Intel
Desktop Board
D850GB/ D850GBAL
Quick Reference
This guide is written for technically qualified personnel with experience
installing and configuring desktop boards.
Warning and Caution .......................................................................... 3
Safety and Regulatory Notice: ............................................................ 3
Desktop Board Connectors................................................................... 4
Supported Components......................................................................... 6
(D850GB only) .............................................................................. 7
2 Installing the I/O Shield................................................................. 9
3 Installing the Desktop Board ........................................................ 10
5 Installing the Processor................................................................. 13
6 Applying Thermal Grease to the Processor................................... 14
7 Installing the Processor Fan Heatsink........................................... 15
8 Installing the Fan Heatsink Clips .................................................. 16
9 Installing the Memory Modules.................................................... 17
10 Connecting the Fans ..................................................................... 18
11 Installing an AGP Card................................................................. 18
Jumpers .................................................................................................... 20
BIOS Setup Program Defaults ............................................................. 22
Items on the CD-ROM
x
Product warranty
x
®
Intel
Express Installer
x
®
Intel
Desktop Board D850GB/D850GBAL Product Guide
x
Software utilities and drivers
x
Software license agreement
x
Readme file
Part number: A30315-003

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D850GB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intel D850GB

Summary of Contents for Intel D850GB

  • Page 1: Table Of Contents

    Setting the BIOS Configuration and USB Port 2 Routing Jumpers ....................20 BIOS Setup Program Defaults ............. 22 Items on the CD-ROM Product warranty ® Intel Express Installer ® Intel Desktop Board D850GB/D850GBAL Product Guide Software utilities and drivers Software license agreement Readme file Part number: A30315-003...
  • Page 2 Intel assumes no responsibility for any errors that may appear in this document. Intel makes no commitment to update nor to keep current the information contained in this document. No part of this document may be copied or reproduced in any form or by any means without prior written consent of Intel.

  • Page 3: Before You Begin

    Safety and Regulatory Notice: ® See the Intel Desktop Board D850GB/D850GBAL Product Guide for all applicable regulatory compliance statements, product certification markings, and safety and electromagnetic compatibility (EMC) standards and regulations these desktop boards are compliant with..

  • Page 4: Desktop Board Connectors

    Desktop Board Connectors Line Devices J8C3 2-pin alternate power LED/Sleep Power LED connector HD LED Reset Connection IRRX Ground Ground IRTX IR Module J9D2 OM11532 continued Intel Desktop Board D50GB/D850GBAL Quick Reference...
  • Page 5 Do not use these connectors for powering devices external to the computer chassis. A fault in the load presented by the external devices could cause damage to the computer, the interconnecting cables, and the external devices themselves. Intel Desktop Board D850GB/D850GBAL Quick Reference...

  • Page 6: Supported Components

    CAUTION Failure to use an ATX12V power supply, or not connecting both additional power supply leads to the D850GB or D850GBAL board may result in damage to the desktop board. For more information on the ATX12V power supply, refer to the Intel Desktop Board D850GB/D850GBAL Product Guide on the CD-ROM.

  • Page 7: Installation Steps

    AGP card with a retention notch (A) as shown in the figure below. Use of the RM with an unnotched card may impair video operation. See the Intel Desktop Board D850GB/D850GBAL Product Guide on the CD-ROM for RM removal instructions.
  • Page 8 Push the free end of the RM over the other end of the AGP connector and press down evenly on both ends of the RM until all four tabs click underneath the AGP connector. Do not apply unnecessary pressure to avoid damaging the board. OM10181 Intel Desktop Board D50GB/D850GBAL Quick Reference...

  • Page 9: Installing The I/O Shield

    Press the shield into place so that it fits tightly and securely. If the shield doesn’t fit, obtain a properly- sized shield from the chassis supplier. OM11542 D850GB I/O Shield OM11543 D850GBAL I/O Shield Intel Desktop Board D850GB/D850GBAL Quick Reference...

  • Page 10: Installing The Desktop Board

    CAUTION Failure to use an ATX12V power supply, or not connecting both additional power supply leads to the D850GB or D850GBAL board may result in damage to the desktop board. For more information on the ATX12V power supply, refer to the Intel Desktop Board D850GB/D850GBAL Product Guide on the CD-ROM.

  • Page 11: Installing The Processor Retention Mechanisms

    4 Installing the Processor Retention Mechanisms The processor retention mechanisms are secured to the board with four screws supplied by the chassis manufacturer. See the location of the processor RM holes in the following figure. OM11538 Intel Desktop Board D850GB/D850GBAL Quick Reference...
  • Page 12 Place the retention mechanisms on the board by aligning the holes in the RM with the holes in the board. Using the screws provided by the chassis manufacturer, install the retention mechanisms into the four holes on the chassis. OM11539 Intel Desktop Board D50GB/D850GBAL Quick Reference...

  • Page 13: Installing The Processor

    Lift the processor socket lever, install the processor so that the first pin (A) is aligned with the first pin location on the board silk screen, and lower the lever back to its original position. OM10633 Intel Desktop Board D850GB/D850GBAL Quick Reference...

  • Page 14: Applying Thermal Grease To The Processor

    6 Applying Thermal Grease to the Processor The processor package includes a thermal grease syringe. Apply about half of the thermal grease from the syringe to the center of the processor surface. OM10642 Intel Desktop Board D50GB/D850GBAL Quick Reference...

  • Page 15: Installing The Processor Fan Heatsink

    7 Installing the Processor Fan Heatsink Place the fan heatsink on the processor so that the fan cable is facing the right edge of the board. OM10634 Intel Desktop Board D850GB/D850GBAL Quick Reference...

  • Page 16: Installing The Fan Heatsink Clips

    RM. Then fasten the side clip (A) to the RM until you hear a click. Repeat this procedure on the opposite side of the fan heatsink. See step 12 on page 18 to connect the processor fan cable header to the board processor fan connector. OM10643 Intel Desktop Board D50GB/D850GBAL Quick Reference...

  • Page 17: Installing The Memory Modules

    0 in size and density. For example, if bank 0 has two 128 MB RIMMs of PC800 RDRAM, bank 1 would require PC800 RDRAM also, however, any other supported RIMM modules such as 64 MB or 192 MB could be used. OM11541 Intel Desktop Board D850GB/D850GBAL Quick Reference...

  • Page 18: Connecting The Fans

    Place the AGP card in the AGP connector. Press down on the card until it is completely seated in the connector and the card retention notch snaps into place below the RM (D850GB only). Secure the card’s metal bracket to the chassis back panel with a screw.

  • Page 19: Attaching Ide Hard Drives With The Ultra Ata-66/100 Cable

    The cable will work correctly only when oriented as shown in the figure below. For correct cable function: Attach the cable end with the single connector (A) to the board. Attach the cable end with the two closely spaced connectors (B) to the drives. OM11544 Intel Desktop Board D850GB/D850GBAL Quick Reference...

  • Page 20: Setting The Bios Configuration And Usb Port 2 Routing

    CAUTION Always turn off the power and unplug the power cord from the computer before changing the jumper. Moving the jumper with the power on may result in unreliable computer operation. J8C2 J8D1 OM11545 Intel Desktop Board D50GB/D850GBAL Quick Reference...

  • Page 21: Jumpers

    Recovery The BIOS recovers data from a recovery diskette in the event of a failed BIOS update. To update or recover the BIOS, see the instructions in the Intel Desktop Board D850GB/D850GBAL Product Guide on the CD-ROM. The USB port 2 routing jumper routes the signals of USB port 2. The table below describes the jumper settings for the front panel USB connector and CNR connector (D850GB only).

  • Page 22: Bios Setup Program Defaults

    BIOS Setup Program Defaults The following table is a partial list of the default BIOS Setup settings. For a complete list, see the Intel Desktop Board D850GB/D850GBAL Product Guide on the CD-ROM. Maintenance Menu * Default Clear All Passwords No options...
  • Page 23 * To access the Maintenance Menu, set the configuration jumper on the desktop board to configure mode (see page 21). ** Refer to the Intel Desktop Board D850GB/D850GBAL Product Guide on the CD-ROM for details on the defaults and options within this submenu.
  • Page 24 Intel Desktop Board D50GB/D850GBAL Quick Reference...
  • Page 25 ® Intel D850GB/D850GBAL ..................3 ................3 .................. 4 ..................6 D850GB ......7 ................9 ................10 ..............11 .................. 13 ..............14 .............. 15 ..............16 ................17 ..................18 ................18 Ultra ATA-66/100 ...... 19 BIOS ........... 20 BIOS ..............
  • Page 26 Intel http://support.intel.com/support/motherboards/desktop ® Intel Desktop Board D850GB Technical Product Specification Intel D850GB ® Intel Desktop Board D850GB Specification Update Intel D850GB Intel Intel Intel (Intel) Intel Intel Intel ® Intel 2000 (Year 2000 Capable) † ¤ Copyright 2000, 2001, Intel Corporation.
  • Page 27 (ESD) ® (EMC) Intel D850GB/D850GBAL (I.T.E.) D850GB/D850GBAL Ã 3 Ã Intel Ã...
  • Page 28 Line Devices J8C3 2-pin alternate power LED/Sleep Power LED connector HD LED Reset Connection IRRX Ground Ground IRTX IR Module J9D2 OM11532 à 4 à D850GB/D850GBAL à Intel à Ã...
  • Page 29 ® Intel 82850 (MCH) G 12 V V BIOS † W Wake on LAN X SCSI K. RIMM ® L. RIMM Z Intel 82801BA I/O (ICH2) AA PCI (CNR) D850GB +5 V +12 V D850GB/D850GBAL Ã 5 Ã Intel Ã...
  • Page 30 D850GB/D850GBAL Intel http://support.intel.com/support/motherboards/desktop ATX12V D850GB D850GBAL ® ATX12V CD-ROM Intel à D850GB/D850GBAL 2.5 V Direct Rambus DRAM (RDRAM) RIMM Direct Rambus 128 MB 2 GB PC600 PC800 RDRAM RIMM (SPD) Intel D850GB http://support.intel.com/support/motherboards/desktop 6 à D850GB/D850GBAL à Intel à Ã...
  • Page 31 D850GB (RM) (RM) CD-ROM Intel D850GB/D850GBAL OM10592 D850GB/D850GBAL Ã 7 Ã Intel Ã...
  • Page 32 RM (A) (J5E1) OM11536 OM10111 OM10180 OM10181 8 à D850GB/D850GBAL à Intel à Ã...
  • Page 33 (EMI) OM11542 D850GB I/O OM11543 D850GBAL I/O D850GB/D850GBAL Ã 9 Ã Intel Ã...
  • Page 34 ATX12V D850GB D850GBAL ATX12V CD-ROM Intel D850GB/D850GBAL Intel Pentium 4 OM11537 10 à D850GB/D850GBAL à Intel à Ã...
  • Page 35 OM11538 D850GB/D850GBAL Ã 11 Ã Intel Ã...
  • Page 36 OM11539 12 à D850GB/D850GBAL à Intel à Ã...
  • Page 37 OM10633 D850GB/D850GBAL Ã 13 Ã Intel Ã...
  • Page 38 OM10642 14 à D850GB/D850GBAL à Intel à Ã...
  • Page 39 OM10634 D850GB/D850GBAL Ã 15 Ã Intel Ã...
  • Page 40 OM10643 16 à D850GB/D850GBAL à Intel à Ã...
  • Page 41 RIMM (CRIMM) RIMM RIMM RIMM RIMM CRIMM RIMM RIMM RIMM RIMM PC800 RDRAM 128 MB RIMM PC800 RDRAM RIMM 64 MB 192 MB OM11541 D850GB/D850GBAL Ã 17 Ã Intel Ã...

  • Page 42: Agp D850Gb

    J6L1 J3M1 J7M2 J10A2 Fan 4 J3M1 Fan 3 J6L1 Fan 2 J7M2 Fan 1 J10A2 OM111533 D850GB/D850GBAL 1.5 V AGP D850GB 18 à D850GB/D850GBAL à Intel à Ã...

  • Page 43: Ultra Ata-66/100 Ide

    Ultra ATA-66/100 ® Intel Ultra ATA-66/100 OM11544 D850GB/D850GBAL Ã 19 Ã Intel Ã...

  • Page 44: Bios Usb

    BIOS J8C2 J8D1 OM11545 20 à D850GB/D850GBAL à Intel à Ã...
  • Page 45 BIOS BIOS BIOS BIOS BIOS BIOS (J8C2) BIOS (POST) BIOS Maintenance BIOS BIOS BIOS CD-ROM Intel D850GB/D850GBAL D850GB (J8D1) D850GB/D850GBAL Ã 21 Ã Intel Ã...

  • Page 46: Bios

    Extended Configuration PCI Configuration PCI Boot Configuration Peripheral Configuration IDE Configuration IDE Diskette Configuration Event Log Configuration Video Configuration Security Supervisor Password is User Password is Set Supervisor Password Set User Password à 22 à D850GB/D850GBAL à Intel à Ã...

  • Page 47: Cd-Rom

    On Modem Ring Stay Off On LAN LAN Power On On PME PME Stay Off On ACPI S5 ACPI S5 Stay Off Ãà Boot Device Boot Device Boot Device à Boot Device Maintenance CD-ROM Intel D850GB/D850GBAL D850GB/D850GBAL à 23 à Intel Ã...
  • Page 48 à 24 à D850GB/D850GBAL à Intel à Ã...
