Angle Grinder
MODEL 9563H
MODEL 9564H
MODEL 9565H
I N S T R U C T I O N
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
DOUBLE
INSULATION
M A N U A L
007357

Advertisement

Table of Contents
loading

Related Manuals for Makita 9565H

Summary of Contents for Makita 9565H

  • Page 1 Angle Grinder MODEL 9563H MODEL 9564H MODEL 9565H 007357 DOUBLE INSULATION I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 2: Specifications

    SPECIFICATIONS Model 9563H 9564H 9565H Depressed center wheel diameter 100 mm 115 mm 125 mm Spindle thread 11,000 11,000 11,000 No load speed (min Overall length 299 mm 299 mm 299 mm Net weight 1.8 kg 1.8 kg 1.8 kg Safety class •...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS ENA001-2 WARNING: When using electric tools, basic safety precautions, including the following, should always be followed to reduce the risk of fire, electric shock and personal injury. Read all these instructions before operating this product and save these instructions. For safe operations: tion and changing accessories.

  • Page 4: Additional Safety Rules

    ADDITIONAL SAFETY RULES ENB031-6 13. Hold the tool firmly. Always use eye and ear protection. Other per- sonal protective equipment such as dust mask, 14. Keep hands away from rotating parts. gloves, helmet and apron should be worn. 15. Make sure the wheel is not contacting the work- Always be sure that the tool is switched off and piece before the switch is turned on.

  • Page 5: Functional Description

    FUNCTIONAL CAUTION: DESCRIPTION • Always be sure that the tool is switched off and unplugged before adjusting or checking function on the tool. Shaft lock 007358 CAUTION: • Never actuate the shaft lock when the spindle is moving. The tool may be damaged.
  • Page 6 Mount the wheel guard with the protrusion on the wheel guard band aligned with the notch on the bearing box. Then rotate the wheel guard around 180 degrees clockwise (for 9563H) or counterclockwise (for 9564H, 9565H). Be sure to tighten the screw securely.

  • Page 7: Operation

    Installing or removing depressed center grinding wheel/Multi- 007362 disc (accessory) Mount the inner flange onto the spindle. Fit the wheel/disc on the inner flange and screw the lock nut onto the spindle. 1. Lock nut 2. Depressed center grinding wheel/ Multi-disc 3.

  • Page 8: Maintenance

    CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose.
  • Page 9 Memo...
  • Page 10 Memo...
  • Page 11 Memo...
  • Page 12 Makita Corporation 884675-1...
