time and press start button: the
appliance will start drying.
ATTENTION! The door must be closed.
6. "Water container full" light
This light lights up when the water container is full or
when it has been inserted incorrectly.

7. Drying time selector dial

Select desired drying time by turning dial clockwise
(to the right).
ATTENTION! In order to avoid causing damage to
mechanism, do not turn the dial anti-clockwise.
There are two drying programmes to choose from:
Linen - Cotton - (2400 W), 20 - 120 minutes
Synthetics - (1400 W), 20 - 80 minutes
Drying times vary according to the particular type of
fabric, quantity of laundry and drying level (see
programme chart).
Cooling
Drying programmes end with an eight minute cooling
phase. This eight minute period is calculated as part of
the overall selected drying time. During the cooling
phase, the appliance's heating elements are switched
off and the laundry is cooled before the tumble dryer
stops automatically in position '0' (end of drying
cycle). Do not shorten or interrupt the cooling phase.
Leaving warm laundry inside the drum will cause
creasing and in some cases permanent damage.
8. Mains-on light
The mains-on light lights up during the drying cycle.
It switches off at the end of selected drying time.
T C S 6 7 3 T
6 7 8
