- Page 1 Libretto Istruzioni Instruction Manual Manuel d’Instructions Bedienungsanleitung Gebruiksaanwijzing Flexa...
- Page 2 Dear Customer, If you follow the recommendations contained in this Instruction Manual, your appliance will give you constant high performance and will remain efficient for many years to come.
-
Page 3: Installation
INSTALLATION • The manufacturer will not be held liable for any damages resulting from incorrect or improper installation. • The minimum safety distance between the cooker top and the extractor hood is 650 mm. • Check that the mains voltage corresponds to that indicated on the rating plate fixed to the inside of the hood. - Page 4 Dimensions Components...
-
Page 5: Drilling The Support Surface And Fitting The Hood
Drilling the Support surface and Fitting the Hood SCREW FITTING • The hood support surface must be 135 mm above the bottom surface of the wall units. • Drill the support with a ø 4.5 mm drill bit, using the drilling template provided. •... -
Page 6: Recirculation Version Air Outlet
CLOSING ELEMENT • The space between the edge of the hood and the rear wall can be closed by applying the element 20 provided, using the screws supplied for this purpose. Connections RECIRCULATION VERSION AIR OUTLET • Cut a hole ø 125 mm in the wall unit over the hood. -
Page 7: Electrical Connection
ELECTRICAL CONNECTION • Connect the hood to the mains through a two-pole switch having a contact gap of at least 3 mm. • When opening the sliding carriage for the first time after installing the hood, pull it out briskly until it clicks. -
Page 8: Grease Filters
Grease filters CLEANING METAL SELF-SUPPORTING GREASE FILTERS • The filters must be cleaned every two months of operation, or more frequently with heavy usage, and can be washed in a dishwasher. • Remove the filters one at a time, after disconnecting the relative fastening elements. -
Page 9: Odour Filters (Recirculation Version)
Odour filters (Recirculation version) REPLACING ACTIVATED CHARCOAL FILTERS • These filters are not washable and cannot be regenerated, and must be replaced approximately every four months of operation, or more frequently with heavy usage. • Remove the metal grease filters, or open the filter retaining grill. - Page 10 Quest’apparecchio è conforme alla norma europea sulla bassa tensione C.E.E. 73/23 relativa alla sicurezza elettrica e alle norme europee: C.E.E. 89/336 relativa alla compatibilità elettromagnetica e C.E.E. 93/68 relativa alla marcatura CE. This appliance conforms to European Low Voltage Directive 75/23/CEE governing electrical safety, European Directive 89/336/ CEE on Electromagnetic Compatibility and Directive 93/68/CEE regarding CE Marking.
