Intel
Desktop Board
D875PBZ
Specification Update
Release Date: August 2004
Order Number: C40099-010
®
The Intel
Desktop Board D875PBZ may contain design defects or errors known as errata, which
may cause the product to deviate from published specifications. Current characterized errata are
documented in this Specification Update.

Advertisement

Table of Contents
loading

Related Manuals for Intel D875PBZ

Summary of Contents for Intel D875PBZ

  • Page 1 Release Date: August 2004 Order Number: C40099-010 ® The Intel Desktop Board D875PBZ may contain design defects or errors known as errata, which may cause the product to deviate from published specifications. Current characterized errata are documented in this Specification Update.
  • Page 2 Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your product order. Copies of documents which have an ordering number and are referenced in this document, or other Intel literature, may be obtained from: Intel Corporation P.O.

  • Page 3: Table Of Contents

    CONTENTS REVISION HISTORY ........................... v PREFACE ..............................vi ® Specification Update for the Intel Desktop Board D875PBZ GENERAL INFORMATION .......................... 3 SPECIFICATION CHANGES ........................6 ERRATA ..............................11 SPECIFICATION CLARIFICATIONS ......................13 DOCUMENTATION CHANGES ......................... 18...

  • Page 5: Revision History

    ® Intel Desktop Board D875PBZ Specification Update REVISION HISTORY Date of Revision Version Description May 2003 -001 This document is the first Specification Update for the ® Intel Desktop Board D875PBZ. Added Specification Clarification 1. July 2003 -002 Added Errata 1, 2. Added Specification Clarification 2. Added Documentation Change 1.

  • Page 6: Preface

    82801ER I/O Controller Hub and that may apply to the desktop board D875PBZ. Unless otherwise noted in this document, it should be assumed that any ICH 5 errata for a given stepping are applicable to the Altered Assembly (AA) revision(s) associated with that stepping.

  • Page 7: Specification Update For The Intel Desktop Board D875Pbz

    Specification Update for the ® Intel Desktop Board D875PBZ...

  • Page 9: General Information

    ® Refer to the Intel 875P Chipset: 82875P Memory Controller Hub (MCH) Specification Update (Order Number 252526) for errata related to the 82875P MCH that may apply to the desktop board D875PBZ. ® Refer to the Intel 82801ER I/O Controller Hub 5 (ICH5) Specification Update (Order Number 252517) for errata related to...
  • Page 10 The following table indicates the Specification Changes, Errata, Specification Clarifications, or Documentation Changes that apply to the desktop board D875PBZ. Intel intends to fix some of the errata in a future revision of the desktop board, and to account for the other outstanding issues through documentation or specification changes as noted.
  • Page 11 ® Intel Desktop Board D875PBZ Specification Update PLANS DOCUMENTATION CHANGES Change to description of Section 1.4, Design Specifications Addition of Memory Configuration Setting to Section 4.3, BIOS Setup, Main Menu ® Removal of Intel branding from subtitle of Section 1.9.2...

  • Page 12: Specification Changes

    Intel Desktop Board D875PBZ Specification Update SPECIFICATION CHANGES The Specification Changes listed in this section apply to the Desktop Board D875PBZ Technical Product Specification (Order Number C31765). All Specification Changes will be incorporated into a future version of that specification.

  • Page 13: Thermal Considerations

    A processor fan heatsink that meets the thermal performance targets for Pentium 4 processors operating above 2.80 GHz The use of an Intel Pentium 4 processor with 1 MB of L2 cache on this Intel desktop board requires the following: •...
  • Page 14 Failure to ensure appropriate airflow may result in reduced performance of both the processor and/or voltage regulator or, in some instances, damage to the ® desktop board. For a list of chassis that have been tested with Intel desktop boards please refer to the following website: http://developer.intel.com/design/motherbd/cooling.htm...
  • Page 15 ® Intel Desktop Board D875PBZ Specification Update CAUTION Ensure that proper airflow is maintained in the processor voltage regulator circuit. Failure to do so may result in damage to the voltage regulator circuit. The processor voltage regulator area (item A in Figure 27) can reach a temperature of up to 85 °C in an open chassis.
  • Page 16 Desktop Board D875PBZ Specification Update Table 41 provides maximum case temperatures for components on the Desktop Board D875PBZ that are sensitive to thermal changes. The operating temperature, current load, or operating frequency could affect case temperatures. Maximum case temperatures are important when considering proper airflow to cool the Desktop Board D875PBZ.

  • Page 17: Errata

    ® Intel Desktop Board D875PBZ Specification Update ERRATA Audio Driver Creates a Popping Noise During Operating System Startup The audio jack-sensing feature requires reading the impedance of the device connected to the ROBLEM audio jack. A voltage is needed so a current can be measured, and the impedance is derived from the voltage and current.

  • Page 18: Standby Mode

    ® Intel Desktop Board D875PBZ Specification Update Some Systems May Hang if the Mouse is Moved When Entering Standby Mode Moving the mouse after placing the system into standby with the mouse may cause the system ROBLEM to immediately awaken and hang.

  • Page 19: Specification Clarifications

    Intel Desktop Board D875PBZ Specification Update SPECIFICATION CLARIFICATIONS The Specification Clarifications listed in this section apply to the Desktop Board D875PBZ Technical Product Specification (Order Number C31765). All Specification Clarifications will be incorporated into a future version of that specification.
  • Page 20 NOTE This document references back-panel slot numbering with respect to processor location on the Desktop Board D875PBZ. The AGP slot is not numbered. PCI slots are identified as PCI slot #x, starting with the slot closest to the processor. Figure 19 on page 66 illustrates the Desktop Board D875PBZ’s PCI slot numbering.
  • Page 21 ® Intel Desktop Board D875PBZ Specification Update 1.6.1 MEMORY FEATURES The Desktop Board D875PBZ has four DIMM sockets and supports the following memory features: • 2.6 V (only) 184-pin DDR SDRAM DIMMs with gold-plated contacts • Unbuffered, single-sided or double-sided DIMMs with the following restriction: Double-sided DIMMs with x16 organization are not supported.
  • Page 22 Connecting the processor fan to a chassis fan connector may result in onboard component damage that will halt fan operation. Table 40 lists the current capability of the fan connectors on the Desktop Board D875PBZ. Table 40.
  • Page 23 ® Intel Desktop Board D875PBZ Specification Update CAUTION Do not place jumpers on this block in any configuration other than the one described in Table 37. Other jumper configurations are not supported and could damage the Desktop Board. Table 37.

  • Page 24: Documentation Changes

    Intel Desktop Board D875PBZ Specification Update DOCUMENTATION CHANGES The Documentation Changes listed in this section apply to the Desktop Board D875PBZ Technical Product Specification (Order Number C31765). All Documentation Changes will be incorporated into a future version of that specification.
  • Page 25 ® Intel Desktop Board D875PBZ Specification Update Table 3. Specifications (continued) Reference Specification Version, Revision Date The information is Name Title and Ownership available from… ATX/ATX12V Power ATX12V Version 1.2, http://www.formfactors.org Supply Design August 2000, /developer/specs/atx/atxs Guide Intel Corporation. pecs.htm Boot Integrity Version 1.0,...
  • Page 26 ® Intel Desktop Board D875PBZ Specification Update Table 3. Specifications (continued) Reference Specification Version, Revision Date The information is Name Title and Ownership available from… OpenHCI – Open OHCI Release 1.0a, http://www.usb.org/develo Host Controller October 10, 1996, pers/docs.html Interface Compaq computer Corp.,...
  • Page 27 ® Intel Desktop Board D875PBZ Specification Update Table 3. Specifications (continued) Reference Specification Version, Revision Date The information is Name Title and Ownership available from… System SMBIOS Version 2.3.1, http://www.dmtf.org/downl Management BIOS March 16, 1999, oad/standards/DSP0119.p American Megatrends Incorporated, Award Software...

  • Page 28: Main Menu

    ® Intel Desktop Board D875PBZ Specification Update 4.3 Main Menu To access this menu, select Main on the menu bar at the top of the screen. Maintenance Main Advanced Security Power Boot Exit Table describes the Main menu. This menu reports processor and memory information and is for configuring the system date and system time.
  • Page 29 ® Intel Desktop Board D875PBZ Specification Update ® Removal of Intel Branding From Subtitle of Section 1.9.2 Section 1.9.2 Subtitle will change as follows: 1.9.2 FLEX 6 AUDIO SUBSYSTEM...
