BANDSAW BLADE WELDER
SEt up AND OpERAtiNg iNStRuctiONS
Due to continuing improvements, actual product may differ slightly from the product described herein.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE tHiS MANuAL.
Copyright
2003 by Harbor Freight Tools
©
any artwork contained herein may be reproduced in any shape or form without the express
written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
Model
Diagrams within this manual may not be drawn proportionally.
Distributed exclusively by Harbor Freight tools
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our website at: http://www.harborfreight.com
3663
. All rights reserved. No portion of this manual or
®
.
®
Revised 03d, 07k
