Teac MC-DX10 Service Manual

Hide thumbs Also See for MC-DX10:
Table of Contents

Advertisement

Quick Links

PRESET(1-20)
VOLUME
TEAC
MICRO Hi-Fi SYSTEM MC-DX10
PC board shown are viewed from parts side.
The parts with no reference number or no parts number
in the exploded views are not supplied.
As regards the resistors and capacitors, refer to the
circuit diagrams contained in this manual.
!
Parts marked with this sign are safety critical
components. they must be replaced with identical
components - refer to the appropriate parts list and
ensure exact replacement.
FPGM/SET
CD
FM/AM
TUNING
SCAN
OPEN
+
POWER
TONE
-
MC-DX10
MICRO Hi-Fi SYSTEM
2 ADJUSTMENT AND CHECKS
3 EXPLODED VIEW AND PARTS LIST
2
3
5
10
18
20

Advertisement

Table of Contents
loading

Related Manuals for Teac MC-DX10

Summary of Contents for Teac MC-DX10

  • Page 1 TUNING SCAN OPEN VOLUME POWER TONE TEAC MICRO Hi-Fi SYSTEM MC-DX10 MC-DX10 MICRO Hi-Fi SYSTEM 1 SPECIFICATIONS PC board shown are viewed from parts side. 2 ADJUSTMENT AND CHECKS The parts with no reference number or no parts number in the exploded views are not supplied.

  • Page 2: Specifications

    MC-DX10 1 SPECIFICATIONS Amplifier Section 5 watts per channel (RMS, 8 ohms) Output Power: 15 watts per channel (RMS, 8 ohms) Output to Subwoofer: 50 Hz to 20 kHz Frequency Responce : Tuner Section 87.5 MHz to 108.0 MHz AM (MW)
  • Page 3 2. Connect the test loop antenna across the output of the signal generator. 3. Connect the oscilloscope to the speaker terminal. 4. Set the signal generator as listed in the alignment chart. 2-2 Adjustment and Test Points AM ANT COIL T502 L501 CT501 T503 CT502 L502 CT504 CT503 MC-DX10 TUNER PCB...
  • Page 4 MC-DX10 2-2-1 FM/AM alignment chart SG SETTING TUNER SETTING ADJUSTMENT POINT ADJUSTMENT ITEM 87.5MHz 87.5MHz L502 1. FM band Adjust for max.output. 1kHz, +/-22.5kHz dev. 108MHz 108MHz CT502 1kHz, +/-22.5kHz dev. 90MHz 90MHz L501 Adjust for max. output 1kHz, +/-22.5kHz dev.

  • Page 5: Exploded Views And Parts List

    MC-DX10 3 EXPLODED VIEWS AND PARTS LIST EXPLODED VIEW - 1 EXPLODED VIEW-2 Left Flat Panel speaker Assy 9601-025220-801 Right Flat Panel speaker Assy 9601-025220-901...
  • Page 6 MC-DX10 EXPLODED VIEW-1 REF. NO DESCRIPTION REMARKS PARTS NO. 6600-020346-000 GUIDE PIN SHAFT 6001-250301-000-04 TEAC MC-DX10 TRAY DOOR 6001-250310-000-04 LENS DISPLAY 6001-250303-000-03 TEAC MC-DX10 FRONT HOUSING 6001-250302-000 WINDOW 9401-025201-171 OPEN SWITCH PCB ASSY 8501-025100-100 MOTOR BRACKET ASSY 3009-213000-200 SONY CD MECH...
  • Page 7 MC-DX10 EXPLODED VIEW-2 REF. NO PARTS NO. DESCRIPTION REMARKS 9601-025220-801 MC-DX10( LEFT) FLAT PANEL SP ASSY 2330-002901-006 RCR JACK (WHITE) 6501-250301-000-01 SPEAKER GRILL 6600-120030-930 SCREW NUT M3x9.3 6001-250312-000 BRACKET COVER SPEAKER 6001-250318-000 PANEL SPEAKER 6600-170095-000 RUBBER PAD 6600-200008-000 DOUBLE SIDE ADHESIVE RING...
  • Page 8 MC-DX10 EXPLODED VIEW-3...
  • Page 9 RUBBER PAD 66.6x30x2 3-15 6600-170097-001 RUBBER PAD 3-16 6600-210131-000 EVA PAD 143x12x1.5 3-17 6600-210130-001 EVA PAD 163x12x1.5 6001-250334-000-03 3-18 MC-DX10 SUB-WOOFER HOUSING 3-19 6600-210129-000 EVA PAD 3-20 6600-990069-000 SUB-WOOFER SOUND BOX 3-21 6001-250333-000 AIR PIPE 3-22 6600-070130-000 FOOT - SW...
  • Page 10 MC-DX10 4 PC BOARDS AND PARTS LIST TUNER PCB ASSY - TOP REF. NO PARTS NO. DESCRIPTION REMARKS 9401-025201-321 TUNER PCB ASSY 4801-250320-001 TUNER PCB CF502 1603-107003-991A FILTER LT10.7MA5 CF503 1603-450001-002 FILTER LTP450B 2300-004000-001 STRAIGHT CONN.WAFER 4PIN CN401 CN501 STRAIGHT CONN WAFER 6PIN...
  • Page 11 MC-DX10 TUNER PCB - TOP TUNER PCB - BOTTOM...
  • Page 12 MC-DX10 SERVO PCB ASSY - TOP REF. NO PARTS NO. DESCRIPTION REMARKS 9401-025201-181 SERVO PCB ASSY 4801-250180-001 SERVO PCB 2300-009000-000 STRAIGHT CONN WAFER 9PIN 2300-003000-001 STRAIGHT CONN WAFER 3PIN 4194-620123-000 IC - TC9462F 4121-530103-000 IC - TA2153FN SERVO PCB ASSY - BOTTOM PARTS NO.
  • Page 13 MC-DX10 SERVO PCB - TOP SERVO PCB - BOTTOM...
  • Page 14 MC-DX10 MCU PCB ASSY - TOP REF. NO PARTS NO. DESCRIPTION REMARK 9401-025204-231 MCU PCB ASSY 4801-250230-001 MCU PCB LCD101 3110-538300-000 LCD DISPLAY LED101,102 3100-334010-000 LED D3MM - BLUE Q104 1301-124000-400 TR - DTA124ESA Q105 1300-114000-400 TR - DTC114YS REM101...
  • Page 15 MC-DX10 MCU PCB - TOP MCU PCB - BOTTOM I/O PCB - TOP I/O PCB - BOTTOM...
  • Page 16 MC-DX10 AUDIO PCB ASSY - TOP REF. NO PARTS NO. DESCRIPTION REMARK 9401-025203-571 AUDIO PCB ASSY 4801-250570-101 AUDIO PCB D201 1402-471201-200 ZENER DIODE 4.7V D202 1401-141480-000 DIODE 1N4148 IC202 4120-780053-000 IC - TA2078P IC205 4178-090311-600 IC - NJM78L09A AUDIO PCB ASSY - BOTTOM REF.
  • Page 17 MC-DX10 AUDIO PCB - TOP AUDIO PCB - BOTTOM SUB-WOOFER POWER PCB SUB-WOOFER OUT PCB...

  • Page 18: Wiring Diagram

    MC-DX10 5 WIRING DIAGRAM TUNER PCB AM ANT COIL WHITE BLACK GREEN CN501 CN401 TO MCU PCB CN103 TO SERVO PCB CN2 SUB-WOOFER POWER PCB TO SUB-WOOFER OUT PCB JP2 TO TRANSFORMER AC12V JP1B TO SPEAKER TO SUB-WOOFER OUT PCB JP1A...
  • Page 19 MC-DX10 SERVO PCB TO MCU PCB CN101 TO MCU PCB CN102 TO CD MECH AUDIO PCB CN203 CN204 TO MCU PCB CN104 TO I/O PCB CN301...
  • Page 20 MC-DX10 6 INCLUDED ACCESSORIES INCLUDED ACCESSORIES REF. NO PARTS NO. DESCRIPTION REMARKS 5100-012500-900 INSTRUCTION BOOK - ENG/ITALIAN 2611-320009-900 2M DOUBLE CHANNEL AUDIO CABLE 2620-220000-900 2M DC POWER CABLE 4090-302032-001 BUTTON LI BATTERY 3V 9805-012500-401 REMOTE CONTROL (RC940)
  • Page 21 TEAC NEDERLAND BV Oeverkruid 15,NL-4941 W Raamsdonksveer, Nederland Phone:0162-510210 TEAC BELGIUM NV/SA. c/o TEAC NEDERLAND BV, Oeverkruid 15, NL-4941 W Raamsdonksveer, Nederland Phone:+31-162-510860 TEAC ITALIANA S.p.A. Via C, Cantu 11, 20092 Cinisello Balsamo, Milano, Italy Phone:02-66010550 TEAC AUSTRALIA PTY., LTD.
  • Page 22 TUNER PCB KSC945 KSC945 DTC114YS 5x3.5T 5x3.5T KSC945 KSC945 KSC945 DTC114YS DTC114YS 5x3.5T KSC945 KSC945 N0456 4.7MH LTP450B LT10.7MA5 KSC945 4.7MH MC-DX10 MICRO HI-FI SYSTEM...
  • Page 23 SERVO PCB 5.6V MC-DX10 MICRO HI-FI SYSTEM...
  • Page 24 MCU PCB TMP87EP26F 2SC2120Y DTC114YS DTC114YS MC-DX10 MICRO HI-FI SYSTEM...
  • Page 25 AUDIO PCB I/O PCB D1 IN4148 IC203C BA4558 IC204A IC203A BA4558 BA4558 IC204B BA4558 IC203B Q305 KSR2003 BA4558 R308 MC-DX10 MICRO HI-FI SYSTEM...
  • Page 26 D305 1N4004 R306 1R / 1W IC7 7812 FUSE2 250V/2A DC JACK SPOUT AC PLUG 230V/50HZ D306 1N4004 C308 C311 C309 C310 470UF D307 1N4004 D308 1N4004 LED1 R-SP L-SP R L G SUB-WOOFER OUT PCB MC-DX10 MICRO HI-FI SYSTEM...
