- Page 1 Split Air Conditioner Owner's Manual Residential Air Conditioners Thank you for choosing Residential Air Conditioners, please read this owner’s manual carefully before operation and retain it for future reference.
-
Page 2: Table Of Contents
CONTENTS Operation and maintenance ■ Notices for operation.................1 ■ Notices for use ..................3 ■ Names and functions of each part ............4 ■ Operation of Remote Controller ............5 ■ Emergency operation..............10 ■ Clean and care ................11 ■ Troubleshooting ................13 Installation service ■... -
Page 3: Notices For Operation
Notices for operation Please read the following carefully before operating Be sure to pull out ★ When the voltage ★ Never splice the is very high, the the power plug as power cord or use components would be easily the air conditioner not in use an extended cord. - Page 4 Notices for operation ★ ★ Please don't cut off or damage the To adjust the airflow direction appropriately. When operating power cords and control cords. the unit, to adjust the vertical and lateral air If they are damaged, please ask the qualified flow direction by use of remote controller.
-
Page 5: Notices For Use
Notices for use Working principle and special functions for cooling Principle: Air conditioner absorbs heat in the room and transmit to outdoor and discharged, so that indoor ambient temperature decreased, its cooling capacity will increase or decrease by outdoor ambient temperature. Anti-freezing function: If the unit is running in COOL mode and in low temperature, there will be frost formed on the heat exchanger, when indoor heat exchanger temperature decreased below 0 ℃... -
Page 6: Names And Functions Of Each Part
Names and functions of each part Indoor unit Air in ⑴ ⑵ ⑸ ⑶ ⑷ Air out ⑻ Front panel ⑴ Filter ⑵ Guide louver ⑶ Wall pipe ⑷ ⑹ Bind tape ⑸ Connection pipe ⑹ Drainage pipe ⑺ ⑺ Remote controller ⑻... -
Page 7: Operation Of Remote Controller
Operation of Remote Controller Remote Controller Description ON/OFF Press it to start or stop operation MODE Press it to select operation mode (AUTO/COOL/DRY/FAN/HEAT) : Press it to increase temperature setting : Press it to decrease temperature setting Press it to set fan speed Press it to set swing angle TIMER ON Press it to set auto-on timer... -
Page 8: Digital Display
Operation of Remote Controller 17 18 19 MODE icon: LOCK icon: is displayed by pressing "+" If MODE button is pressed, current operation mode icon and “-” buttons simultaneously.Press (AUTO), ( COOL), them again to clear the display. (DRY), (FAN) or (HEAT SET TIME display: is only for heat pump models) will... - Page 9 Operation of Remote Controller Remote Controller Description ON/OFF: Press this button to turn on the unit. Press this button again to turn off the unit. MODE: Each time you press this button, a mode is selected in a sequence that goes from AUTO, , as the following: COOL, DRY, FAN, and HEAT HEAT...
- Page 10 Operation of Remote Controller TIMER ON: Press this button to initiate the auto-ON timer. To cancel the auto-timer program, simply press this button again. After pressing this button, disappears and "ON "blinks . 00:00 is displayed for ON time setting. Within 5 seconds, press + or - button to adjust the time value. Every press of either button changes the time setting by 1 minute.
- Page 11 Operation of Remote Controller LIGHT: Press LIGHT button to turn on the display's light and press this button again to turn off the display's light. If the light is turned on , is displayed. If the light is tunrned off, disappears.
-
Page 12: Emergency Operation
Emergency Operation Emergency Operation When the wireless remote controller is lost or damaged, please use the manual switch, at this time, it is running in Auto Run mode that will not change the temperature setting value and fan speed. The manual switch can be operated as follow: At operation: When the unit stopped running, ●... -
Page 13: Clean And Care
Clean and care CAUTION Turn power off and pull out the power plug before cleaning air conditioner. Or it may ● cause electric shock. Never sprinkle water on the indoor unit for cleaning because it can cause an electric ● shock. - Page 14 Clean and care ① Take down the air filter At the slot of surface panel to open an angle, pull the ( a) air filter downward and take it out. ( b) Cleaning ② To clean the dust adhering to the filters, you can either use a vacuum cleaner, or wash them with warm water (the water with the neutral detergent should below 45 ℃).
-
Page 15: Troubleshooting
Troubleshooting Warning Do not repair the air conditioner at your discretion. Incorrect repair may cause electric shock or fire, so please contact Authorized Service Center for professional repair. Following checks prior to contact may save your time and costs. Phenomenon Troubleshooting The unit can not operte immediately Once the air conditioner is stopped,... - Page 16 Troubleshooting Phenomenon Troubleshooting Creaking noise can be heard when This is caused by the deformation of start or stop the unit. plastic due to the change of temperature. Air conditioner does not operate at all. Has the power been shut down? ●...
- Page 17 Troubleshooting Troubleshooting Phenomenon In HEAT mode, when the temperature of ● Indoor unit cannot deliver air indoor heat exchanger is very low, that will stop deliver air in order to prevent cool air. (Within 3min) In HEAT mode, when the outdoor temperature ●...
-
Page 18: Installation Service
Installation service- Notices for installation Important Notices 1. The unit installation work must be done by qualified personnel according to the local rules and this manual. 2. Installation must be performed in accordance with the requirements of NEC and CEC by authorized personnel only. -
Page 19: Notices For Installation
Notices for installation Safety Requirements For Electric Appliances 1. The power supply should be used the rated voltage and AC exclusive circuit, the power cable diameter should be satisfied. 2. Don't drag the power cable emphatically. 3. It should be reliably earthed, and it should be connected to the special earth device, the installation work should be operated by the professional. -
Page 20: Installation Dimension Diagram
Installation dimension diagram Installation dimension diagram Space to the ceiling Above 15cm Above 15cm Above Space to the wall Space to the wall Above Above Air outlet side Space to the floor... -
Page 21: Install Indoor Unit
Install indoor unit Install the rear panel 1. Always mount the rear panel horizontally. As the water drainage pipe at the left, when adjusting the rear panel, this side should not be too high; the right side should be slightly high. 2. -
Page 22: Wiring Cover
Install indoor unit Connect indoor and outdoor electric wires 1. Open the front panel upwardly. 2. Screw off the fixing screw of cover plate and screw off cover plate. 3. Put the power connection cable through the back of indoor unit wire hole and take it out. 4. - Page 23 Install indoor unit Install the indoor unit External connection The piping can be lead out from right, right rear, ● electric wire Gas side piping Liquid side left, left rear. piping 1. When routing the piping and wiring from the left Tailing 3 Tailing 2 or right side of indoor unit, cut off the tailings...
-
Page 24: Check After Installation And Test Operation
Check after installation and test operation Check after installation Items to be checked Possible malfunction The unit may drop, shake or emit noise. Has it been fixed firmly? It may cause insufficient cooling (heating) Have you done the refrigerant leakage test? capacity. -
Page 25: Installation And Maintenance Of Healthy Filter
Installation and Maintenance of Healthy Filter Installation Instructions 1. Forcibly pull the panel for a specific angle from the two ends of the front panel according to the arrow direction. Then pull the air filter downwards to remove it. (See Fig.a) Fig. -
Page 26: Configuration Of Connection Pipe And Additional Volume Of Refrigerant
Configuration of connection pipe and additional volume of refrigerant 1. Standard length of connection pipe 5m 7.5m 8m 2. Min length of connection pipe For the unit with standard connection pipe of 5m, there is no limitation for the min length of connection pipe. For the unit with standard connection pipe of 7.5m and 8m, the min length of connection pipe is 3m. - Page 27 Configuration of connection pipe and additional volume of refrigerant Sheet 2. Additional refrigerant charging amount for R22 R407C R410A and R134a Diameter of connection pipe mm Indoor unit throttle Outdoor unit throttle Liquid pipe Gas pipe Cooling only, Cooling only Cooling and cooling and heating (g / m)
- Page 28 66129912625...
