- Page 1 APPROVED COPY A7595-0238 ® DA-C130 Sht 1 of 12 Charger / Power Supply OWNER’S MANUAL...
- Page 2 APPROVED COPY A7595-0238 DA-C130 Sht 2 of 12...
-
Page 3: Table Of Contents
APPROVED COPY TABLE OF CONTENTS INTRODUCTION ..................1 FEATURES A7595-0238 ....................1 SAFEGUARDS ....................2 DA-C130 Sht 3 of 12 GROUNDING/EARTHING ................2 Charging ......................3 Applications ..................... 3 Three Stage Charging Methodology ............... 4 LED Indications....................5 OPERATION AS DC CAMERA SUPPLY FROM MAINS ....... -
Page 4: Introduction
Sht 4 of 12 charging. Like all Anton/Bauer chargers, everything is automatic. Once a battery is placed onto the charger, it will automatically go into one of the Three Stage Charging modes. The left side of the charger is dedicated to charging, while the right side operates simultaneously as selected between charging or operating as a camera power supply. -
Page 5: Safeguards
APPROVED COPY SAFEGUARDS A7595-0238 Power Sources: This unit was designed to operate at mains voltages from 100 to 240 Volts AC, 50-60 Hz. DA-C130 Sht 5 of 12 Important: When powering charger using a generator, the generator must produce a sine wave or modified sine wave output, otherwise charger may be damaged. -
Page 6: Charging
Charging As with all Anton/Bauer chargers, charging with T2 is fully automatic. Mount any Digital A7595-0238 Logic Series or Logic Series battery to the T2 and it will automatically determine the appropriate charge routine and execute it. DA-C130 Sht 6 of 12 Applications ®... -
Page 7: Three Stage Charging Methodology
APPROVED COPY Three Stage Charging Methodology In general, the T2 will deliver a three stage charge routine to each battery. A7595-0238 1. Stage One will deliver a high rate charge matched to the capabilities of the battery (typically a one or two hour rate, depending on battery type). During this... -
Page 8: Led Indications
APPROVED COPY LED Indications The T2 has two sets of three LEDs (one red, two green). The green status LED A7595-0238 indicates: Steady green – line voltage is present with no power drawn through camera output; Flashing green - line voltage is present, powering camera; Off – line voltage not... -
Page 9: Operation As Dc Camera Supply From Mains
The T2 can operate cameras and camcorders using the four pin camera output A7595-0238 connector located on the back of the T2. To power the camera, attach one end of the XLR4 accessory cable (available separately) to the T2. Attach the other end to the... -
Page 10: Fcc Notice
70 watts at 16 volts Fuse Rating 5 amp (PCB Mounted) *IN CAMERA POWER MODE AT 4 PIN XLR CONNECTOR. FUSE/TYPE REPLACEMENT The fuse of the T2 is a PCB mounted device which should only be replaced by a qualified service technician. -
Page 11: Warranty
Anton/Bauer, Inc. (“Anton/Bauer”), 14 Progress Drive, Shelton, Connecticut 06484. If you (the purchaser of the Product from Anton/Bauer, or the person for whom the Product was purchased, if it was a gift) have any questions regarding Product applications, Product specification, or to obtain warranty service on this or any Anton/Bauer product, contact the company at the address above. - Page 12 Sht 12 of 12 The following are trademarks of Anton/Bauer, Inc.: ACS, ADM, Anton/Bauer, Anton/Bauer logo and parallelogram design, Aspekt, Automatique, DataTap, Dionic, EgripZ, ElightZ, ElipZ, EssentialZ, Gold Mount, HubZ, HyTRON, Impac, InterActive and design, LifeSaver, Logic Series, Logic Series logo, Maxx man logo design, MicroCode, PowerStrap, Probe, Proformer, ProPac, RealTime, Satellight, Snap-On, SpokeZ, SSP, Stasis, Tandem, TrimPac, Ultrakit, Ultralight, “The power behind the best cameras capturing the best images in the world.”, “The quality...
