Back Panel

Access Point's connection ports are located on the back panel. Below is the description of each
connection port.
Antenna Connector:
This round connection is standard Reverse SMA connector where any antenna with Reverse
SMA connector can connect to the Access Point.
DC Adapter Port
Insert the power jack of the power adapter into this port.
LAN Port
The Access Point's LAN port is where you connect to your LAN's network devices.
Reset
The Reset button allows you to do one of two things.
1) If problems occur with your Access Point, press the reset button with a pencil tip
(for less than 4 seconds) and the Access Point will re-boot itself, keeping your
original configurations.
2) If problems persist or you experience extreme problems or you forgot your
password, press the reset button for longer than 4 seconds and the Access Point will
reset itself to the factory default settings (warning: your original configurations will
be replaced with the factory default settings).
