4. Wireless LAN Access Point Configuration

This Access Point provides a web-based configuration tool allowing you to configure from wired
or wireless stations. Follow the instructions below to get started configuration.

From Wired Station

1. Make sure your wired station is in the same subnet as the Access Point.
The default IP Address and Sub Mask of the Access Point are:
Default IP Address: 192.168.0.254
Default Subnet:
Configure your PC to be in the same subnet as the Access Point.
1a) Windows 95/98/Me
1.
Click the Start button and select Settings, then click Control Panel. The Control
Panel window will appear.
2.
Double-click Network icon. The Network window will appear.
3.
Check your list of Network Components. If TCP/IP is not installed, click the Add
button to install it now. If TCP/IP is installed, go to step 6.
4.
In the Network Component Type dialog box, select Protocol and click Add button.
5.
In the Select Network Protocol dialog box, select Microsoft and TCP/IP and then click
the OK button to start installing the TCP/IP protocol. You may need your
Windows CD to complete the installation.
6.
After installing TCP/IP, go back to the Network dialog box. Select TCP/IP from the
list of Network Components and then click the Properties button.
7.
Check each of the tabs and verify the following settings:
Bindings: Check Client for Microsoft Networks and File and printer sharing for
Microsoft Networks.
WINS Configuration: Select Disable WINS Resolution.
IP Address: Select Specify an IP Address. Specify the IP Address and Subnet
Mask as following example.
8.
Reboot the PC. Your PC will now have the IP Address you specified.
255.255.255.0
IP Address: 192.168.0.200 (any IP address within
192.168.0.2~192.168.0.253 is available, but do not setup
192.168.0.254)
Subnet Mask: 255.255.255.0
Wireless Range Extender (WL-130) Configuration
