CV215AP1
Instruction Manual
en
Manuale di istruzioni
it
pt
Manual de Utilização

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CV215AP1 and is the answer not in the manual?

Questions and answers

Related Manuals for Smeg CV215AP1

Summary of Contents for Smeg CV215AP1

  • Page 1 CV215AP1 Instruction Manual Manuale di istruzioni Manual de Utilização...
  • Page 2 Please read this manual first! Dear Customer, We hope that your product, which has been produced in modern plants and checked under the most meticulous quality control procedures, will provide you an effective service. For this, we recommend you to carefully read the entire manual of your product before using it and keep it at hand for future references.

  • Page 3: Table Of Contents

    CONTENTS 1 Your refrigerator 4 Preparation 2 Important Safety Warnings 4 5 Using your refrigerator 13 Intended use ........4 Setting the operating temperature ... 13 For products with a water dispenser; . 6 Making ice ........16 Child safety ........6 6 Maintenance and HCA Warning ........

  • Page 4: Your Refrigerator

    Your refrigerator MAX. 1. Thermostat 2. Flap (Fast-Freeze compartment) 3. Ice cube tray & Ice bank 4. Drawers 5. Adjustable front feet C Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If the subject parts are not included in the product you have purchased, then it is valid for other models.

  • Page 5: Important Safety Warnings

    Important Safety Warnings Please review the following • For products with a freezer compartment; Do not put bottled and information. Failure to observe this canned liquid beverages in the freezer information may cause injuries or compartment. Otherwise, these may material damage. Otherwise, all burst.
  • Page 6 • Do not pull by the cable when pulling • Never connect your refrigerator to off the plug. electricity-saving systems; they may • Place the beverage with higher proofs damage the refrigerator. tightly closed and vertically. • If there is a blue light on the •...

  • Page 7: For Products With A Water Dispenser

    down and hurt you and damage Child safety refrigerator when you open the door. • If the door has a lock, the key should Never place objects on top of the be kept away from reach of children. refrigerator; otherwise, these objects •...

  • Page 8: Things To Be Done For Energy Saving

    Things to be done for energy saving • Do not leave the doors of your refrigerator open for a long time. • Do not put hot food or drinks in your refrigerator. • Do not overload your refrigerator so that the air circulation inside of it is not prevented.

  • Page 9: Installation

    Installation Please remember that the manufacturer shall not be held liable if the information given in the instruction manual is not observed. Points to be considered when re-transporting your refrigerator 1.Your refrigerator must be emptied and cleaned prior to any transportation. 2.Shelves, accessories, crisper and etc.

  • Page 10: Disposing Of The Packaging

    3. There must be appropriate air A damaged power cable must be ventilation around your refrigerator replaced by a qualified electrician. in order to achieve an efficient Product must not be operated before operation. If the refrigerator is to be it is repaired! There is danger of placed in a recess in the wall, there electric shock!

  • Page 11: Adjusting The Feet

    Adjusting the feet If the ambient temperature is below 0°C, the food in the fridge If your refrigerator is unbalanced; compartment will freeze.So, we You can balance your refrigerator by recommend you don’t use the fridge turning the front legs as shown in the compartment in such low ambient illustration below.

  • Page 12: Reversing The Doors

    Reversing the doors Proceed in numerical order . (12) 45 ° 180°...

  • Page 13: Preparation

    Preparation Your refrigerator should be installed at least 30 cm away from heat sources such as hobs, ovens, central heater and stoves and at least 5 cm away from electrical ovens and should not be located under direct sunlight. The ambient temperature of the room where you install your refrigerator should at least be 10°C.

  • Page 14: Using Your Refrigerator

    Using your refrigerator Setting the operating temperature Cold Warm The operating temperature is regulated by the temperature control. The normal storage temperature of 1 = Lowest cooling setting (Warmest your appliance should be -18 °C (0 °F). setting) Lower temperatures can be obtained MAX.

  • Page 15: Indicator Lights

    MAX. Thermostat knob The thermostat knob is located on the Indicator lights indicator light frame. There are three coloured indicator Important: lights located inside the appliance When you press the fast-freeze switch which show the operating mode of the or adjust the set temperature, there freezer.
  • Page 16 • Attention Remember to turn the thermostat Keep the already deep-frozen food knob back to its previous always separated with freshly placed position once food has frozen. food. Defrosting of the appliance When deep-freezing hot food, the cooling compressor will work until the Excessive build-up of ice will affect food is completely frozen.

  • Page 17: Making Ice

    Making ice Fill the ice container with water and place it into its seat. Your ice will be ready approximately in two hours. You can easily remove your ice by slightly twisting the ice container. Reconnect the appliance to the mains. Place the frozen food into the drawers and slide the drawers into the freezer.

  • Page 18: Maintenance And Cleaning

    Maintenance and cleaning Protection of plastic Never use gasoline, benzene or surfaces similar substances for cleaning purposes. Do not put the liquid oils or oil-cooked meals in your refrigerator in unsealed We recommend that you unplug the containers as they damage the appliance before cleaning.

  • Page 19: Recommended Solutions For The Problems

    Recommended solutions for the problems Please review this list before calling the service. It might save you time and money. This list includes frequent complaints that are not arising from defective workmanship or material usage. Some of the features described here may not exist in your product.
  • Page 20 The fridge is running frequently or for a long time. • Your new product may be wider than the previous one. This is quite normal. Large refrigerators operate for a longer period of time. • The ambient room temperature may be high. This is quite normal. •...
  • Page 21 The operation noise increases when the refrigerator is running. • The operating performance of the refrigerator may change due to the changes in the ambient temperature. It is normal and not a fault. Vibrations or noise. • The floor is not even or it is weak. The refrigerator rocks when moved slowly. Make sure that the floor is strong enough to carry the refrigerator, and level.
