Lucent Technologies GX 550 Technical Specifications

Scale ATM networks and increase your capacity to deliver ATM, IP / MPLS, and frame relay services
at the network edge. Designed for the core, the GX 550
availability, service-aware routing, and high-speed switching you require at the heart of your
multiservice network. With optical interfaces and DWDM support, the GX 550
connect directly to your optical network. This enables you to move statistical multi-plexing into
your transmission facility — helping to create more cost-efficient data transport. Expand service
functionality into low-speed native ATM, Private Line and voice transport applications with the
GX 550
Applications
• Scale ATM networks to
OC-48c/STM-16
• Transport ATM and IP/MPLS
• Provide Circuit Emulation Services
(CES), ATM services and
unchannelized access with the
GX 550 ES
®
Benefits
• Create new revenue opportunities
through multiservice capabilities
• Provide ATM-level QoS for all
multiservice traffic
• Balance core and access functions
for improved ROI
• Simplify network management and
reduce operating costs with Navis
network management software
Features
• Protocol-independent multiservice
switching — Flexibility to change
your service mix to meet demand
• Small footprint — Scale to 25 Gbps
full duplex capacity (32 Gbps for
IP/MPLS) to provide 50/64 Gbps
capacity per rack
• Superior availability — Lossless
fabric switchover and 1+1 Automatic
Protection Switching (APS)
provide proven reliability
• Excellent scalability— High port
densities, industry-leading Virtual
Circuit support, and distributed
routing and signaling increase
service capacity
• Expandable design — Low-speed
ATM interfaces supported
including CES
® Extender Shelf (ES).

Technical Specifications

Description
1.Protocols Supported
ATM/Frame Relay:
IP/MPLS:
Circuit Emulation
2. Physical Interface and Base Input/Output (I/O) Modules
Physical Interface Modules
a. 1-port OC-48/STM-16
b. 1-port OC-48c /STM-16c with optional
full 1+1 or SONET/SDH APS protection
c. 1-port OC-12c/STM-4
d. 4-port OC-3c/STM-1
Interfaces support SONET/SDH laser-based intermediate reach (IR) and long-reach (LR) interfaces
Base I/O Modules
a. ATM Base I/O
GX 550 Extender Shelf (ES)
®
®
a. DS3 Circuit Emulation/ATM
3. System Architecture
• 25 Gbps full duplex switch fabric
(32 Gbps for IP/MPLS)
• Hot-swappable components
• Lossless switchover to redundant
switch fabric
• Distributed routing and signaling
• Port and line card redundancy
• Dedicated packet forwarding engines
for IP/MPLS traffic
GX 550 Multiservice
®
WAN Switch
Multiservice WAN Switch provides the
®
Specifications
UNI 3.0/3.1/4.0, TM 4.0, IISP, PNNI, B-ICI
BGP-4, RIP, Static, MOSPF, DVMRP, IGMP, PPP, LDP,
RSVP-TE, OSPF-TE
Up to 9 ports per chassis
Up to 10 ports per chassis
Up to 39 ports per chassis
Up to 156 ports per chassis
BI01, BI02, BI0-C
Up to 228 fully protected
• QoS with buffering support for up to
20 million cells
• Per VC queuing support
• T1/E1 primary and secondary clock inputs
• Stratum 3e timing
• Multimode LED interfaces
• Up to 2.56M simultaneous circuits sup-
ported per system
® switch can
