- Page 1 60143-1248 Suite Road, Heights Theatre NEC Multimedia Theatre MultiSync MT830 + /MT1030 + ™ LCD Projector User’s Manual NEC Technologies Illinois Itasca, Arlington 1250 Inc. Technologies, Multimedia /MT1035 + ™ ® ™...
- Page 2 I M P O R T A N T Precautions Please read this manual carefully before using your NEC MultiSync MT830+/MT1030+/MT1035+ LCD Projector and keep the manual handy for future reference. Your serial number is located under the name plate label on the right side of your MultiSync MT830+/MT1030+/MT1035+.
-
Page 3: Important Safeguards
2000 hours of use, the lamp bulb may shatter, and pieces of glass may be scattered in the lamp case. Do not touch them as the pieces of glass may cause injury. If this happens, contact your NEC dealer for lamp replacement. - Page 4 ATTENTION RISQUE D’ELECTROCUTION NE PAS OUVRIR ATTENTION RAYONNEMENT LASER NE PAS REGARDER DANS LE FAISCEAU LONGUEUR D’ONDE: 645 nm (640-660 nm) MAX. SORTIE: 1 mW APPREIL A LASER DE CLASSE 2 AVERTISSEMENT AFIN DE REDUIRE LES RISQUES D’INCENDIE OU D’ELECTROCUTION, NE PAS EXPOSER CET APPAREIL A LA PLUIE OU A L’HUMIDITE.
-
Page 5: Remplacement De La Lampe
être éparpillées dans le compartiment de la lampe. Ne les touchez pas car elles peuvent vous blesser. Dans ce cas, contactez votre revendeur NEC afin de procéder au remplacement de la lampe. - Page 6 LCD Projector ® Products NEC Technologies, Inc. (hereafter NECTECH) warrants this product to be free from defects in material and workmanship under the following terms. HOW LONG IS THE WARRANTY? Parts and labor are warranted for (2) two years from the date of the first customer purchase.
-
Page 7: Table Of Contents
T A B L E 1. Introduction Introduction To The MultiSync MT830+/MT1030+/MT1035+ LCD Projector ... 13 How Do You Get Started? ... 15 What’s In The Box? ... 15 Getting To Know Your MultiSync MT830+/MT1030+/MT1035+ LCD Projector ... 17 Front / Rear Features ... 17 Side Features ... -
Page 8: Introduction
• Eight kinds of pointers are available for your presentation. Installing the MultiSync MT830+/MT1030+/MT1035+ LCD Projector on the ceiling must be done by authorized NEC techni- , SXGA(with cians. Consult your NEC dealer for more information. -
Page 9: How Do You Get Started
Please save the original box and packing materials if you ever need to ship your MultiSync MT830+/MT1030+/MT1035+ LCD Projector. • NEC MultiSync MT830+/MT1030+/MT1035+ LCD Projector • Remote Control With Built-In Laser Pointer And Cables • Mouse Adapter for IBM PS/2 and Mac •... -
Page 10: Getting To Know Your Multisync Mt830+/Mt1030+/Mt1035+ Lcd Projector
Getting To Know Your MultiSync MT830+/MT1030+/MT1035+ LCD Projector Front Features Lens And Lens Cap Carrying Handle One-Touch Front Vent Tilt button Front Feet Right Side Features Remote Sensor INTRODUCTION Rear Features AC Input Plug the female end of the supplied power cable here, and the male end into a properly grounded outlet. -
Page 11: Top Features
Top Features 1 Power Button Use this button to turn the power on and off when the Main Power Switch is on and the LCD projector is in standby. 2 Menu Button Displays the on- screen menu. 3 Select ( ) / (+)(–) Buttons Select: After you press the “Menu”... -
Page 12: Terminal Panel Features
Terminal Panel Features This panel is located on the left side and is where you connect your cables. 1 S-Video Input Here is where you connect the S-Video input from an external source like a VCR. Left Channel/Mono Audio Input Jack This is your left channel audio input for stereo sound coming from S-Video equipment or audio system. - Page 13 7 Mouse Output Port Use this port to operate your computer’s mouse functions from the NEC MultiSync MT830+/MT1030+/MT1035+ remote control. When your computer is connected here, the remote sensors on the LCD projector cabinet will receive your mouse commands.
-
Page 14: Remote Control Features
Remote Control Features You can use your remote control with the cable or wireless to operate your MultiSync MT830+/MT1030+/MT1035+ LCD Projector. With the mouse output port connected to your computer, you can also use the projector's remote control to operate your computer's mouse wireless. (See pages 59 and 60 to connect your computer to the mouse output port.) If you want to use your remote control with the cable, connect one end of the cable to the jack on the remote control and the other end to the... - Page 15 11 Laser Button Press and hold this button to activate the laser pointer. When lit, you can use the laser to draw your audience's attention to a red dot that you can place on any object within 30 feet (10 m). 12 Menu Button Use this button to call up the On-Screen Menu so you can adjust and set the image.
- Page 16 19 Slide Button Press (+) to advance the next file or slide and (-) to return to the previous file or slide. (the optional MT Viewer board required) 20 Magnify Button Use the (+) or (-) button to adjust the image size up to 400%. When the Pointer is displayed, the magnified image is displayed at the center of the Pointer.
-
Page 17: Installation
I N S T A L L A T I O N This section describes how to set up your MultiSync MT830+/MT1030+/ MT1035+ LCD projector and how to connect video and audio sources. Setting Up Your MultiSync MT830+/MT1030+/ MT1035+ LCD Projector Your MultiSync MT830+/MT1030+/MT1035+ LCD Projector is simple to set up and use. -
Page 18: Using A Tabletop Or Cart
Using A Tabletop Or Cart 1. Place your LCD projector on a flat level surface at the optimal distance from the screen or wall so you realize the size image you want. (Avoid having bright room lighting or sun light directly on the screen or wall where you'll be projecting the image.) 2. -
Page 19: Distance Chart
Distance Chart A : Distance between the lens and the screen center C : Horizontal throw distance between the screen surface and the lens D : Vertical distance between the projector foot and the bottom of image E : Vertical distance between the projector foot and the screen center INSTALLATION MT830+/MT1030+ Formulas(mm) - Page 20 MT830+/MT1030+ Standard Zoom Lens (Wide) Degree (sin= ) 0.16 0.15 (cos= ) 0.99 0.99 Screen Size inch H–Width 1219 4 : 3 Diagonal inch 1572 2400 inch 61.9 94.5 1552 2371 inch 61.1 93.4 inch -1.32 -0.16 inch 13.3 18.2 Standard Zoom Lens (Tele) Degree (sin= )
- Page 21 MT1035+ Standard Zoom Lens (Wide) Degree (sin= ) 0.17 0.17 (cos= ) 0.99 0.99 Screen Size inch H–Width 1219 4 : 3 Diagonal inch 1471 2242 inch 57.9 88.3 1452 2214 inch 57.2 87.2 inch -1.3 -0.13 inch 12.9 17.5 Standard Zoom Lens (Tele) Degree (sin= )
-
Page 22: Ceiling Installation
Ceiling Installation Installing your MultiSync MT830+/MT1030+/ MT1035+ LCD Projector on the ceiling must be done by a qualified technician. Contact your NEC dealer for more information. Do not attempt to install the projector yourself. NOTE : Distances may vary 5%. - Page 23 MT830+/MT1030+ Standard Zoom Lens (Wide) Degree (sin= ) 0.16 0.15 (cos= ) 0.99 0.99 Screen Size inch H–Width 1219 4 : 3 Diagonal inch 1572 2400 inch 61.9 94.5 inch 13.1 17.9 1552 2371 inch 61.11 93.36 inch -1.0 Standard Zoom Lens (Tele) Degree (sin= ) 0.12...
- Page 24 MT1035+ Standard Zoom Lens (Wide) Degree (sin= ) 0.17 0.17 (cos= ) 0.99 0.99 Screen Size inch H–Width 1219 4 : 3 Diagonal inch 1471 2242 inch 57.9 88.3 inch 12.6 17.2 1452 2214 inch 57.2 87.2 inch -1.0 Standard Zoom Lens (Tele) Degree (sin= ) 0.12...
-
Page 25: Reflecting The Image
The distance the projector must be from the screen is the same as if you were projecting the image from the front. Contact your NEC dealer if you need a transparent screen. -
Page 26: Wiring Diagram
Wiring Diagram S– VI D EO I NP UT A UDI O RGB MONIT OR OUTP UT L /M ONO L /M ONO VI DEO INP UT A UDI O Document Camera Signal cable (supplied) To mini D-Sub 15-pin connector on the LCD Projector. Remote Control Guideline 1. -
Page 27: Connecting Your Pc Or Macintosh Computer
Connecting Your PC Or Macintosh Computer Connecting your PC or Macintosh computer to your MultiSync MT830+ (SVGA) /MT1030+ and MT1035+ (XGA) Projector will enable you to project your computer's screen image for an impressive presentation. All of these following display standards are supported: VGA 640 480 for graphics VGA 640 400 for graphics... - Page 28 Examples of DIP switch setting 13” fixed mode 1 2 3 4 5 6 7 8 NOTE: Refer to your computer's owner's manual for more information about your computer's video output requirements and any special identification or configuring your projector's image and monitor may require. Settings for Macintosh Adapter Macintosh models applied Desktop type and PowerBook with...
- Page 29 2. Click and open "Options." 3. Select your new resolution and click "OK." If you have an NEC monitor connected to your Macintosh, you may have a "DPI-On-The-Fly" extension that enables you to change your resolution directly. The "DPI-On-The-Fly" icon is under your Apple menu.
-
Page 30: Connecting Your Document Camera
Connecting Your Document Camera You can connect your MultiSync MT830+/MT1030+/MT1035+ LCD Projector to a document camera. To do so, simply: 1. Turn off the power to your LCD projector and document camera. 2. Use a standard video cable to connect your document camera to the Video input on your projector. 3. -
Page 31: Connecting Your Computer To The Mouse Output Port
Connecting Your Computer to the Mouse Output Port The built-in remote mouse receiver enables you to operate your computer's mouse functions from the NEC MultiSync MT830+/ MT1030+/MT1035+ remote control. It is a great convenience for clicking through your computer-generated presentations. -
Page 32: Operation
O P E R A T I O N This section describes how to select a computer or video source and how to adjust the picture and sound. General Controls Before you turn on your MultiSync MT830+/MT1030+/ MT1035+ LCD Projector, ensure that the computer or video source is turned on and that your lens cap is removed. -
Page 33: Using The Menus
Using The Menus 1. Press the "Menu" button on the remote control or projector cabinet to display the Main Menu. 2. Press the "Select" button on the projector cabinet or ( ) ( ) buttons on your remote control to highlight the menu for the item you want to adjust. -
Page 34: Menu Descriptions & Functions
Menu Descriptions & Functions Source Menu Enables you to select a video source such as a VCR, DVD player, laser disc player, computer or document camera depending on what is connected to your inputs. Press the "Select" button on the projector cabinet or ( ) ( ) buttons on your remote control to highlight the menu for the item you want to adjust Video Selects what is connected to your Video input-VCR, laser disc player, DVD player, or... - Page 35 Image Adjustment Provides access to controls for your image and sound. Use the “Select” button on the projector cabinet or ( ) ( ) buttons on your remote control to highlight the menu for the item you want to adjust. Menu The volume, image mode, keystone, brightness, contrast, color, tint and sharpness controls are available for Video or S-Video sources.
- Page 36 When "Auto mode" is selected, the LCD projector automatically determines the best resolution for the current RGB input signal to project an image using NEC's AccuBlend Intelligent Pixel Blending Technology. Use the Mouse pad (–) button to turn off the Auto mode feature to enable the Resolution feature.
-
Page 37: Power Menu(Projector Control Icons)
Power Menu Provides access to Lamp Usage information and the Auto Start and Power Management fea- tures. Use the “Select” button on the projector cabinet or ( ) ( ) buttons on your remote control to access a submenu. Then press the Mouse pad (+) or (–) to choose a specific option. Lamp Usage This tells you how long the lamp has been in operation. -
Page 38: Settings Menu(Maintenance Icons)
Settings Menu Enables you to set preferences and other operating options. Use the “Select” button on the projector cabinet or ( ) ( ) buttons on your remote control to access the submenu you want. Capture (with the optional viewer board installed only) When Capture is selected, press "Enter"... -
Page 39: Using The Viewer Function
Using the Viewer function If you use the Viewer function on the LCD projector, you must first install the optional MT Viewer board (VK-MT) in the LCD projector and set up the exclusive software included with the VK-MT kit. See the user's manual included with the VK-MT for installing and uninstalling the software. - Page 40 Projecting Slides Orientation of flash memory card insertion The flash memory card has a front and a back side and the flash memory card is designed to be inserted in only one orientation. The card is designed so that it cannot be inserted in reverse, but trying to insert it forcefully might break the pins inside the slot or ruin the flash memory card slot.
- Page 41 Selecting a File from a List of Files * The Viewer feature allows you to store one or more presentation materials in a single flash memory card. Each material is referred to as a "file" or "slide". To select a file from a list of files 1.
- Page 42 Switching Slides To switch slides, press "SLIDE +" or "SLIDE -" button. This will cancel the Auto Play mode. To set the Auto Play mode, press the Menu button to select “Start” from the Source menu and press the Enter button on the cabinet or the Left Click button on the remote control.
-
Page 43: Maintenance
2000 hours of use, the lamp bulb may shatter, and pieces of glass may be scattered in the lamp case. Do not touch them as the pieces of glass may cause injury. If this happens, contact your NEC dealer for lamp replacement. -
Page 44: Cleaning Or Replacing The Filter
Cleaning Or Replacing The Filter The air-filter sponge keeps the inside of the MultiSync MT830+/MT1030+/MT1035+ LCD Projec- tor free from dust or dirt and should be cleaned after every 100 hours of operation (more often in dusty conditions). If the filter is dirty or clogged, your projector may overheat. NOTE: Clean your filter after every 100 hours of operation. - Page 45 2000 heures d’utilisation, l’ampoule peut se briser et des brisures de verre peuvent être éparpillées dans le compartiment de la lampe. Ne les touchez pas car elles peuvent vous blesser. Dans ce cas, contactez votre revendeur NEC afin de procéder au remplacement de la lampe.
-
Page 46: Nettoyage Ou Remplacement Du Filtre
Nettoyage ou remplacement du filtre Le coussin éponge du filtre à air maintient l’intérieur du projecteur à affichage à cristaux liquides MultiSync MT830+/MT1030+/MT1035+ à l’abri de la poussière ou de la saleté et doit être nettoyé toutes les 100 heures d’utilisation (plus souvent dans les endroits poussiéreux). Si le filtre est sale ou bouché, le projecteur risque de surchauffer. -
Page 47: Troubleshooting
Either the lamp cover or filter cover is not fastened properly. Check each and reattach them if necessary. The cooling fan has stopped. Contact your NEC dealer for service. The lamp is not turned on. • The projector was turned off and back on too quickly. Turn off the projector, wait one minute, then turn the projector back on. -
Page 48: Common Problems & Solutions
• While an image with over 1024 768 dots is projected, several lines of information will be lost. Use the supplied software to displayed change the image to 1024 768 dots in size. No effect sound • Is the sound volume set to the minimum level? To Contact Your NEC Service Representative, Call 1-800-836-0655 TROUBLE SHOOTING... -
Page 49: Specifications
S P E C I F I C A T I O N S This section provides technical information about the MultiSync MT830+/MT1030+/MT1035+ LCD Projector's performance. Optical LCD Panel Lens Lamp Image Size Projection Distance Electrical Inputs Video Bandwidth Color Reproduction Horizontal Resolution Power Requirement Input Current... -
Page 50: Cabinet Dimensions
Cabinet Dimensions 11.4" (290) FOCUS ZOOM – – ON/OFF POWER STATUS ENTER – SELECT MENU 7" (178.5) 13.1" (332) 830+ AC IN Unit : inch (mm) SPECIFICATIONS... -
Page 51: D-Sub Pin Assignments
D-Sub Pin Assignments PC 15-Pin mini D-Sub Pin No. Signal to be connected Green Blue Red GND Green GND Blue GND No Connection Digital GND No Connection Horizontal Sync Vertical Sync No Connection PC 15-Pin mini D-Sub SPECIFICATIONS... -
Page 52: Timing Chart
Timing Chart Signal Resolution NTSC 640 480 768 576 SECAM 768 576 VESA 640 350 640 400 VESA 640 400 640 400 VESA 640 480 640 480 640 480 640 480 640 480 VESA 640 480 VESA 640 480 640 480 VESA 640 480 720 350... -
Page 53: Pc Control Command Reference
PC Control Command Reference Command Codes Function Code Video RGB1 RGB2 S-VIDEO PC CARD Power On Power Off Picture Mute Onscreen Mute Power Zoom W Power Zoom T Power Focus + Power Focus – Reset Freeze Slide + Slide - Front Floor Front Ceiling Rear Floor... - Page 54 Command Codes (continued) Function Brightness Contrast Color Tint Sharpness Audio Volume Picture Adj Fine Picture H Position V Position Lamp Reset Language Select White Balance Sub Brightness Sub Contrast Pointer Select Video System These commands are subject to change without notice. *(Low-order data) (High-order data) CSUM CSUM = Checksum is a low-order digit of the sum from the Code to the immediately preceding data.
-
Page 55: Cable Connection
Cable Connection Communication Protocol Baud rate: 9600 bps Data length: 8 bits Parity: No parity Stop bit: One bit X on/off: None Full duplex Communications procedure: If the CPU of the LCD projector has received the data correctly, it returns an ACK(C5H). If the received data is not correct, the CPU returns a NAK(CAH), then the following status: Receiving success: Receiving failure:...
