Oven And Accessories - Sharp R-25ST Operation Manual With Cookbook

R-25ST English 20/01/2005
3
1 Control panel
2 Oven lamp
3 Door opening handle
4 Waveguide cover
5 Seal packing
6 Oven cavity
7 Door seals and sealing surfaces
8 Ventilation openings
9 Outer cabinet
10 Power cord
ACCESSORIES:
Check to make sure the following accessories are
provided:
(11) Turntable (12) Roller stay (13) Seal packing
• Place the roller stay in the seal packing on the
floor of the cavity.
• Then place the turntable on the roller stay.
• To avoid turntable damage, ensure dishes or
containers are lifted clear of the turntable rim when
removing them from the oven.
NOTE: When you order accessories, please mention
two items: part name and model name to your dealer
or SHARP authorised service agent.
16:19 Page 3

OVEN AND ACCESSORIES

7
10
3
6 5 4
9
1
2
8
11
12
13
