- Page 1 PLASMA CUTTER - 35 AMP PLASMA CUTTER - 35 AMP PLASMA CUTTER - 35 AMP PLASMA CUTTER - 35 AMP PLASMA CUTTER - 35 AMP ASSEMBLY AND OPERATING INSTRUCTIONS Visit our Web site at http://www.harborfreight.com For technical questions and replacement parts, please call 1-800-444-3353...
- Page 2 ITEM Safety Warnings and Precautions WARNING: When using tool, basic safety precautions should always be followed to re- duce the risk of personal injury and damage to equipment. Read all instructions before using this tool! Keep work area clean Observe work area conditions Keep children away Store idle equipment Use the right tool for the job...
- Page 3 Dress properly Use eye and ear protection Do not overreach Maintain tools with care Disconnect power Avoid unintentional starting Stay alert Check for damaged parts Guard against electric shock Replacement parts and accessories Do not operate tool if under the influence of alcohol or drugs Use proper size and type extension cord 35 amps 11 AWG...
- Page 4 Maintenance Pacemaker safety warning Note Warning: The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions and situations that may occur. It must be under- stood by the operator that common sense and caution are factors which cannot be built into this product, but must be supplied by the operator.
- Page 5 Fire and Explosion Safety Fumes and Gases Hazards...
- Page 6 Transporting the Plasma Cutter High Frequency Radiation Electrical Shock Hazard Unpacking...
- Page 7 WARNING: This product, when used for welding and similar applications, produces chemicals known to the State of California to cause cancer and birth defects (or other reproductive harm). (California Health & Safety Code 25249.5, et seq.) Front Panel Controls and Indicators Cutting Operation Assembly Operation...
- Page 8 Caution: Verify that no wires, cables, or other obstructions are below the cutting area. Troubleshooting SYMPTION POSSIBLE CAUSE REV 06/03...
- Page 9 Maintenance Warning: Before performing any maintenance you must disconnect power to the Plasma Cutter and discharge it’s electrode to ground. Main Parts List Item # Description NOTE...
- Page 10 Main Assembly Drawing 72.1 PLEASE READ THE FOLLOWING CAREFULLY 84.1 46.1...
- Page 11 Torch Assembly Drawing Torch Parts List Item # Description...
