Dolby Digital 5.1

Multimedia Entertainment System
with AC 3 Decoder
PowerMax-950
User Manual
To ensure the smooth handling of your warranty please write the serial number of
your drive into the box. In the case of warranty you are expected to send it together
with a copy of your invoice to your nearest TEAC sales representative.

Advertisement

Table of Contents
loading

Related Manuals for Teac PowerMax-950

Summary of Contents for Teac PowerMax-950

  • Page 1: Dolby Digital

    To ensure the smooth handling of your warranty please write the serial number of your drive into the box. In the case of warranty you are expected to send it together with a copy of your invoice to your nearest TEAC sales representative.

  • Page 2: Table Of Contents

    Warranty ......................30 • Changes in specifications and features may be made without notice or obligation. • Copyright © 2003, TEAC Corporation. All rights reserved. First Edition: February 2003 • Company and product names provided herein are trademarks of their respective companies.

  • Page 3: Important Safeguards

    Important Safeguards For your protection, please read these instructions completely, and keep this manual for future reference. Carefully observe and comply with all warnings, cautions and instructions placed or de- scribed in the operating instructions or service manual. Warning To guard against injury, the following basic safety precautions should be observed in the installation, use, and servicing of the set.
  • Page 4 Unplug the power cord and consult a qualified Polarization technician (or the dealer from whom the unit If this unit is equipped with a polarized AC line was purchased or the nearest service center). plug (a plug having one blade wider that the other), that plug will fit into the power outlet only This symbol is intended to alert one way.

  • Page 5: Features

    Features Dolby Digital (5.1 channel) surround Compact design with separate panel sound at the decoder unit Dolby Pro • Logic surround sound Five satellite speakers (wall mount- ing possible) Stereo sound Powerful subwoofer in a wooden Two digital inputs (optical and case coaxial) Magnetically shielded speakers...

  • Page 6: Precautions

    Precautions • Please read this owner's manual care- Never put anything, especially metal fully. It has been prepared to help you into the unit. with initial set up procedures. • Do not attempt to clean the unit with • Do not open the cabinet. Doing so may alcohol, benzene or thinner, as this cause an electric shock.

  • Page 7: Powermax-950 User Controls

    PowerMax-950 User Controls another. During the test the corre- sponding LEDs at the front panel of the decoder unit light and show which of the speakers the test signal is ac- tually applied (/L, /C, /R, /SR, /SL, /LFE). After passing the test the sys- tem resumes with the last settings.

  • Page 8: Connecting Speakers

    Connecting Speakers Rear right speaker Rear left speaker Front right speaker Subwoofer Front left speaker Center speaker Decoder 9pin connecting cable 12V power cable...

  • Page 9: Connecting Equipment

    Connecting Equipment Your PowerMax-950 can be connected The unit receives its input signal over to the following devices: both of the channels. To select the input you have to set the little switch at the DVD player back side of the unit to “COAXIAL” or XBOX / PS2 (see "How to connect...

  • Page 10: How To Connect The Xbox

    5. Connect the optical cable to the adapt- er and plug its other side into the de- 1. Remove the installed AV cable if there coder device of the PowerMax-950. is any. Now activate the Dolby Digital mode of 2. Plug the enclosed adapter into the AV your XBOX.
  • Page 11 Front/Center Speakers: Subwoofer: The placement of the subwoofer does The left, right and center speakers not affect the final quality of the sound should face the seated listener and be image too much, so you can install it with placed at ear level. The center speaker the room layout in mind.

  • Page 12: Surround Sound

    Surround Sound Since the unit is equipped with front, center, rear and subwoofer amplifiers, Dolby Digital and Dolby Pro • Logic effects can be reproduced. You can enjoy the feeling of a movie theater, concert hall or ball game ground in your own room. •...

  • Page 13: Specifications

    Specifications Amplifier Section Power Output P.M.P.O. Front-/Rear speaker 4 x 100 watts 15 watts Center speaker 150 watts Subwoofer 400 watts 15 watts Power Source AC 230V ~ 50Hz/55watts Safety Standards Speaker Section Front, Center and Rear speaker Speaker 7.6cm (magnetic shielded type) Impedance 8 Ohm Frequency Response...

  • Page 14: Warranty

    (2) years from the date of purchase by the orig- inal retail purchaser. According to the following terms this TEAC product will be re- paired without charge of labor and materials by the authorized TEAC service stations, by the authorized TEAC dealers and/or their authorized service stations.
  • Page 15 Limitations of Liability and Exclusion of Implied Warranties Unless considered unenforceable or unlawfull under the applicable national law: 1. TEAC’s liability for any defective product is limited to repair or replacement of the product, at TEAC's option and the option of authorized service stations, author- ized dealers and their authorized service stations.
  • Page 16 TEAC products.Furthermore TEAC is not liable for damages arising out of loss of use, loss of revenue or profits, or any other damages, wether incidential, consequential, or otherwise.
