Summary of Contents for Smeg CV 275 NF
- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Smeg CV275NF o cerca il tuo prodotto tra le migliori offerte di Frigoriferi e Congelatori CV 275 NF Instruction Manual Manuale di istruzioni Gebruiksaanwijzing Notice d'Utilisation...
- Page 2 Please read this user manual first! Dear Customer, We hope that your product, which has been produced in modern plants and checked under the most meticulous quality control procedures, will provide you an effective service. Therefore, read this entire user manual carefully before using the product and keep it as a reference.
-
Page 3: Table Of Contents
CONTENTS 1 Your refrigerator 5 Using your cooler/freezer 16 Setting the operating temperature ...16 2 Safety and Environment Fast freeze ........18 Instructions Freezing of Foodstuff .......18 General Safety ........6 Defrosting ........18 Intended Use ........8 Freezing fresh food ......18 Child Safety ........9 Recommendations for preservation of Compliance with WEEE Directive and frozen food ........19... -
Page 4: Your Refrigerator
Your refrigerator MAX. 1. Control Panel 2. Fan 3. Flap (Fast-Freeze compartment) 4. Ice cube tray & Ice bank 5. Drawers 6. Adjustable front feet C Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If the subject parts are not included in the product you have purchased, then it is valid for other models. -
Page 5: Safety And Environment Instructions
Safety and Environment Instructions This section provides the safety – staff kitchen areas in shops, offices and other working environments; instructions necessary to prevent the – farm houses and by clients in hotels, risk of injury and material damage. motels and other residential type Failure to observe these instructions will environments;... - Page 6 Do not keep flammable materials and products with flammable gas (sprays, etc.) in the refrigerator. Do not place containers holding liquids on top of the product. Splashing water on an electrified part may cause electric shock and risk of fire. Exposing the product to rain, snow, sunlight and wind will cause electrical danger.
-
Page 7: Intended Use
refrigerating appliances. The label on the inner left To avoid contamination of food, side indicates the type of gas please respect the following used in the product. instructions: 1.1.2 For Models with – Opening the door for long periods Water Dispenser can cause a significant increase of Pressure for cold water inlet shall the temperature in the compartments... -
Page 8: Child Safety
Package Information Original spare parts will be provided for 10 years, following the product Packaging materials of the product purchasing date. manufactured from recyclable Child Safety materials in accordance with our National Environment Regulations. Do Keep packaging materials out of not dispose of the packaging materials children’s reach. -
Page 9: Installation
Installation In case the information which are given in the user manual are not taken into account, manufacturer will not assume any liability for this. Points to be paid attention to when the relocation of the refrigerator 1. Your refrigerator should be unplugged.Before transportation of your refrigerator, it should be emptied 4. -
Page 10: Disposing Of The Packaging
Placing and Installation Extension cables and multi plugs must not be used for connection. If the entrance door of the room A damaged power cable must be where the refrigerator will be installed is replaced by a qualified electrician. not wide enough for the refrigerator to pass through, then call the authorized Product must not be operated before service to have them remove the doors... -
Page 11: Adjusting The Legs
Adjusting the legs If your refrigerator is unbalanced; You can balance your refrigerator by turning its front legs as illustrated in the figure. The corner where the leg exists is lowered when you turn in the direction of black arrow and raised when you turn in the opposite direction. -
Page 12: Reversing The Doors
Reversing the doors Proceed in numerical order . 45 ° 180°... -
Page 13: Preparation
Preparation Your cooler/freezer should be °C, frozen food in the freezer does installed at least 30 cm away from not thaw thanks to its Advanced heat sources such as hobs, ovens, Electronic Temperature Control central heater and stoves and at least System. - Page 14 Since hot and humid air will not directly penetrate into your product when the doors are not opened, your product will optimize itself in conditions sufficient to protect your food. Functions and components such as compressor, fan, heater, defrost, lighting, display and so on will operate according to the needs to consume minimum energy under these circumstances.
-
Page 15: Using Your Cooler/Freezer
Using your cooler/freezer Setting the operating temperature MAX. Cold Warm Frequently opening the door causes the interior temperature to rise. The operating temperature is regulated For this reason, it is recommended by the temperature control. to close the door again as soon as 1 = Lowest cooling setting (Warmest possible after use. - Page 16 Indicator lights Freezing There are three coloured indicator Freezing food lights located inside the appliance You can use the appliance for freezing which show the operating mode of the fresh food as well as for storing pre- freezer. frozen food. Amber Indicator Please refer to the recommendations Illuminates when the thermostat knob...
-
Page 17: Fast Freeze
Freezing fresh food Fast freeze It must be preferred to wrap or cover the food before placing them in the If large amounts of fresh food are going refrigerator. to be frozen, adjust the control knob to max. 24 hours before putting the fresh Hot food must cool down to the room temperature before putting food in the fast freeze compartment. -
Page 18: Recommendations For Preservation Of Frozen Food
1. Do not freeze too large quantities Defrosting of food at one time. The quality of The freezer compartment defrosts the food is best preserved when it automatically. is frozen right through to the core as Placing the food quickly as possible. 2. - Page 19 WARNING! Foodstuff must be divided into portions according to the family’s daily or meal based consumption needs. Foodstuff must be packaged in an airtight manner to prevent them from drying even if they are going to be kept for a short time. Materials necessary for packaging: Cold resistant adhesive tape Self adhesive label...
-
Page 20: Maintenance And Cleaning
Maintenance and cleaning Never use gasoline, benzene or To remove door racks, remove all the similar substances for cleaning contents and then simply push the purposes. door rack upwards from the base. We recommend that you unplug the Never use cleaning agents or water appliance before cleaning. -
Page 21: Troubleshooting
Troubleshooting Please review this list before calling the service. It will save your time and money. This list includes frequent complaints that are not arising from defective workmanship or material usage. Some of the features described here may not exist in your product. The refrigerator does not operate. - Page 22 The operation noise increases when the refrigerator is running. The operating performance of the refrigerator may change due to the changes in the ambient temperature. It is normal and not a fault. The refrigerator is running frequently or for a long time. New product may be wider than the previous one.
- Page 23 Temperature in the fridge or freezer is very high. The fridge temperature is adjusted to a very high value. >>>Fridge compartment temperature setting has an effect on the temperature of the freezer. Change the temperatures of the fridge or freezer and wait until the relevant compartments attain a sufficient temperature.
- Page 24 Bad odour inside the refrigerator. No regular cleaning is performed. >>>Clean the inside of the refrigerator regularly with a sponge, lukewarm water or carbonate dissolved in water. Some containers or package materials may cause the smell. >>>Use a different container or different brand packaging material. Food is put into the refrigerator in uncovered containers.
