- Page 1 CV260PNF CV270PNF1 Instruction Manual Manuale di istruzioni Manual de instrucciones Manual de Utilização...
- Page 2 Please read this manual first! Dear Customer, We hope that your product, which has been produced in modern plants and checked under the most meticulous quality control procedures, will provide you an effective service. For this, we recommend you to carefully read the entire manual of your product before using it and keep it at hand for future references.
-
Page 3: Table Of Contents
... 9 Before operating your refrigerator .. 9 Electric connection ... 10 Disposing of the packaging ... 10 Disposing of your old refrigerator . 10 Adjusting the legs ... 11 Reversing the doors ... 12 4 Using your refrigerator 13 LED indicators and control panel . -
Page 4: Your Refrigerator
Your refrigerator 1. Control Panel 2 Fan 3. Flap (Fast-Freeze compartment) 4. Ice cube tray & Ice bank 5. Drawers 6. Adjustable front feet C Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If the subject parts are not included in the... -
Page 5: Important Safety Warnings
• Never use the parts on your refrigerator such as the door as a means of support or step. • Do not use electrical devices inside the refrigerator. - Page 6 Do not touch the plug with wet hands when plugging the product. • Do not plug the refrigerator if the wall outlet is loose. • Water should not be sprayed directly on inner or outer parts of the product for safety purposes.
-
Page 7: For Products With A Water Dispenser
• As they require a precise temperature, vaccines, heat-sensitive medicine and scientific materials and etc. should not be kept in the refrigerator. • If not to be used for a long time, refrigerator should be unplugged. A possible problem in power cable may cause fire. -
Page 8: Things To Be Done For Energy Saving
• Do not put hot food or drinks in your refrigerator. • Do not overload your refrigerator so that the air circulation inside of it is not prevented. • Do not install your refrigerator... -
Page 9: Installation
Before operating your refrigerator Before starting to use your refrigerator check the following: 1. Is the interior of the refrigerator dry and can the air circulate freely in the rear of it? -
Page 10: Electric Connection
3. Clean the interior of the refrigerator as recommended in the “Maintenance and cleaning” section. 4. Plug the refrigerator into the wall outlet. -
Page 11: Adjusting The Legs
Adjusting the legs If your refrigerator is unbalanced; You can balance your refrigerator by turning the front legs of it as illustrated in the figure. The corner where the leg exists is lowered when you turn in the direction of black arrow and raised when you turn in the opposite direction. -
Page 12: Reversing The Doors
Reversing the doors Proceed in numerical order . 45 ° 180°... -
Page 13: Using Your Refrigerator
Using your refrigerator Setting the operating temperature The operating temperature is regulated by the temperature control. 1 = Lowest cooling setting (Warmest Warm setting) 4 = Highest cooling setting (Coldest setting) (Or) Min. = Lowest cooling setting (Warmest setting) Max. = Highest cooling setting... - Page 14 Note: Red indicator light has a built-in delay. Once the appliance is energized red indicator light will not illuminate for 24 hours. Thermostat knob (5) The thermostat knob is located on the indicator light frame. Important: When you press the fast-freeze switch or adjust the set temperature, there may be a short delay before the compressor starts to operate.
- Page 15 Making ice cubes Fill the ice-cube tray 3/4 full with water and place it in the freezer. As soon as the water has turned into ice, you can take out the ice cubes. Never use sharp objects such as knives or forks to remove the ice cubes.
-
Page 16: Maintenance And Cleaning
B Make sure that no water enters the lamp housing and other electrical items. B If your refrigerator is not going to be used for a long period of time, unplug the power cable, remove all food, clean it and leave the door ajar. -
Page 17: For The Problems
The refrigerator does not operate • Is the refrigerator properly plugged in? Insert the plug to the wall socket. • Is the fuse of the socket which your refrigerator is connected to or the main fuse blown out? Check the fuse. - Page 18 The fridge is running frequently or for a long time. • Your new refrigerator may be wider than the previous one. This is quite normal. Large refrigerators operate for a longer period of time. • The ambient room temperature may be high.This is quite normal.
- Page 19 It is normal and not a fault. Vibrations or noise. • The floor is not even or it is weak. The refrigerator rocks when moved slowly. Make sure that the floor is level, strong and capable to carry the refrigerator.
- Page 20 • Food packages may prevent the door’s closing. Replace the packages that are obstructing the door. • The refrigerator is probably not completely vertical on the floor and it might be rocking when slightly moved. Adjust the elevation screws. • The floor is not level or strong. Make sure that the floor is level and capable to carry the refrigerator.
