- Page 1 CV 2902 PNE Instruction Manual Manuale di istruzioni Manual do Utilizador Notice d'Utilisation Bruksanvisning...
- Page 2 Please read this user manual first! Dear Customer, We hope that your product, which has been produced in modern plants and checked under the most meticulous quality control procedures, will provide you an effective service. Therefore, read this entire user manual carefully before using the product and keep it as a reference.
-
Page 3: Table Of Contents
CONTENTS 1 Your cooler/freezer 4 Preparation 2 Important Safety Warnings 6 5 Using your cooler/freezer 16 Intended use ........6 Icematic and ice storage container ..18 General safety ........6 Dual cooling system: .......19 For products with a water dispenser; 10 Freezing fresh food ......19 Child safety ........10 Recommendations for preservation of frozen food ........20... -
Page 4: Your Cooler/Freezer
Your cooler/freezer 1. Control Panel 2. Flap (Fast-Freeze compartment) 3. Ice cube tray & Ice bank 4. Drawers 5. Adjustable front feet Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If the subject parts are not included in the product you have purchased, then it is valid for other models. -
Page 5: Important Safety Warnings
Important Safety Warnings Please review General safety following information. • When you want to Failure to observe this dispose/scrap the information may cause product, we recommend injuries material you to consult the damage. Otherwise, all authorized service warranty reliability in order to learn the commitments will become required information and invalid. - Page 6 of the evaporator, pipe freezer compartment. extensions or surface Otherwise, these may coatings are punctured burst. causes skin irritations • Do not touch frozen food and eye injuries. by hand; they may stick to your hand. • Do not cover or block the ventilation holes on • Unplug your refrigerator your refrigerator with any...
- Page 7 • Do not use mechanical • Contact authorized devices or other means service when there is a to accelerate the power cable damage to defrosting process, avoid danger. other than those • Never plug the recommended by the refrigerator into the wall manufacturer.
- Page 8 • This operation manual gas near the refrigerator should be handed in to to avoid fire and the new owner of the explosion risk. product when it is given • Never place containers to others. filled with water on top • Avoid causing damage of the refrigerator;...
-
Page 9: For Products With A Water Dispenser
• The plug's tip should be exceeds 5 bars a cleaned regularly with a pressure regulator dry cloth; otherwise, it should be used. If the may cause fire. water mains pressure exceeds 8 bars then • Refrigerator may move the refrigerator’s water if adjustable legs are not circuit should not be properly secured on the... -
Page 10: Package Information
for recycling. Therefore, do not dispose which the unit is placed. the product with normal domestic Ignore this warning if your waste at the end of its service life. Take product's cooling system contains it to a collection point for the recycling R134a. -
Page 11: Installation
Installation In case the information which are given in the user manual are not taken into account, manufacturer will not assume any liability for this. Points to be paid attention to when the relocation of the cooler/freezer 1. Your cooler/freezer should be unplugged.Before transportation 3. -
Page 12: Disposing Of The Packaging
• The voltage stated on the label Before disposing of your cooler/ located at left inner side of your freezer, cut out the electric plug and, if product should be equal to your there are any locks on the door, make network voltage. -
Page 13: Adjusting The Legs
Adjusting the legs Changing the door opening direction If your cooler/freezer is unbalanced; You can balance your cooler/freezer Door opening direction your by turning its front legs as illustrated refrigerator can be changed according in the figure. The corner where the leg to the place you are using it. -
Page 14: Preparation
Preparation • Your cooler/freezer should be installed at least 30 cm away from heat sources such as hobs, ovens, central heater and stoves and at least 5 cm away from electrical ovens and should not be located under direct sunlight. • The ambient temperature of the room where you install your cooler/freezer should at least be 10°C. -
Page 15: Using Your Cooler/Freezer
Using your cooler/freezer Indicator Panel 1. Quick Freeze Function: Quick Freeze indicator turns on when If you press the QuickFreeze button the Quick Freeze function is on. Press repeatedly with short intervals, the QuickFreeze button again to cancel this electronic circuit protection will be function. - Page 16 3. Freezer Set Function: 9-Energy Saving Function This function allows you to make When you press this button, Energy the freezer compartment temperature saving icon will light up and Energy setting. Press this button to set the Saving Function will be activated. If temperature of the freezer compartment energy saving function is active, all to -18, -20, -22 and -24 respectively.
-
Page 17: Icematic And Ice Storage Container
Icematic and ice storage container *optional Using the Icematic Fill the Icematic with water and place it into its seat. Your ice will be ready approximately in two hours. Do not remove the Icematic from its seating to take ice. Turn the knobs on the ice reservoirs clockwise by 90 degrees. -
Page 18: Dual Cooling System
Dual cooling system: • Frozen food must be used immediately after they are thawed Your refrigerator is equipped with and they should never be re-frozen. two separate cooling systems to • Please observe the following cool the fresh food compartment and instructions to obtain the best results. freezer compartment. Thus, air in the 1. -
Page 19: Recommendations For Preservation Of Frozen Food
F r e e z e r F r i d g e Compartment Compartment Remarks Setting Setting -18°C 4°C This is the normal recommended setting. -20, -22 or These settings are recommended when the 4°C -24°C ambient temperature exceeds 30°C. Use when you wish to freeze your food in a Quick Freeze 4°C... -
Page 20: Deep-Freeze Information
Deep-freeze information Food must be frozen as rapidly as possible when they are put in the freezer in order to keep them in good quality. The TSE norm requires (according to certain measurement conditions) the refrigerator to freeze at least 4.5 kg of foodstuff at 32°C ambient temperature to -18°C or lower within 24 hours for every 100-liters of freezer volume. -
Page 21: Maintenance And Cleaning
Maintenance and cleaning Protection of plastic Never use gasoline, benzene or surfaces similar substances for cleaning purposes. Do not put the liquid oils or oil- We recommend that you unplug the cooked meals in your cooler/freezer appliance before cleaning. in unsealed containers as they damage the plastic surfaces of your Never use any sharp abrasive cooler/freezer. -
Page 22: Troubleshooting
Troubleshooting Please review this list before calling the service. It will save your time and money. This list includes frequent complaints that are not arising from defective workmanship or material usage. Some of the features described here may not exist in your product. The cooler/freezer does not operate. - Page 23 The cooler/freezer is running frequently or for a long time. • New product may be wider than the previous one. Larger cooler/freezers operate for a longer period of time. • The room temperature may be high. >>>It is normal that the product operates for longer periods in hot ambient.
- Page 24 Temperature in the fridge or freezer is very high. • The fridge temperature is adjusted to a very high value. >>>Fridge compartment temperature setting has an effect on the temperature of the freezer. Change the temperatures of the fridge or freezer and wait until the relevant compartments attain a sufficient temperature.
- Page 25 Bad odour inside the cooler/freezer. • No regular cleaning is performed. >>>Clean the inside of the cooler/freezer regularly with a sponge, lukewarm water or carbonate dissolved in water. • Some containers or package materials may cause the smell. >>>Use a different container or different brand packaging material.
