American Standard Colony Soft 3875.409 Specification Sheet

38mm
(1-1/2)
MAX.

GENERAL DESCRIPTION:

Cast brass valve bodies with reinforced flexible hose
connections for 6" to 12" (152mm to 305mm) installations.
1/4 turn washerless ceramic disc valve cartridges. Cast
brass spout. One-half inch brass male inlets with brass
coupling nuts. 20" (500mm) long flexible stainless steel drain
cable is pre-assembled to faucet body. Metal Speed Connect™
drain body with 1-1/4 inch (32mm) tail piece, (3875.409).
Non-Metallic Speed Connect™ drain body with 1-1/4 inch
(32mm) tail piece, (3875.403). 2.2 gpm/8.3L/min. maximum
flow rate.
SUGGESTED SPECIFICATION:
Two handle widespread lavatory faucet shall feature cast brass valve bodies with reinforced flexible hose connections for 6"
to 12" installations. Shall also feature 1/4 turn washerless ceramic disc valve cartridges. Shall also feature a drain body with
stainless steel cable actuation. Fitting shall be American Standard Model # 3875.__.__.
© 2006 American Standard Inc.
TWO-HANDLE WIDESPREAD LAVATORY FAUCET
35mm
(1-3/8)DIA.
MOUNTING
HOLES
FLEXIBLE
HOSE
152mm - 305mm
(6 TO 12)
FLEXIBLE
MODEL NUMBER:
3875.403 Widespread Lavatory
Non-metallic Speed Connect™ Pop-up drain.
3875.409 Widespread Lavatory
Metal Speed Connect™ Pop-up drain.
115mm
(4-1/2)
51mm
(2)
64mm
(2-1/2)
DIA.
FLEXIBLE
HOSE
32mm OD
(1-1/4 OD)

PRODUCT FEATURES:

Brass Construction:
with water.
Ceramic Disc Valve Cartridges:
smooth handle operation and drip-free performance.
Low Lead:
Meets NSF Standard 61/Section 9 & Prop 65 lead
requirements.
Speed Connect Drain:
• Fewer Parts - installs in less time.
• No adjustments required - seals the first time, every time.
• Flexible stainless steel cable - installs effortlessly in tight spaces.
Choice of Finishes
C75
COLONY SOFT
WITH ACRYLIC HANDLES
80mm
(3-1/8)
29mm
(1-1/8)
DIA.
FOR GROUND JOINT
OR 1/2" O.D. SLIP
CONNECTION
Durable. Ideal for prolonged contact
Assures a lifetime of
