MULTI-BATTERY CHARGING STATION
Model 92775
OPERATING INSTRUCTIONS
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at: http://www.harborfreight.com
TO PREVENT SERIOUS INJURY,
READ AND UNDERSTAND ALL WARNINGS
AND INSTRUCTIONS BEFORE USE.
®
Copyright 2005 by Harbor Freight Tools
. All rights reserved. No portion of this
©
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
Advertisement
Table of Contents
Related Manuals for Chicago Electric 92775
Summary of Contents for Chicago Electric 92775
-
Page 1: Operating Instructions
. All rights reserved. No portion of this © manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. For technical questions or replacement parts, please call 1-800-444-3353. -
Page 2: Product Specifications
When unpacking, check to make sure all the parts listed and shown on the Product Features Listing on pages 9 through 11 are included. If any parts are missing or broken, please call Harbor Freight Tools at the number shown on the cover of this manual as soon as possible. -
Page 3: Work Area
Do not use small equipment, tools, or attachments to do the work of larger industrial equipment, tools, or attachments. Do not use this product for a purpose for SKU 92775 For technical questions, please call 1-800-444-3353 WORK AREA... - Page 4 “Inspection, Maintenance, And Cleaning” section of this manual. Use of unauthorized parts or failure to follow maintenance instructions may create a risk of electric shock or injury. SKU 92775 For technical questions, please call 1-800-444-3353 SERVICE SAVE THESE INSTRUCTIONS...
-
Page 5: Grounded Tools: Tools With Three Prong Plugs
The plug and outlet should look like that in the following illustration. (See Figure A.) 3-PRONG PLUG FIGURE A SKU 92775 For technical questions, please call 1-800-444-3353 GROUNDING WARNING! 120 VOLT, GROUNDED, ELECTRICAL OUTLET. -
Page 6: Extension Cords
5.1-7.0 7.1-12.0 12.1-16.0 16.1-20.0 *Based on limiting the line voltage drop to five volts at 150% of the rated amperes. FIGURE B SKU 92775 For technical questions, please call 1-800-444-3353 EXTENSION CORDS (120 VOLT) EXTENSION CORD LENGTH FEET FEET FEET... -
Page 7: Specific Safety Rules
Maintain labels and nameplates on the Charger. These carry important information. If unreadable or missing, contact Harbor Freight Tools for a replacement. To avoid electrical shock, never start or run the Charger in the rain. Never allow water or other liquids to leak inside the body of the Charger. - Page 8 Proper Battery Care: Battery leakage may occur under extreme usage or temperature conditions. If battery fluid comes in contact with skin, wash with soap SKU 92775 For technical questions, please call 1-800-444-3353 PAGE 8...
-
Page 9: Control Panel Features
CONTROL PANEL FEATURES FIGURE D CHARGING CURRENT SELECTOR (1) POWER ON (2) BATTERY CHARGING (3) BATTERY CHARGED (4) LOW BATTERY (5) POWER SWITCH (6) SKU 92775 For technical questions, please call 1-800-444-3353 SAVE THESE INSTRUCTIONS PAGE 9... - Page 10 Relay to protect the Battery Charger from a short circuit and reverse polarity. The 12 Volt Relay will not connect the battery to the Battery Charger unless the battery voltage is more than 9 volts and connected to the proper polarity.
- Page 11 The Battery Charger features six separate circuits that allow the unit to charge up to six batteries at once. To charge a battery, pull out the sliding Shelf on the Battery Charger, and place the battery on the Shelf. Connect the Charger Clamps (7) as discussed in Step #7, page 10 .
-
Page 12: Inspection, Maintenance, And Cleaning
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. SKU 92775 For technical questions, please call 1-800-444-3353 PAGE 12...
