CONTROL PANEL

2
1
10 9 8
22
21
20
08:56 Page 4
3
4
7 6 5
11
12
13
14
15
16
17
18
19
4
Digital display and indicators:
1 BOTTOM GRILL indicator
2 TOP GRILL indicator
3 CLOCK SET indicator
4 LESS/MORE indicator
5 INFORMATION indicator
6 TIMER indicator
7 COOKING IN PROGRESS indicator
8 WEIGHT (kg) indicator
9 MICROWAVE indicator
10 CONVECTION indicator
Operating buttons:
11 LANGUAGE button
12 AUTO COOK button
13 AUTO DEFROST button
14 PIZZA button
15 COOKING MODE dial
Rotate the dial so that indicator points to
appropriate symbol:
for microwave cooking
for microwave cooking with TOP GRILL
for microwave cooking with BOTTOM GRILL
for microwave cooking with CONVECTION
for CONVECTION
for TOP GRILL
for BOTTOM GRILL
for TOP & BOTTOM GRILLS
16 CONVECTION (˚C) button
Press to change the convection setting.
17 TIME/WEIGHT dial
Rotate the dial to enter either the
cooking/defrosting time or weight of food.
18 START /+1 button
MIN
19 INFO/CLOCK button
20 STOP button
21 MICROWAVE POWER LEVEL button
Press to change the microwave power setting.
22 LESS/MORE buttons
