Summary of Contents for Allied Telesis AT-4016F/ST
- Page 1 CentreCOM AT-4016F/ST AT-4016F/SC Ethernet Switch with ATM Access Installation Manual...
- Page 2 Copyright 1996 Allied Telesyn International Corporation All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesyn International Corporation. Allied Telesyn International Corporation reserves the right to make changes in specifications and other information contained in this document without prior written notice.
-
Page 3: Electrical Safety And Installation Requirements
Electrical Safety and Installation Requirements RADIATED ENERGY U.S. Federal Communications Commission Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 4 Das ist ein “ LED Produkt der Klasse 1 .” GEFAHR DURCH BLITZSCHLAG GEFAHR : Keine Arbeiten am Gerät oder an den Kabeln während eines Gewitters ausführen. VORSICHT : DAS NETZKABEL DIENT ZUM TRENNEN DER STROMVERSORGUNG. ZUR TRENNUNG VOM NETZ, KABEL AUS DER STECKDOSE ZIEHEN.
- Page 5 RFI Emissie EN55022 Klasse A WAARSCHUWING : Binnenshuis kan dit product radiostoring veroorzaken, in welk geval de gebruiker verplicht kan worden om gepaste maatregelen te nemen. Immuniteit EN50082-1 Electrische Veiligheid EN60950, UL1950, CSA 950 VEILIGHEID WAARSCHUWINGEN MET BETREKKING TOT ELEKTRICITEIT WAARSCHUWING : GEVAAR VOOR ELEKTRISCHE SCHOKKEN Gelieve het deksel niet te verwijderen, teneinde ELEKTRISCHE schokken te voorkomen.
- Page 6 INSTALLATION ELECTRICITE—REGLAGE DE TENSION AUTOMATIQUE Ce produit peut s’ajuster automatiquement sur n’importe quelle tension comprise dans la plage indiquée sur le label. ELECTRICITE—EQUIPEMENT DE CLASSE 1 CET APPAREIL DOIT ETRE MIS A LA TERRE. La prise de courant doit être branchée dans une prise femelle correctement mise à la terre.
- Page 7 Emissione RFI (interferenza di radiofrequenza) EN55022 Classe AVVERTENZA: in ambiente domestico questo prodotto potrebbe causare radio interferenza. In questo caso potrebbe richiedersi all'utente di prendere gli adeguati provvedimenti. Immunità EN50082-1 Sicurezza elettrica EN60950, UL1950, CSA 950 NORME DI SICUREZZA AVVERTENZE ELETTRICHE ATTENZIONE: PERICOLO DI SCOSSE ELETTRICHE Per evitare SCOSSE ELETTRICHE non asportare il coperchio.
- Page 8 ELEKTRISKE—TYPE 1. KLASSE UTSTYR DETTE UTSTYRET MÅ JORDES. Strømkontakten må være tilkoplet en korrekt jordet grunnstøpselkontakt. En støpselkontakt som ikke er jordet på rett måte, kan tilføre farlig spenning til lett tilgjengelige metalldeler. ELEKTRISKE—MEDDELELSE OM LEDNINGER Bruk en strømledning av maksimal størrelse 4,5 m i lengde, vurdert for minst av 6 amp, 250V, fremstilt av HAR ledning IEC 320 koplingsstykke på...
- Page 9 Emisión RFI EN55022 Clase A ADVERTENCIA: en un entorno doméstico, este producto puede causar radiointerferencias, en cuyo caso, puede requerirse del usuario que tome las medidas que sean convenientes al respecto. Inmunidad EN50082-1 Seguridad eléctrica EN60950, UL1950, CSA 950 SEGURIDAD AVISOS ELECTRICOS ADVERTENCIA: PELIGRO DE ELECTROCHOQUE Para evitar un ELECTROCHOQUE, no quite la tapa.
- Page 10 ELEKTRISKT—TYP KLASS 1 UTRUSTNING DENNA UTRUSTNING MÅSTE VARA JORDAD. Nätkabeln måste vara ansluten till ett ordentligt jordat uttag. Ett felaktigt uttag kan göra att närliggande metalldelar utsätts för högspänning. Apparaten skall anslutas till jordat uttag, när den ansluts till ett nätverk.
-
Page 11: Table Of Contents
AT-4016F/ST......... - Page 12 Table of Contents Chapter 2 Installation Site Preparation ................15 Location .
-
Page 13: About This Manual
The contents of each chapter are described below. Chapter 1, “Overview” describes both the AT-4016F/SC and AT-4016F/ST hardware platforms. These platforms are identical in that they combine 10 Mbps of dedicated Ethernet-to-Ethernet bandwidth on each of sixteen (16) FOIRL, 10BASE-FL, Fiber Optic ports with a 155 Mbps Asynchronous Transfer Mode (ATM) Fiber Optic port for Ethernet-to-ATM connectivity. -
Page 14: Document Conventions
About This Manual Document Conventions The following conventions are used in this manual: Commands, prompts, and information displayed by the computer appear in Courier typeface, for example: Current Number of Learned Addresses: 133 Number of Defined Filters: 4 Information that you enter appears in Courier bold typeface, for example: AT-4016F >status Information that you need to enter with a command is enclosed in angle brackets <... -
Page 15: Contacting Ati Technical Support
AT-4016F Installation Manual Internet drafts are available by anonymous FTP. Internet draft directories are located at: — US East Coast: ds.internic.net — US West Coast: ftp.isi.edu — Europe: nic.nordu.net — Pacific Rim: nunnari.oz.au ATM documentation is also available through Phillips Publishing International: (301) 424-3700 or (703) 281-1135 Contacting ATI Technical Support Problems? You can contact ATI’s Technical Support staff by:... -
Page 16: Bulletin Board Services
About This Manual Bulletin Board A bulletin board is available. The number is: Services (206) 483-7979 Modem settings for the bulletin board is: 9600 baud; 8 bits; no parity; 1 stop bit. The process is straightforward: Once the BBS is accessed, it requests that you register either as a new user or as a current user. -
Page 17: Overview
AT-4016F Ethernet Switch with ATM Access This manual describes both the AT-4016F/SC and the AT-4016F/ST hardware platforms. While these platforms are identical in form and function they differ only by the type of Ethernet-to-Ethernet front panel connector. -
Page 18: Features
Overview Features The following features are fully implemented “Hot swappable,” dual-redundant, load-sharing, modular power supplies 16 Fiber Optic — either SC or ST connectors — ports ATM media interface, configurable by means of removable media cards in several different media types RS232C ASYNC ASCII terminal port for local network management Recessed reset switch... -
Page 19: Ati's Solution
AT-4016F Installation Manual ATI’s Solution In the past, a legacy Ethernet-to-Ethernet switch partially resolved fundamental bandwidth congestion problems by assigning each node to a unique segment. That was yesterday. Unfortunately, legacy Ethernet-to-Ethernet switching is not a total solution to bandwidth congestion when it originates from the backbone or if you (and others at the same time) access a server or data base which is outside your local network. - Page 20 Overview Figure 3 shows the front panel of an AT-4016F/ST. Figure 3: AT-4016F/ST Front Panel Figure 4 shows the Ethernet-to-ATM modular media interface which is located on the back panel. Both the AT-4016F/SC and the AT-4016/ST have identical back panels.
- Page 21 AT-4016F Installation Manual Figure 5 shows a close-up of the ATM Media Module faceplate using an SC connector. Figure 5: ATM Faceplate Without a media module installed, or installed but not used, the AT-4016F operates as a standalone Ethernet switch. When ordered factory-installed, the media module version is indicated by the third digit in the model name suffix.
-
Page 22: Mib Support
Overview MIB Support The following Management Information Base (MIB) protocols are supported by ATI’s AT-4016F Omega Management Software. SNMP MIB2 (RFC 1213) Ethernet MIB (RFC 1643) Partial Bridge MIB (RFC 1493) ATM Forum ILMI MIB Ethernet-to-Ethernet Switch Your AT-4016F combines Ethernet-to-Ethernet device switching with Ethernet-to-ATM backbone/server connectivity. -
Page 23: Selector Byte
AT-4016F Installation Manual Selector Byte The selector byte is used to denote specific ELAN membership. [network prefix] [MAC address] [selector byte] Selector bytes consist of integers ranging from 00 to 64 and includes a “Super LEC.” For example, a complete ATM port address will resemble of the following: [network prefix] [MAC address] [00] —... -
Page 24: Two Modes Of Ethernet Switching
Overview Each ATM MAC address is created by adding the port number to the basic AT-4016F MAC address. Since the AT-4016F has 16 ports there are 16 MAC addresses: Port #1 - [basic MAC address + 01] Port #2 - [basic MAC address + 02] Port #16 - [basic MAC address +16] Two Modes of Ethernet Switching There are two popular methods to forward information: cut-through and... -
Page 25: Bridging
AT-4016F Installation Manual Bridging Your AT-4016F acts as a transparent bridge to the Ethernet ports and the ATM interface. As such, it learns the source MAC address of all incoming packets and ages out devices which have not been heard for a period of time. -
Page 26: At-4016F User Topology
Overview Each entry which is automatically entered (a dynamic entry) includes: An Ethernet MAC address The port number of the LAN on which the address resides The age of the entry ELAN/VLAN membership Each entry which is manually entered (a static entry) contains the same information as a dynamic entry, except that a static entry is not aged. -
Page 27: At-4016F/St
AT-4016F Installation Manual AT-4016F/ST The AT-4016F/ST has Straight Tip (ST) connectors which mate through a two-pin, bayonet-style interface. ST connectors are popular simply because they have less attenuation and less vulnerability to human error than previous fiber optic connectors such as a Sub Miniature Assembly (SMA). -
Page 28: At-4016F/Sc
Overview AT-4016F/SC The AT-4016F/SC has Subscriber Channel (SC) connectors which mate through a square push-pull interface. SC connectors represent, for many individuals, an improvement over ST connectors in that they have a lock proof mechanism. Figure 10 shows the front panel of an AT-4016F/SC. Figure 10: AT-4016F/SC Front Panel Figure 11 shows an SC connector matrix with the locking device removed... -
Page 29: Foirl, 10Base-Fl Wiring Specifications
AT-4016F Installation Manual Figure 12 shows an SC connector group with the locking device installed. Figure 12: AT-4016F/SC Connector With Lock FOIRL, 10Base-FL Wiring Specifications The IEEE FOIRL standard limits a fiber segment length to 1 km (1,000 meters or 3,280 feet). That is, the fiber optic cable that connects two repeaters is limited to 1 km (3,280 ft.). -
Page 30: Configuration Rules
Overview Configuration Depending on the medium you choose, there are certain wiring practices you must follow to ensure the reliability of communication throughout the Rules network. The AT-4016F complies with IEEE standards for 802.3 Carrier- Sense Multiple-Access with Collision Detection (CSMA/CD) Ethernet and with ATM Forum UNI Specification 3.0;... -
Page 31: Site Preparation
Chapter 2 Installation Site Preparation Note Before installing the AT-4016F Ethernet Switch with ATM Access, read the “Electrical Safety and Installation Requirements” on page i. Location The AT-4016F can be installed on a shelf, in a desktop chassis, or in a 19-inch rack which ATI has designated Model AT-31C1. -
Page 32: Installing The At-4016F Atm Ethernet Switch
Installation Installing the AT-4016F ATM Ethernet Switch The following procedure details how to install an AT-4016F in a standalone configuration. Installing the switch 1. Plug one end of the power cord into the switch’s power receptacle and the other end into a power outlet. 2. -
Page 33: Installing The Redundant Power Supplies
AT-4016F Installation Manual Installing the Redundant Power Supplies The AT-4016F has a redundant, dual power-supply. See Table 3 in Chapter 1 for the list of AT-4016F models. Power supply modules are keyed so that they will only fit in the appropriate switch housing. The following procedure details how to replace an AT-4016F power supply. -
Page 34: Media Module Installation
Installation Media Module Installation ATM Physical Media Modules are available in several versions for differing network requirements. Installing ATM Media Modules ATM Media Modules plug into the Media Channel connector located on the AT-4016F back panel. Attention You must disconnect the AT-4016F from its power source to install or swap ATM Media Modules. -
Page 35: Connectivity
Chapter 3 Connectivity This chapter describes network hardware functions. The first two sections cover the layout of the front and back panels. The rest of the chapter covers the functionality of the different components: connectors, indicators and switches. Front Panel An AT-4016F/SC front panel is shown in Figure 15. -
Page 36: Back Panel
Connectivity The front panel includes the following components: 16 Fiber Optic — either SC or ST — station ports RS232 Terminal Port PCMCIA Flash Memory slot Recessed Reset Switch Diagnostic LEDs: — Network Loading indicators — ATM Port indicators — Individual Fiber Optic Port Interface indicators —... -
Page 37: At-4016F Ports
AT-4016F Installation Manual AT-4016F Ports Station Ports There are 16 Fiber Optic station ports which can be used to connect to workstations, servers or hubs. RS232 The AT-4016F includes an RS232 Terminal Port on the front panel. The principal use for this port is the connection of a local network Terminal Port management terminal to access ATI’s Omega agent. -
Page 38: Led Displays
Connectivity LED Displays The AT-4016F has four types of LEDs: System Status indicators show the overall condition of the switch Power Supply Indicators Port indicators shows information about each Fiber Optic port connection. ATM Interface indicators show status and alarm information about the ATM Physical Interface System Status Network Load (Green)—Indicates approximately how much of the... -
Page 39: Power Supply Leds
AT-4016F Installation Manual Power Supply Figure 19 shows the Power Supply LEDs. LEDs Figure 19: Power Supply LEDs PS Present 1 (Green)—Indicates Power Supply #1 is installed. PS Present 2 (Green)—Indicates Power Supply #2 is installed. PS Fail 1 (Amber)—Indicates Power Supply #1 has failed. This means that there is either an inadequate, or nonexistent, amount of AC voltage. -
Page 40: Fiber Optic Port Leds
Connectivity Fiber Optic Port The port indicators on the AT-4016F front panel provide visual diagnostic and activity information for network analysis. Each Fiber Optic port LEDs supports the following indicator functions with three front panel LEDs per port, arranged in a central bank as shown in Figure 20. Figure 20: Port Indicators LINK (Solid Green)—This indicates that the particular port has a valid link and is not partitioned. -
Page 41: Atm Interface Leds
AT-4016F Installation Manual ATM Interface LEDs The AT-4016F supports an additional set of indicators that convey diagnostic and status information about the ATM Physical Interface. The location of these indicators is shown in Figure 21. Figure 21: ATM Interface LEDs ATM Port LEDs ONLINE (Solid Green)—Indicates that the ATM Physical Interface is active (enabled). -
Page 42: Atm Media Module Leds
Connectivity ATM Media A further set of indicators appears on the ATM Media Module. Located on the back panel of the AT-4016F, these LEDs convey diagnostic and status Module LEDs information specific to the type of media connection that has been installed. -
Page 43: Reset Switch
AT-4016F Installation Manual Reset Switch Located at the far left of the front panel (as shown in Figure 23), this switch is recessed to avoid inadvertent activation. To press the switch, insert the tip of a pen or similar object into the access hole. Figure 23: Reset Switch The Reset switch initiates the same diagnostic self-testing cycle which takes place when you initially apply power to the system. -
Page 45: Troubleshooting
Chapter 4 Troubleshooting Troubleshooting the Installation This section provides a checklist for resolving problems associated with your AT-4016F and cabling. The first rule of troubleshooting is to isolate the problem. As you experiment, only vary one factor at a time. Substitute known good equipment and see if the problem persists or is eliminated. -
Page 47: Glossary
Appendix A Glossary 10BASE-T—IEEE 802.3 UTP Ethernet. Low-cost Level 3 or better UTP wiring affords 100 meters (328 ft.) of point-to-point link segments. UTP uses RJ-45 connectors and sometimes 50-pin AMP connectors to a patch panel and runs at 10 MHz. ADDRESS RESOLUTION PROTOCOL (ARP)—The procedures and messages in any communications protocol which resolve local addresses to those of the network. - Page 48 Glossary CARRIER SENSE MULTIPLE ACCESS with COLLISION DETECT (CSMA/CD)—This is the access method employed by IEEE 802.3 LAN transceivers, by which multiple stations compete for use of the transmission medium (coax cable) for data packet transmission. It provides for a level of error detection should that transmission be corrupted or impeded by contention for the transmission medium.
- Page 49 AT-4016F Installation Manual HUB/REPEATER—A hub is a central signal distributor. It is used in a wiring topology consisting of several point-to-point segments originating from a central point. The term hub is often used interchangeably with the term repeater. Multiport 10Base-T, 10Base2 and fiber optic (10Base-FL, FOIRL) repeaters are considered hubs.
- Page 50 Glossary MAU-to-MAU, HUB-to-HUB WIRING—10Base-T MAU-to-MAU or hub-to-hub wiring generally requires a crossover cable located somewhere along the UTP cable run. This may commonly occur at the punch-down block or between the RJ-45 wall receptacle and the workstation. MAU/TRANSCEIVER—An Ethernet transceiver is a MAU. A 10Base-T MAU interfaces the UTP media to an AUI port on a workstation, repeater, bridge or other Ethernet device.
- Page 51 AT-4016F Installation Manual PROPAGATION DELAY—The time it takes a signal to travel from the input of a system component to the output. Usually measured in nanoseconds. IEEE 802.3 has specific propagation delay maxima for computing propagation budgets when designing a LAN. Cable length plays a major role in propagation delay; for example, a 50-meter (164-foot) AUI cable has a maximum allowable propagation delay of 257 ns.
- Page 52 Glossary SWITCHED VIRTUAL CIRCUIT (SVC)—A virtual circuit (X.25), virtual connection (Frame Relay) or virtual channel connection (ATM) that has been established dynamically in response to a signaling request message. SWITCHED LAN—Emerging technology that replaces the shared bus backplane of Ethernet hubs and the shared ring backplane of token Ring hubs with a switching backplane.
-
Page 53: Technical Support Fax Order
Appendix B Technical Support Fax Order Name _______________________________ _ ___________________________________ Company ____________________________ _ ___________________________________ Address _____________________________ _ ___________________________________ City ____________________State/Province____________ Zip/Postal Code __________ Country _______________________ Phone______________________ Fax _________ Incident Summary Model number of Allied Telesyn product I am using _____________________________ Firmware release number of Allied Telesyn product _____________________________ Other network software products I am using (e.g., network managers) ____________________________________ _ ___________________________________... -
Page 55: Installation Manual Feedback
Appendix C Installation Manual Feedback Please tell us what additional information you would like to see discussed in the manual. If there are topics you would like information on that were not covered in the manual, please photocopy this page, answer the questions and fax or mail this form back to Allied Telesyn. -
Page 57: Where To Find Us
Appendix D Where To Find Us For Technical Support or Service Location Phone North America 1 (800) 428-4835 1 (206) 481-3790 United States, Canada, Mexico, Central America, South America, Australia, New Zealand France (+33) 1-69-28-16-17 (+33) 1-69-28-37-49 France, Belgium, Luxembourg, The Netherlands, Middle East, Africa Germany (+01) 30-83-56-66 (+49) 30-435-70-650... -
Page 59: Index
Appendix E Index alarms Electronic xv blue 25 electronic mail xv red 25 yellow 25 hot swapping 17 AT-4016F ports 21 ATM media interface 21 RS232 terminal 21 indicators 25, 26 station 21 ATM media module 26 collision 24 LOS 25 fiber optic port 24 online 25 link (amber) 24... - Page 60 Index station ports modules AT-4016F 1, 2, 5 fiber optic 20 AT-4016F/SC front panel 19 support, contacting technical xv ATM media 5, 18 switches 27 ATM physical media 5 synchronous optical network (SONET) 2 ports technical support, contacting xv media 2 terminal connector 20 power supply troubleshooting 29...
