- Page 1 A C Z C I 4 H 4 R 1 8 A C Z E M4 H 4 R 1 8 A C Z C I 4 H 4 R 2 4 A C Z E M4 H 4 R 2 4...
-
Page 2: Table Of Contents
Content Operation Notices Precautions......................1 Parts name ......................2 Screen Operation Guide Buttons on remote controller .................3 Introduction for icons on display screen ..............3 Introduction for buttons on remote controller............4 Function introduction for combination buttons............6 Operation guide .....................7 Replacement of batteries in remote controller............7 Emergency operation ....................8 Maintenance Clean and maintenance..................8... -
Page 3: Precautions
Precautions Warning cause electric shock. may be broken. damage. Please contact dealer when you need to repair air conditioner. person can perform the work. Otherwise, it may cause personal injury or damage. damage or personal injury. personal injury or damage. electric shock. -
Page 4: Parts Name
Parts name Indoor Unit air inlet panel aux.button air outlet cooling power receiver indicator indicator window display heating temp. drying indicator indicator indicator remote control (Display content or position may be different from above graphics, please refer to actual products) Outdoor Unit air inlet handle... -
Page 5: Buttons On Remote Controller
Buttons on remote controller ON/OFF button MODE button +/- button SWING button SLEEP button TIMER button Introduction for icons on display screen Timer on Timer off Sending signal auto operation swing operation cool operation sleep operation dry operation lock fan operation set speed heat operation Set temperature... -
Page 6: Introduction For Buttons On Remote Controller
Introduction for buttons on remote controller Note: When power is connected(stand by condition), you can operate the air conditioner through the remote controller. When unit is on, each time you press the button on remote controller, the sending signal icon " "... - Page 7 Introduction for buttons on remote controller SPEED 2 ( ), SPEED 3 ( ), SPEED 4 ( AUTO Note: SWING button Press this button to turn on up&down air swing. SLEEP button Under Cool, Heat mode, press this button to turn on Sleep function. Press this button to cancel Sleep function.
-
Page 8: Function Introduction For Combination Buttons
Introduction for buttons on remote controller Note: If time changes from 10h to 24h, the set time will be increased or decreased by 1h. troller will exit setting status. Function introduction for combination buttons Child lock function Press “+” and “-” buttons simultaneously can turn on or turn off child lock function. When child lock function is started up, LOCK indicator on remote controller is ON. -
Page 9: Operation Guide
Operation guide turn on the air conditioner. Press "+" or "-" button to set your required temperature. (Temperature can’t be adjusted under auto mode). speed. Press "SWING" button to select fan blowing angle. Replacement of batteries in remote controller battery 1. -
Page 10: Emergency Operation
Emergency operation If remote controller is lost or damaged, please use auxiliary button to turn on or turn off the air conditioner. The operation in details are as below: air conditioner. When the air conditioner is turned on, it will operate under auto mode. - Page 11 Clean and maintenance Open panel Pull out the panel to a certain the water (below 45 ) to clean it, and then put it in a shady and cool place to dry. panel cover tightly. Note: operation environment, clean frequency can be increased.
- Page 12 Clean and maintenance Checking before use-season 1. Check whether air inlets and air outlets are blocked. 2. Check whether circuit break, plug and socket are in good condition. 4. Check whether mounting bracket for outdoor unit is damaged or corroded. If yes, please contact dealer.
-
Page 13: Malfunction Analysis
Malfunction analysis General phenomenon analysis Please check below items before asking for maintenance. If the malfunction still Phenomenon Check items Solution (such as static electricity, stable the plug after about 3min, and voltage)? then turn on the unit again. within the signal receiving range? Indoor unit can’t receive... - Page 14 Malfunction analysis Phenomenon Check items Solution fuse is burnt out? circuit break or fuse. ioner can’t operate after stopping operation? on the unit again. for remote controller is correct? Mist is em- itted from temperature and humidity will indoor unit’s idity is high? be decrease and mist will air outlet...
- Page 15 Malfunction analysis Phenomenon Check items Solution Odours are such as furniture and cigarette, emitted etc. ner operates such as thunder, wireless power, and then turn on the abnormally devices, etc. unit again. Outdoor ating mode, it may generate unit has vapor, which is a normal vapor phenomenon.
-
Page 16: Error Code
Malfunction analysis Error Code When air conditioner status is abnormal, temperature indicator on indoor unit will ation of error code. Above indicator diagram is only for reference. Please refer to Indoor actual product for the actual display indicator and position. Error code Error code Troubleshooting... -
Page 17: Installation Dimension Diagram
Installation dimension diagram Space to the wall Space to the wall Drainage pipe... -
Page 18: Tools For Installation
Tools for installation 1 Level meter 2 Screw driver 3 Impact drill 4 Drill head 5 Pipe expander 6 Torque wrench 7 Open-end wrench 8 Pipe cutter 9 Leakage detector 10 Vacuum pump 11 Pressure meter 13 Inner hexagon spanner 14 Measuring tape Note: Selection of installation location... -
Page 19: Requirements For Electric Connection
Requirements for electric connection Safety precaution 1. Must follow the electric safety regulations when installing the unit. circuit break. 3. Make sure the power supply matches with the requirement of air conditioner. Unstable power supply or incorrect wiring or malfunction. Please install proper power supply cables before using the air conditioner. -
Page 20: Installation Of Indoor Unit
Installation of indoor unit Step one: choosing installation location rm it with the client. Step two: install wall-mounting frame 1. Hang the wall-mounting frame on the wall; adjust it in horizontal position with the plastic expansion particles in the holes. 3. - Page 21 Installation of indoor unit Indoor outdoor Note: opening the hole. The plastic expansion particles are 5-10 locally. Step four: outlet pipe 1. The pipe can be led out in the 2. When select leading out the pipe direction of right, rear right, left or from left or right, please cut off the rear left.
- Page 22 Installation of indoor unit Hex nut diameter Tightening torque (N . m) open-end wrench 15~20 30~40 union nut 40~55 pipe torque wrench 60~65 70~75 indoor pipe 4. Wrap the indoor pipe and joint of con- nection pipe with insulating pipe, and then wrap it with tape.
- Page 23 Installation of indoor unit 2. Make the power connection wire go cable-cross through the cable-cross hole at the back hole the front side. power connection wire with wire clip. N(1) N(1) L1 L2 Outdoor unit connection 4. Put wiring cover back and then tighten the screw. 5.
- Page 24 Installation of indoor unit Step eight: bind up pipe drain hose 1. Bind up the connection pipe, power connection pipe band cord and drain hose with the band. indoor and outdoor power cord indoor unit pipe indoor power cord liquid pipe 3.
-
Page 25: Installation Of Outdoor Unit
Installation of outdoor unit (select it according to the actual installation situation) 1. Select installation location according to the house structure. 2. Fix the support of outdoor unit on the selected location with expansion screws. Note: installing the outdoor unit. Make sure the support can withstand at least four times of the unit weight. - Page 26 Installation of outdoor unit Step four: connect indoor and outdoor pipes 1. Remove the screw on the right han- 3. Pretightening the union nut with dle of outdoor unit and then remove hand. the handle. pipe joint screw union nut handle 2.
- Page 27 Installation of outdoor unit 2. Fix the power connection wire and signal control wire with wire clip (only for cooling and heating unit). Note: Step six: neaten the pipes 1. The pipes should be placed along the wall, bent reasonably and hidden possibly. Min. semidiameter of bending the pipe is 10cm.
-
Page 28: Vacuum Pumping
Vacuum pumping Use vacuum pump 1. Remove the valve caps on the liquid valve and gas liquid valve piezometer valve and the nut of refri- gas valve gerant charging vent. refrigerant valve cap 2. Connect the charging hose charging vent nut of refrigerant gerant charging vent of gas charging vent... -
Page 29: Check After Installation
Check after installation Items to be checked Possible malfunction The unit may drop, shake or emit noise. Have you done the refrigerant leakage test? (heating) capacity. It may cause condensation and water dripping. It may cause condensation and water Is water drained well? dripping. - Page 30 1. Standard length of connection pipe 2. Min. length of connection pipe is 3m. 3. Max. length of connection pipe and max. high difference. Max length Max length Cooling Max height Cooling Max height of connec- of connec- capacity difference capacity difference tion pipe...
- Page 31 Diameter of connection pipe Outdoor unit throttle Liquid pipe(mm) Gas pipe(mm) Cooling only(g/m) Cooling and heating(g/m)
-
Page 32: Pipe Expanding Method
Pipe expanding method Note: Improper pipe expanding is the main cause of refrigerant leakage. Please expand the pipe according to the following steps: E: Expand the port the distance of indoor unit and hard outdoor unit. mold expander pipe pipe pipe cutter Note: leaning... - Page 33 5 6 1 0 N W 1 2 A v e S u i t e 2 0 9 - 2 1 1 F o r t L a u d e r d a l e , F L 3 3 3 0 9 P h : 9 5 4 - 7 7 1 - 1 4 1 5 F x : 9 5 4 - 7 7 1 - 1 4 1 8 h t t p : / / w w w .
