Connecting Your Computer to the
Mouse Output Port
The built-in remote mouse receiver enables you to operate your
computer's mouse functions from the NEC MultiSync MT830/1030
remote control. It is a great convenience for clicking through your
computer-generated presentations.
To connect the mouse output port:
1. Turn off your computer.
2. For PCs: Remove your current mouse and connect the serial
cable from the mouse output to your PC's mouse port. (Use the
6-pin adapter for connecting to a PS/2 computer.)
For Macintosh: Remove your current mouse from your com-
puter, attach the Macintosh adapter to the mouse output port's
serial cable, and connect the LCD Projector to your mouse port.
3. When the built-in remote mouse receiver is available, it will
disable your regular mouse, disconnect the serial cable and
restart your computer.
The built-in Remote Mouse Receiver as a mouse for your computer
REMOTE
S – V ID E O
I N P U T
A U D I O
CONTROL
R GB M O NIT O R O UT PUT
AUDIO
INPUT
L / M O N O
R
RG B
I NP UT
1
AUDIO
RG B
INP UT
2
AUDIO
L/ M O N O
R
V I D E O
I N P U T
A U D I O
REMOTE
S – V ID E O
I N P U T
A U D I O
CONTROL
R GB M O NIT O R O UT PUT
AUDIO
INPUT
L / M O N O
R
RG B
I NP UT
1
AUDIO
RG B
INP UT
2
AUDIO
L/ M O N O
R
V I D E O
I N P U T
A U D I O
INSTALLATION
IBM PC/AT
Serial cable (supplied)
Macintosh
IBM PS/2
55
56
