_ OVERViEW

Headrest
01
02 Harness buckle
03 Central adjusting device
04 Central harness
05 Operating lever for the tilt adjustment mechanism
06 Unlocking device for the seat lock (with double switch)
07 Safety display seat lock
08 ISOFIX SYSTEM control dial
09 Support leg operating button
10 Support leg
11 Front seat lock
Rear seat lock
12
13 ISOFIX SYSTEM unlocking button (left and right)
14 ISOFIX SYSTEM safety displays (left and right)
15 ISOFIX adapter
_ USing THE COnCORD ULTimAX CHiLD CAR SEAT
With the safety of your child in mind, you have decided to purchase our car seat
CONCORD ULTIMAX. The product is manufactured under strict quality control conditions.
Its optimum safety characteristics are only effective if the seat it used as intended.
As a result you should ensure strict adherence with the mounting and usage instructions.
The CONCORD ULTIMAX is suitable for children up to the age of approx. 4 or up to
18 kg. It is suitable for use in vehicles with ISOFIX-approved seats (see documentation
contained in the vehicle's operating manual) in accordance with the relevant child
restraint and anchoring category.
As a result of accident statistics, however, we recommend using the seat behind the
front passenger seat.
The seat consists of 2 parts: the seat (a) and ISOFIX base (B).
The seat can be locked into 4 forwards positions and one backwards position.
22
_ gEnERAL inFORmATiOn
• This is an ISOFIX child restraint. It has been approved for general use in vehicles
equipped with ISOFIX anchoring systems in compliance with ECE regulation 44,
change series 04.
• It is suitable for use in vehicles with ISOFIX-approved seats (see documentation
contained in the vehicle's operating manual) in accordance with the relevant child
restraint and anchoring category.
• This child safety restraint is compliant with the ISOFIX weight category: up to 18 kg
and ISOFIX size categories: D and A
• If you have any questions or doubts, please contact the manufacturer of the child
safety unit or your retailer.
_ FOR iSOFiX SUiTABLE VEHiCLES
The CONCORD ULTIMAX with ISOFIX system has been approved for ‚semi universal'
use, and is suitable for mounting on specific vehicle seats.
The appendix CAR FITTING LIST contains an overview of vehicles and vehicle seats that
have been approved for using the CONCORD ULTIMAX with ISOFIX system in connection
with a support leg.
Should your vehicle not be listed, please ensure that the CONCORD ULTIMAX can be
properly mounted in your car / on the desired seat before you purchase the child seat!
Read the user manual provided by the manufacturer of your vehicle and the mounting
and security instructions contained in this user manual.
For latest updates, please visit: www.concord.de.
23
