INSTRUCTION BOOKLET
COOKER HOOD
ZHC 935

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZHC 935 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Zanussi ZHC 935

Summary of Contents for Zanussi ZHC 935

  • Page 1 INSTRUCTION BOOKLET COOKER HOOD ZHC 935...
  • Page 2 To enable you to use your appliance effectively and safely, please read this instruction book carefully before using the appliance and retain for future reference. If you require guidance in the use of the appliance or require further information on Zanussi Products, please contact our Customer Care Department.

  • Page 3: Important Safety Information

    It is dangerous to alter the specifications or • Refer to your local Zanussi Service Force modify this product in any way. Centre. Always insist on genuine spare parts. •...

  • Page 4: Your Appliance

    YOUR APPLIANCE OPERATING INSTRUCTIONS This cooker hood is designed to extract unpleasant odours from the kitchen, it will not extract steam. Cooker Hood Controls The cooker hood functions are controlled by five push button switches located centrally in the control fascia. Push to switch ON the worktop lighting.
  • Page 5 To Operate Select the required fan speed and light if required. The appliance can be installed to recirculate or extract contaminated air. The cooker hood is more effective when used in the extraction mode. Recirculation The cooker hood is supplied specified for use in the recirculation mode with the charcoal filter fitted.

  • Page 6: Maintenance And Cleaning

    MAINTENANCE AND CLEANING Before carrying out any maintenance or cleaning isolate the cooker hood from the mains supply. The cooker hood must be kept clean, as a build up of grease or fat can be a fire hazard. External Cleaning The metal casing, visor and chimney should be cleaned at least once a month to keep the hood looking like new.

  • Page 7: Charcoal Filter

    MAINTENANCE AND CLEANING Charcoal Filter The charcoal filter cannot be cleaned or regenerated, it should be replaced approximately every three months or more frequently if the hood is used for more than three hours per day. To Remove the Charcoal Filter Remove the metal grease filter.

  • Page 8: Something Not Working

    If you require an engineer or spare parts contact For general assistance with your appliance or for your local Service Force Centre by telephoning: further information on Zanussi products please contact our Customer Care Department. 08705 929929 Customer Care Department...

  • Page 9: Guarantee Conditions

    GUARANTEE CONDITIONS We, Zanussi, undertake that if within twenty four months of the date of the purchase this Zanussi built-in product or any part thereof is proved to be defective by reason only of faulty workmanship or materials, the company will, at our option repair or replace the same FREE OF ANY CHARGE for labour, materials or carriage on condition that: •...

  • Page 10: Installation Instructions

    INSTALLATION INSTRUCTIONS It is dangerous to alter the specifications or attempt to modify this product in any way. Technical information DIMENSIONS HEIGHT OF CANOPY: 73mm HEIGHT OF CHIMNEY:(UPPER SECTION) 215mm (LOWER SECTION) 740mm WIDTH OF CANOPY: 898mm DEPTH OF CANOPY: 500mm WEIGHT: (GROSS) 24.00kg...

  • Page 11: Installing The Cooker Hood

    INSTALLING THE COOKER HOOD Please ensure that when the appliance is This cooker hood is designed to be fixed to any installed it is easily accessible to an engineer vertical surface over a cooking area, and can be in the event of a breakdown. used in the extraction (ducted to the outside) or recirculation mode.

  • Page 12: Clearance Heights

    INSTALLING THE COOKER HOOD A: Built-in Electric Hob: 650mm clearance B: Built-in Gas Hob: 700mm clearance C: Slot-in Electric Cooker: 685mm clearance D: Slot-in Gas Cooker: 767mm clearance Clearance Heights The cooker hood is designed to be fitted over a cooking appliance at the clearance heights stated, providing the maximum output of the appliance beneath does not exceed the maximums quoted...

  • Page 13: Fitting The Wall Brackets

    INSTALLING THE COOKER HOOD 7.2.1 Mark a hole centre on the horizontal line Fitting the Wall Brackets 965mm above the worktop, 116mm either Draw a vertical line on the wall from the centre of side of the vertical line as indicated. the cooking appliance up to the ceiling, or as high Drill the holes marked on the wall using a as the adjoing wall cabinets using a spirit level...

  • Page 14: Fitting The Canopy Hood

    INSTALLING THE COOKER HOOD Fitting the Canopy Hood Before starting to fix the canopy, tighten the two screws Vr located on the canopy mouiunting brackets. Hook the canopy onto the screws (not supplied). Tighten up the screws. Adjust the screws item Vr to level the canopy.

  • Page 15: Fitting The Chimney Stack

    INSTALLING THE COOKER HOOD Fitting the Chimney Stack The chimney consists of two sections. The upper 7.2.1 chimney measures 215mm and the lower chimney (with the holes for recirculation on either side) measures 740mm. Upper Chimney Stack Expand the sides of the upper chimney stack item 2.1 and place the chimney over the two brackets 7.2.1 ensuring they are well seated.
  • Page 19 © Electrolux plc 2002 436000659 02 - 020626...
