Summary of Contents for Zanussi ZI 9310 DIS
- Page 1 REFRIGERATOR- FREEZER ZI 9310 DIS INSTRUCTION BOOKLET...
- Page 3 Before use Setting the temperature The freezer compartment Freezing fresh food Storage of frozen food Thawing Making ice cubes Fresh food refrigeration Normal operating sounds Internal cleaning When the appliance is not in use External cleaning Changing the light bulb Defrosting Positioning 2222 209-46...
- Page 4 Remove all securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0.5 litre of water). The temperature inside the refrigerator and the freezer is regulated by a single thermostat (B) with 6 temperature positions and an “OFF” (O) position. The pilot light (A) will illuminate when switched on.
- Page 5 When first starting-up or after a period of non use, before putting the products in the freezer compartment let the appliance run for at least two hours on the coldest setting, then turn the thermostat knob to the normal opertion position. Do not exceed the storage period indicated by the manufacturer.
- Page 6 • To obtain the best results from your appliance, neither hot foods nor liquids which may evaporate, should be placed in the larder compartment. • Keep the time between buying chilled food and placing it in your fridge as short as possible. •...
- Page 7 Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from the ELECTRICITY supply. Clean the inside and accessories with warm water and bicarbonate of soda (5ml to 0.5 litre of water). Rinse and dry thoroughly. When the appliance is not in use for long periods, disconnect from the electricity supply, empty all foods and clean the appliance, leaving the doors ajar to prevent unpleasant smells.
- Page 8 The refrigerator automatically defrosts every time the compressor stops. The water is discharged, via the pipe, into a tray located at the back of the appliance above the compressor, where it evaporates. D037 To avoid defrost water overflowing into the fridge, periodically clean the water discharge hole in the centre of the V shaped drip collector at the back of the refrigerator compartment behind the fruit and...
- Page 9 If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation a charge will be made, even if the appliance is under guarantee. contacting your local Service Force Centre, check the following points: No power to the appliance The light does not come on The temperature in the fridge or freezer section is...
- Page 10 The model and serial number of the appliance (found on the rating plate) The purchase date For general enquiries concerning your Zanussi appliance or for further information on Zanussi products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.zanussi.co.uk...
- Page 11 We, Zanussi, undertake that if within 24 months of the date of the purchase this Zanussi appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate.
- Page 12 POWER SUPPLY VOLTAGE AND FREQUENCY TOTAL POWER ABSORBED AVERAGE DAILY UNITS ELECTRICITY * GROSS CAPACITY NET CAPACITY STAR RATING This figure is based on standard test results in accordance with European Standard EN 153. Actual consumption will depend on how the appliance is used and where it is located. 220-240 V / 50 Hz 110 W 0.86 kWh...
- Page 13 IF YOU ARE DISCARDING AN OLD APPLIANCE THAT HAS A LOCK OR CATCH ON THE DOOR, YOU MUST ENSURE THAT IT IS MADE UNUSABLE TO PREVENT YOUNG CHILDREN BEING TRAPPED INSIDE. Depending upon the position which you choose for your appliance, you may wish to reverse the way in which the door opens.
- Page 14 The plug must not be used if the fuse cover/carrier is lost. The cover/carrier is indicated by the coloured insert at the base of the plug. A replacement cover/carrier must be obtained from your local Zanussi Service Force Centre. This appliance complies with the following E.E.C. Directives: (Low Voltage Directive) and subsequent modifications;...
- Page 15 1. Unscrew the upper pin and remove the spacer 2. Remove the upper door 3. Unscrew the pins (B) and the spacers (C) and refit them on the middle hinge of the opposite side. Snap the hinge cover (A). 4. Refit the upper door, the upper pin and the spacer on the opposite side 5.
- Page 16 Push appliance into housing until stop strip (A) touches the kitchen unit. D023 Open the door and push the appliance against the side of the kitchen unit opposite to that of appliance hinges. Fasten the appliance with 4 screws provided in the kit included with the appliance.
- Page 17 Separate parts A, B, C, D as shown in the figure Place guide (A) on the inside part of the furniture door, up and down as shown in the figure and mark the position of external holes. After having drilled holes, fix the guide with the screws supplied.
- Page 18 Should the lining up of the furniture door be necessary, use the clearance of slots. At the end of operations, it is necessary to check if the door of the furniture closes properly. Fix cover (D) on guide (B) until it clips into place. If the appliance is fixed to the side of the kitchen unit, simply slacken the screws in fixing brackets (E), move the brackets as shown in the figure and re-...
