SOLAR CHARGER 18V-24V
ASSEMbLy And OpERAtiOn inStRuCtiOnS
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE tHiS MAnuAL.
©
Copyright
2006 by Harbor Freight Tools
of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight
Tools. Diagrams within this manual may not be drawn proportionally.
Due to continuing improvements, actual product may differ slightly from
the product described herein. Tools required for assembly and service
may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Revised Manual 09k
Model
95000
®
All rights reserved. No portion
.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Chicago Electric 95000
Summary of Contents for Chicago Electric 95000
- Page 1 SOLAR CHARGER 18V-24V Model 95000 ASSEMbLy And OpERAtiOn inStRuCtiOnS Visit our website at: http://www.harborfreight.com Read this material before using this product. Failure to do so can result in serious injury. SAVE tHiS MAnuAL. © ® All rights reserved. No portion Copyright 2006 by Harbor Freight Tools of this manual or any artwork contained herein may be reproduced in...
-
Page 2: Specifications
SpECiFiCAtiOnS Solar Panels in a Portable Folding Design Features For Charging 18V through 24V Batteries, Charging Indicator LED, Blocking Diode to Prevent Draining, Four Different Adaptors Overall Dimensions 26 1/2” L X 20 1/2” W x 3/4” T (open position) 400 mA Maximum Output ~24 V Direct Sunlight, ~17.5 V Indirect Sunlight... - Page 3 Follow instructions in the “Inspection, Maintenance, And Cleaning” section of this manual. Use of unauthorized parts or failure to follow maintenance instructions may create a risk of property damage or injury. Maintain labels and nameplates on the charger. These carry important information. If unreadable or missing, contact Harbor Freight Tools for a replacement.
- Page 4 OpERAtiOn Solar Charger (1) Figure 1 Unfold the Solar Charger. Open the “support legs” on the backs. See Figure 1. Place the Charger in a position that can receive direct sunlight without shade. Turn the Solar Charger toward the sun. The blue LED will go on (or flash) whenever the Solar Charger is generating electricity.
- Page 5 See below for charging function instructions: Charging base Adapter : Refer to the manual that comes with the charging base. The charging time will be altered substantially–the Solar Charger must receive at least four hours direct sunlight to fully charge a battery. Different batteries will have different capacities and may require different charging times.
-
Page 6: Parts List
pARtS LiSt part description Q’ty Solar Charger w/Power Cord Charging Base Adapter Alligator Clamp Adapter Cigarette Lighter Receptacle Adapter Cigarette Lighter Plug Adapter Cordless Tool Charging Connector pLEASE REAd tHE FOLLOWinG CAREFuLLy tHE MAnuFACtuRER And/OR diStRibutOR HAS pROVidEd tHE pARtS LiSt And ASSEMbLy diAGRAM in tHiS MAnuAL AS A REFEREnCE tOOL OnLy. - Page 7 LiMitEd 90 dAy WARRAnty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
