MAXDATA Workstation Fusion 7000 User Manual page 10

Table 1. Workstation Board Features (continued)
Feature
Peripheral interfaces
RAID
Power
Security
Workstation monito-
ring and control
Form factor
10
Description
Two SATA channels, one device per channel
Two IDE interfaces with ATA-100 support
Up to four Universal Serial Bus (USB) 2.0 ports
Two RJ-45 Ethernet connectors (one Gigabit, one 10/100 megabit)
One diskette drive interface
One parallel port
One serial port
PS/2-compatible keyboard and mouse ports
RAID 0.1 using the Silicon Image 3112A PCI to Serial ATA controller
SSI-Entry Electronics Bay (EEB) 3.0 compliant
Power/sleep switch with LED indicator
Wake on LAN (WOL)
Wake on RTC
Wake on USB
BIOS password
Keyboard password protection
Floppy write protection
Hardware monitoring using the Winbond W83627HF super I/O controller
Software monitoring using LANDesk Client Manager (LDCM) 6
SSI-EEB 3.0 – compliant form factor
Features
