Summary of Contents for Zanussi ZHC 632
- Page 1 ZANUSSI Köksfläkt Ventilator Emhætte Liesituuletin Cooker Hood ZHC 932 ZHC 632 Instruktionsbok Bruksanvisning Brugsvejledning Käyttöohje Operating and Installation Instructions...
-
Page 2: Table Of Contents
Innehållsförteckning ............. 2 Innholdsfortegnelse ............10 Sisällysluettelo ..............18 Indholdsfortegnelse ............26 Contents ................34 Contents Safety warnings ..................34 Description of the cooker hood ............... 35 Using the cooker hood ................35 Maintenance and cleaning ..............36 Guarantee conditions ................38 Technical specifications ................ -
Page 3: Description Of The Cooker Hood
Description of the cooker hood Functions There are two possible systems: • Extraction of air to the outside using an optional venting kit and evacuation duct. • Recirculation using an optional charcoal filter. The air outlet must not be connected to chimney flues or combustion gas ducts. -
Page 4: Using The Cooker Hood
Using the cooker hood • The hood is fitted with one motor having several speed. Best results are obtained by using a low Motor switch Light switch speed for normal conditions and high speed when odours are more concentrated. Turn the hood on a few minutes before you start cooking then you will get an underpressure in the kitchen. -
Page 5: Charcoal Filter
Charcoal filter • The charcoal filter should only be used if you want to use the hood in the recirculation function. • To do this you will need an original ELECTROLUX charcoal filter (available from your local Service Force Centre). •... -
Page 6: Guarantee Conditions
Guarantee Conditions Standard guarantee conditions We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate. -
Page 7: Technical Specifications
Special accessories Charcoal filter PNC 942 120 892 Technical specifications ZHC 932 ZHC 632 Size (cm) Height 81,8/114,8 81,8/114,8 Width 89,9 69,9 Depth 51,5 51,5 Light 2 x 40W 2 x 40W Grease filter Voltage 220-240V 220-240V Total power 260W... - Page 8 Installation Wall unit mounting - Fig. 7-8-9-10-11 • Position the template on the wall, mark the position, and drill the holes (Y). • Mount the two rawl plugs with the hooks. • Hang the hood on the hooks and level it with the adjustment screws. •...
-
Page 9: Mounting The Chimney
• Mount the chimney holder close to the ceilingwith the rawl plugs and the screws. Warning! Be careful that it is centered over the hood and horizontally aligned. Chimney holder Fig. 9 Centre line • Hang the hood on the wall again. Additional hanging points Hooks... - Page 12 LI15DA Ed. 05/03...
