- Page 1 FRIDGE-FREEZER ZI 9321 T INSTRUCTION BOOKLET 2222 230-81...
-
Page 2: Warnings
WARNINGS It is most important that this instruction book should be retained with the appliance for future refer- ence. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can be acquainted with the functioning of the appliance and the relevant warnings. -
Page 3: Table Of Contents
• Do not place carbonated or fizzy drinks in the • There are working parts in this product which freezer as it creates pressure on the container, heat up. Always ensure that there is adequate which may cause it to explode, resulting in ventilation as a failure to do this will result in component failure and possible food loss. -
Page 4: Use
Freezing fresh food Cleaning the interior Before using the appliance for the first time, wash The 4-star compartment is suitable for the interior and all internal accessories with luke- long term storage of commercially frozen food, and warm water and some neutral soap so as to remove for freezing fresh food. -
Page 5: Fresh Food Refrigeration
Fresh food refrigeration To obtain the best performance: • do not store warm food or evaporating liquids in the refrigerator; • do cover or wrap the food, particularly if it has a strong flavour. • Position food so that air can circulate freely round PR166 D040 Movable shelves... -
Page 6: Removable Drawer
Removable drawer Fruit, vegetables and bottles should be placed in the special bottom drawer provided (see the diagram). D723/2 HINTS Hints for refrigeration • lean foods store better and longer than fatty ones; salt reduces the storage life of food; Useful hints: •... -
Page 7: Maintenance
MAINTENANCE min. 50 mm 200 cm Unplug the appliance before carrying out Periods of non-operation any maintenance operation. When the appliance is not in use for long periods, take the following precautions: Warning min. remove the plug from the wall socket; This appliance contains hydrocarbons in its cooling 200 cm unit;... -
Page 8: Customer Service And Spare Parts
Do not use a mechanical device or any artificial means to speed up the thawing process other than Important those recommended by the manufacturer. However, when the ice becomes very thick on the A temperature rise of the frozen food packs, inner liner, complete defrosting should be carried out during defrosting, may shorten their safe as follows:... -
Page 9: Installation
INSTALLATION It must be possible to disconnect the appliance from Location the mains power supply; the plug must therefore be The appliance should be installed well away from easily accessible after installation sources of heat such as radiators, boilers, direct sunlight etc. -
Page 10: Instructions For Totally Built-In Appliances
Instructions for totally built-in min. 50 mm 200 cm appliances Dimensions of the recess Height 1780 mm min. Depth 550 mm 200 cm Width 560 mm D567 The appliance’s door has been locked in position for transport by means of pins on both sides. Ac- cording to the door opening direction, remove relevant pins at the top and at the bottom. - Page 11 Open the door and push the appliance against the side of the kitchen unit opposite to that of appliance hinges. Fasten the appliance with 4 screws provided in the kit included with the appliance. Snap vent grille (C) and hinge cover (D) into position. D723/2 Press in the joint covers between the appliance and the kitchen unit.
- Page 12 Place guide (A) on the inside part of the furniture door, up and down as shown in the figure and mark the position of external holes. After having drilled holes, fix the guide with the screws supplied. PR166 D040 Fix cover (C) on guide (A) until it clips into place. PR33 Open the appliance door and the furniture door at 90°.
-
Page 13: Reversibility Of The Freezer Door
Fix cover (D) on guide (B) until it clips into place. PR167/1 Reversibility of the freezer door 180°...
